| Image Sensor |
2 × 1/2.5" Progressive Scan CMOS |
| Maximum Resolution |
3632 × 1632 (6MP) |
| Main Stream |
50Hz: 20fps (4096 × 1860)
60Hz: 20fps (4096 × 1860) |
| Sub Stream |
50Hz: 1200 × 536 / 960 × 432 @20fps
60Hz: 1200 × 536 / 960 × 432 @20fps |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| Video Bit Rate |
32 Kbps – 16 Mbps |
| Lens |
Dual 2.8mm Fixed Lenses |
| Viewing Angle |
180° Horizontal | 77° Vertical |
| Minimum Illumination |
Colour: 0.005 Lux @ (F1.6, AGC ON) |
| Audio |
Built-in Microphone & Built-in Speaker |
| Audio Compression |
G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC |
| Motion Detection |
Motion Detection 2.0 with Human & Vehicle Detection |
| Supplement Light |
Smart Light, White Light & IR Light |
| Supplement Light Range |
White Light: Up to 30m
IR Light: Up to 30m |
| Wide Dynamic Range |
120dB WDR |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Basic Events |
Motion Detection, Human & Vehicle Detection, Video Tampering, Exception Detection |
| Privacy Mask |
4 Programmable Polygon Privacy Masks |
| Audio Alarm |
Supported (Custom Audio via ANNKE App) |
| Region of Interest (ROI) |
1 Fixed Region for Main Stream |
| General Functions |
Rotate, Remote Access, IP Address Filter |
| API |
ONVIF Version 19.12 |
| Network Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP |
| Ethernet Interface |
1 × RJ45 10/100 Mbps Self-adaptive Ethernet Port |
| Storage |
Built-in MicroSD / SDHC / SDXC Slot, Supports up to 512GB (Card Not Included) |
| Power Supply |
PoE (IEEE 802.3af, Max. 11.5W) or DC 12V ±25% (Max. 10W) |
| Housing |
Metal & Plastic |
| Indoor / Outdoor |
Indoor / Outdoor |
| Weatherproof Rating |
IP67 |
| Operating Temperature |
-30°C to 60°C (-22°F to 140°F) |
| Dimensions (L × W × H) |
103.6 × 76 × 234.5 mm (4.1" × 3.0" × 9.2") |
| Weight |
Approx. 560g (1.2 lb.) |
| Hardware Reset |
Yes |
