NVR HAC (16-ch) is a 16-channel network video recorder designed for reliable video surveillance management. It supports high-resolution recording up to 8MP and provides HDMI output for clear live viewing and playback.
The device supports multiple video compression formats including H.265 and H.264, enabling efficient storage and bandwidth usage. It also integrates intelligent video analytics such as motion detection and AI object detection when used with compatible Ajax cameras.
Features
- Supports up to 16 IP camera channels
- Recording resolution up to 8MP
- Supports H.265, H.264, and JetSparrow video compression
- HDMI output for live monitoring
- Integrated video management system
- Motion detection and AI object detection support
- Supports Ajax cameras and ONVIF compatible IP cameras
- Interactive timeline and smart event filtering
- Video wall interface for monitoring multiple cameras
- Visual verification of Ajax system alarms
Complete Set
- NVR HAC (16-ch)
- SmartBracket mounting panel
- Power cable
- Ethernet cable
- Installation kit
- Quick start guide
Download
Tech Specs
| Device Type |
Network Video Recorder (NVR) |
| Video Input |
16 channels |
| Recording Resolution |
8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Live View / Playback Resolution |
8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF |
| HDMI Output Resolution |
1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720 px |
| Video Compression |
H.265, H.264, JetSparrow |
| Decoding Capability |
1 × channel at 8MP
3 × channels at 5MP
4 × channels at 4MP
4 × channels at 1080p
10 × channels at 720p
16 × channels at 1024 × 576 |
| Synchronous Playback |
16 channels |
| Live View Layout |
1, 4, 9, 16, 5+1, 7+1 views (custom layouts up to 10 × 10) |
| Motion Detection |
Up to 16 channels |
| AI Object Detection |
Supported with Ajax cameras |
| HDD |
1 × SATA (supports up to 16 TB, 3.5" HDD) |
| Network Interface |
1 × RJ-45 Ethernet (10/100 Mbps) |
| USB Ports |
2 × USB 2.0 (Type-A) |
| Network Bandwidth |
Incoming: up to 80 Mbps / Outgoing: up to 40 Mbps |
| Protocols |
HTTP, HTTPS, TCP/IP, IPv4, IPv6, SNMP, RTSP, UDP, DHCP, DNS, DDNS |
| Interoperability |
ONVIF compatible |
| Main Power Supply |
110–240 V~, 50/60 Hz |
| Power Consumption |
Up to 24 W |
| Clock Battery |
CR2032, 3 V |
| Dimensions |
212 × 212 × 64 mm |
| Weight |
782 g (without HDD) |
| Operating Temperature |
0 °C to +40 °C |
| Operating Humidity |
Up to 75% |
| Protection Class |
IP20 |
| Color |
Black / White |
2-Years Warranty
Ajax’s 2-year manufacturer warranty covers defects in materials or errors in the manufacturing process that may occur within 24 months from the date of sale. The warranty does not cover normal wear and tear (device body scrapes, scratches, etc.), wear of the elements caused by improper operation, and normal wear of the device components, mechanical and/or electrical damage (including latent), exposure to direct sunlight, high humidity, and vibration or damage caused by natural disasters.
The warranty does not cover damage to the product resulting from unauthorised repair, installation, and/or replacement of components or programs, including the installation of updates and extensions, performed by anyone other than an authorised representative of the Limited Liability Company “Ajax Systems Manufacturing”.
If a device is faulty, SpyMonkey will facilitate the warranty process with the manufacturer for you. We aim to do so in a manner that is as fast and efficient as possible.
Please contact our support team at support@SpyMonkey.com.au or 1300-049-519.
Please note, that we do not cover inbound shipping of the return to us however if a replacement is to be sent we will cover outbound shipping to the customer. We will need the serial number of the product and your order number.
Please don’t ship us anything until you have had confirmation from our teams and they have given you an RMA number and return address.
