| Physical & Power |
Display: 7" capacitive touch screen, 1024×600 resolution (16:9) Camera: 2MP CMOS with privacy shutter Memory: 2GB DDR3, 8GB Flash Interfaces: 1× Type-C, 1× HDMI out, 3× relay outputs, 3× inputs Indicators: Power, Network, Message LEDs Audio: Dual microphones, dual speakers, noise suppression, AEC, VAD, AGC, CNG Bluetooth & BLE support Power: IEEE802.3af PoE Dimensions: 363.5 × 179.8 × 30.8 mm Installation: Flush or wall mount IP Rating: IP66 IK Rating: IK08 Tamper Resistant: Yes |
| Environmental |
Working Temperature: 0°C ~ +40°C Storage Temperature: -20°C ~ +70°C Humidity: 10–90% non-condensing |
| Video |
Resolution: up to 1920×1080 Frame rate: 1080p@30fps Technology: HDR Formats: CIF, QCIF, VGA, 4CIF, 720p, 1080p |
| Networking |
Protocols: IPv4/IPv6, HTTP/HTTPS, FTP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP |
| Deployment & Maintenance |
Auto-provisioning (FTP/TFTP/HTTP/HTTPS) Web management portal Firmware upgrade, backup/restore, system logs Web-based packet dump |
| Phone Features |
SIP Accounts: 2 Call waiting, hold, transfer, auto redial, speed dial, direct IP call Multicast paging, action URL/URI Local audio/video recording, conference calls DND, adjustable volume, selectable ringtones Multi-language support, daylight saving time |
| Directory |
Local phonebook: up to 3000 groups with contact pictures Call logs: 600 entries (200 missed, 200 dialed, 200 received) Favorites, blacklist, LDAP support Intelligent search method |
| Default Applications |
Browser, Calculator, Calendar, Camera, Clock, Contacts, Dialer, Downloads, Explorer, Gallery, Messages, Music, Phone Settings, Reboot Setting, Search, Settings, Sound Recorder, Surveillance, Video |
