| Camera |
|
| Image Sensor |
1/3” 4.0MP Progressive Scan CMOS |
| Max. Resolution |
4.0 Megapixel |
| Effective Pixels |
|
| RAM / ROM |
512MB / 128MB |
| Min Illumination |
|
| S/N Ratio |
> 56dB |
| Infrared System |
2 x Infrared LED, 50m range, Auto/manual on/off control |
| Lens |
|
| Lens Type |
Fixed |
| Lens / Iris |
2.8mm Fixed Focal Lens with Fixed Iris |
| Field of View |
Horizontal: 103°, Vertical: 55° |
| Focus |
Auto Focus / 0.9m Min. Focus Distance |
| DORI |
|
| Detect (25px/m) |
56m |
| Observe (63px/m) |
22m |
| Recognise (125px/m) |
11m |
| Identify (250px/m) |
6m |
| Video |
|
| Resolution |
4.0MP (2688 x 1520) to CIF (352 x 288) |
| Frame Rate (Main) |
|
| Frame Rate (Sub) |
D1 (1 ~ 25fps) |
| Frame Rate (Third) |
720p (1 ~ 25fps) |
| Video Compression |
H.265 / H.264 / H.264B / MJPEG |
| Bit Rate |
H.265: 3 ~ 8192Kbps / H.264: 3 ~ 8192Kbps |
| Bit Rate Control |
Constant bit rate (CBR) / Variable bit rate (VBR) |
| Day/Night |
|
| Lighting Compensation |
|
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom |
| Gain Control |
Auto / Manual |
| Noise Reduction |
3D DNR |
| Picture Control |
Mirror / Flip (0°, 90°, 180°, 270°) (Support 90°/270° with 2.0MP resolution) |
| IVS |
|
| Intelligent Functions |
Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Infrared |
| Perimeter Protection |
Tripwire & Intrusion (Add recognition of humans & vehicles) |
| Face Detection |
N/A |
| Face Attributes |
N/A |
| People Counting |
N/A |
| Heat Map |
N/A |
| Event Trigger |
Motion Detection, Video Tampering , Scene Changing, Network Disconnection, IP Address Conflict, Illegal Access, Storage Anomaly |
| Intelligent Search |
Via NVR Smart Search, Search tripwire/ intrusion events by people or vehicle |
| Network |
|
| Ethernet |
|
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Streaming Method |
|
| Max. User Access |
20 Users |
| Interface |
|
| Video Interface |
N/A |
| Audio Interface |
Built-in Mic / Audio Compression - G.711a; G.711Mu; G726; AAC: G.723 |
| Alarm Interface |
N/A |
| RS485 |
N/A |
| Edge Storage |
MicroSD Card (up to 256GB) / NAS |
| Interoperability |
ONVIF / P2P / CGI / Milestone / Genetec |
| Environmental |
|
| Power Supply |
|
| Power Consumption |
<7.7W |
| Operating Conditions |
|
| Ingress Protection |
IP67 |
| Vandal Resistance |
N/A |
| Series |
|
| Camera Type |
Turret |
| Housing |
Metal |
| Pan/Tilt/Rotation |
Pan: 0° ~ 360°, Tilt: 0° ~ 78°, Rotation: 0° ~ 360° |
| ePoE |
No |
| Dimensions |
|
| Net Weight |
0.55kg |
| Warranty (Years) |
4 |
