The AXIS FA3105-L is a discreet 1080p indoor sensor unit designed for flexible, around-the-clock surveillance. With a compact eyeball design, built-in IR illumination, and Forensic WDR, it ensures clear video even in total darkness or challenging lighting. Ideal for banks, gas stations, and retail environments, it offers reliable coverage and easy mounting when paired with an AXIS FA Main Unit.
Feature
-
1080p Full HD Resolution – Captures sharp, detailed video at up to 30 fps for dependable indoor surveillance.
-
Forensic WDR – Delivers clear and balanced images in scenes with strong backlight or shadows.
-
Built-in IR Illumination – Enables effective video capture in complete darkness up to 15 meters or more.
-
Eyeball Design – Compact flat-faced form allows flexible installation on walls or ceilings.
-
Corridor Format – Optimised for vertically oriented areas like aisles, hallways, and entrances.
-
Rugged, Compact Build – Lightweight aluminum/plastic casing is IP3X-rated and PVC-free for sustainable, long-term use.
-
Simple Integration – Connects via an 8-meter cable to the AXIS FA54 Main Unit for centralized processing and power.
What’s Included:
- AXIS FA3105-L Eyeball Sensor Unit
- 8-meter (26 ft) black connection cable
- Mounting bracket
DOWNLOADS
Key Info
Flexible and Discreet Installation
The compact eyeball design offers easy placement in tight or high-risk indoor locations like banks, retail stores, and fuel stations.
24/7 Surveillance Ready
With built-in IR LED and automatic IR cut filter, the sensor captures detailed images day or night, even in total darkness.
Exceptional Clarity in Any Light
Forensic WDR ensures reliable image quality even in high-contrast or backlit scenes, helping to distinguish important details.
Simple Connection to Main Unit
Designed for use with AXIS FA54 Main Unit, the sensor connects with an included 8-meter cable, simplifying deployment and management.
Secure and Sustainable
Complies with key EMC, safety, and environmental standards, with PVC-free materials and a 5-year Axis warranty.
Tech Specs
| Specification |
Details |
| **Camera** |
|
| Image Sensor |
1/3” (effective) progressive scan RGB CMOS |
| Lens |
Fixed iris 3.13 mm, F2.0 |
| Field of View |
H: 103°, V: 55° |
| Day/Night |
IR-cut filter with built-in 850 nm IR LED |
| Minimum Illumination |
Color: 0.2 lux / 0 lux with IR |
| IR Range |
15 m (50 ft) or more depending on scene |
| Shutter Speed |
1/32500 s to 1/25 s (50 Hz), 1/32500 s to 1/30 s (60 Hz) |
| Wide Dynamic Range |
Forensic WDR |
| **Video** |
|
| Resolution |
1920x1080 (1080p) |
| Frame Rate |
Max. 25/30 fps (50/60 Hz) |
| Compression |
Via AXIS FA Main Unit |
| Streaming |
Via AXIS FA Main Unit |
| Image Settings |
Via AXIS FA Main Unit (brightness, contrast, white balance, etc.) |
| Corridor Format |
Supported |
| **Audio** |
|
| Input/Output |
Supported via AXIS FA Main Unit (e.g., FA54) |
| **Network** |
|
| Connector |
Connected to FA Main Unit via 8 m cable |
| Protocols |
Network features handled by AXIS FA Main Unit |
| **System Integration** |
|
| API |
VAPIX, ONVIF, and others via FA Main Unit |
| Event Triggers |
Motion, tampering, etc., via Main Unit |
| Event Actions |
Configurable through Main Unit |
| **Analytics** |
|
| Included |
Motion detection, etc., via FA Main Unit |
| Optional |
ACAP applications via FA Main Unit |
| **Cybersecurity** |
|
| Software |
Secure boot, signed firmware, etc., via Main Unit |
| Hardware |
Security features handled by Main Unit |
| **General** |
|
| Casing |
Aluminum and plastic, PVC-free |
| Power |
Supplied by AXIS FA Main Unit |
| Mounting |
Surface mount with included bracket |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F), 5–95% RH (non-condensing) |
| Operating Conditions |
-20 °C to 50 °C (-4 °F to 122 °F), 10–85% RH (non-condensing) |
| Dimensions |
Ø 72.7 mm × H 57 mm (2 7/8 in × 2 1/4 in) |
| Weight |
88 g (0.19 lb) |
| Required Hardware |
AXIS FA54 Main Unit |
| IR Illumination |
850 nm IR LED, power-efficient, long-life |
| Approvals |
EMC: EN 55032 Class A, FCC Part 15 Class A, ICES-003 Class A, VCCI Class A, RCM, KCSafety: IEC/EN/UL 62368-1, EN 62471Environment: IEC 60529 IP3X, IEC 60068-2-1/-2/-14/-78, IEC 60068-2-6/-27 |
| Optional Accessories |
AXIS F7315 Cable White 15 m |
| Warranty |
5-year warranty |
Q&A
Q1: Can the AXIS FA3105-L record in complete darkness?
A: Yes. It features built-in IR LEDs that enable surveillance in 0 lux environments up to 15 meters or more.
Q2: Does this sensor unit work standalone?
A: No. It must be connected to an AXIS FA Main Unit, such as the AXIS FA54, to function.
Q3: Where is it best to install the FA3105-L?
A: It’s ideal for indoor applications like banks, gas stations, and retail stores where discreet, flexible surveillance is needed.
Q4: How does Forensic WDR help in real-world use?
A: It enhances image visibility in scenes with high contrast—like entrances with strong sunlight—ensuring no detail is missed.
Q5: Is the camera environmentally friendly?
A: Yes. The unit is PVC-free and meets multiple environmental and safety standards, supporting sustainable operations.
