The Hikvision DS-UPS600 is a reliable and compact UPS (Uninterruptible Power Supply) designed to safeguard your essential security equipment from power fluctuations. With its wide input voltage range and built-in AVR (Automatic Voltage Regulation), it ensures a stable power supply, protecting your devices from damage and ensuring continuous operation. Ideal for homes and small businesses, this UPS offers super-fast charging and comprehensive protection against overloads and short circuits, making it a crucial component for maintaining an uninterrupted security system.
Features
-
Reliable Power Backup: Provides immediate backup power during outages, ensuring your security system remains operational.
-
Automatic Voltage Regulation (AVR): Stabilizes incoming power, protecting sensitive electronics from voltage spikes and sags.
-
Fast Charging: Quickly recharges its battery (4-6 hours to 90% capacity) to be ready for the next power event.
-
Compact Design: Space-saving dimensions (274 mm × 95 mm × 139 mm) allow for easy integration into any setup.
-
Comprehensive Protection: Safeguards against surges, overloads, and discharge, extending the lifespan of your connected devices.
-
Clear Status Indicators: LED display clearly shows working mode, charging status, and fault conditions for easy monitoring.
-
Audible Alarms: Provides distinct audio alerts for various conditions like low battery, overloading, and faults.
-
Wide Operating Range: Functions reliably in temperatures from 0 °C to 40 °C and humidity from 30% to 90%.
-
Essential for Security Systems: Ensures continuous power for DVRs, NVRs, cameras, and other critical security components.
DOWNLOADS
Extra Info
Uninterrupted Power for Critical Systems
The DS-UPS600 acts as a vital buffer between your valuable security equipment and an unstable power grid. When the main power fails, it seamlessly switches to battery power in less than 10 milliseconds, preventing your surveillance cameras, recorders, or alarms from shutting down unexpectedly. This ensures that your property remains monitored and protected, even during blackouts.
Stable Voltage with Built-in AVR
Fluctuating voltage can damage sensitive electronics over time. The integrated Automatic Voltage Regulation (AVR) feature of the DS-UPS600 automatically corrects incoming voltage to a safe and consistent range (210 VAC to 235 VAC output), providing a clean power supply to your connected devices and extending their operational life.
Rapid Recovery
After a power event, the UPS quickly recharges its 12V/7Ah battery, reaching 90% capacity within 4-6 hours. This rapid recharge capability means your system is quickly prepared for subsequent power interruptions, ensuring continuous readiness.
Protection Against Electrical Hazards
Beyond basic backup, this UPS offers comprehensive protection features. It includes surge protection to defend against sudden voltage spikes, overload protection to prevent damage from excessive power draw, and discharge protection to maintain battery health, all contributing to the longevity and reliability of your security setup.
Technical Specifications
| Specification |
Details |
| Model |
DS-UPS600 |
| Power Capacity |
600 VA / 360 W |
| Input Voltage Range |
140 VAC to 290 VAC |
| Input Frequency |
50/60 Hz |
| Output Voltage Range |
210 VAC to 235 VAC |
| Output Frequency |
50 Hz ± 0.5 Hz |
| Transfer Time |
≤ 10 ms |
| Waveform |
PWM |
| Battery Type |
12 V/7 Ah |
| Recharge Time |
4-6 hours recover to
90% capacity |
| Display Indicator |
Working Mode (AC Mode): Solid green
Charging Mode (DC Mode): Solid red
Overloading Mode: Flashing yellow |
| Alarm |
Charging Mode (DC mode): Sounding every 8 seconds
Low Battery: Sounding every second
Overloading Mode: Sounding every 0.5 seconds
Fault: Continuously sounding |
| Communicate Ports |
No |
| Full Protection |
Surge protection,
Overload protection,
Discharge protection |
| Operating Temperature |
0 °C to 40 °C
(32 °F to 104 °F) |
| Operating Humidity |
30% to 90%
(non-condensing) |
| Dimension |
274 mm × 95 mm × 139 mm
(10.79" × 3.74" × 5.47") |
| Weight |
Approx. 4.2 kg (9.26 lb) |
Q&A
Q: What is the power capacity of the DS-UPS600?
A: The DS-UPS600 has a power capacity of 600 VA / 360 W.
Q: How long does it take for the battery to recharge?
A: The battery recharges to 90% capacity in 4-6 hours.
Q: Does this UPS have automatic voltage regulation (AVR)?
A: Yes, it has a built-in AVR that provides an output voltage range of 210 VAC to 235 VAC.
Q: What kind of protection does the DS-UPS600 offer?
A: It offers surge protection, overload protection, and discharge protection.
Q: What are the dimensions of the DS-UPS600?
A: The dimensions are 274 mm × 95 mm × 139 mm (10.79" × 3.74" × 5.47").
Q: Does it have communication ports?
A: No, the DS-UPS600 does not have communication ports.
