The AXIS M1065-LW is a compact, full-featured indoor wireless network camera designed for home, office, and retail surveillance. With HDTV 1080p resolution, built-in microphone and speaker, and PIR motion detection—even in the dark—it delivers reliable video and audio monitoring. Easy to mount and install, it supports wireless connection and edge storage for flexible deployment.
Feature
-
Wireless and Edge Storage – Supports Wi-Fi and microSD for easy installation without extensive cabling.
-
Built-in Audio and Alerts – Microphone and mini-speaker allow for two-way audio, announcements, or alerts.
-
PIR Motion Sensor – Detects movement even in complete darkness using passive infrared technology.
-
Full HD 1080p Quality – Crisp video resolution with Wide Dynamic Range (WDR) for balanced exposure.
-
Easy Installation – Includes wall and corner brackets, and a compact form factor ideal for indoor use.
-
IR Night Vision – Built-in infrared LEDs offer up to 10 meters of night visibility.
-
AXIS Guard Suite Included – Built-in analytics such as motion detection, tampering alarm, loitering guard, and more.
What's Included:
- AXIS M1065-LW Camera
- Power supply
- Mounting bracket and tabletop stand
- Installation Guide
- Windows decoder 1-user license
DOWNLOADS
Key Info
Smart Indoor Surveillance
Compact and modern, the M1065-LW fits discreetly into home or business settings, providing real-time video and audio with smart motion alerts.
Flexible Connectivity
Supports both 2.4 GHz and 5 GHz wireless frequencies, WPS push-button pairing, and secure WPA/WPA2 connections.
Integrated Audio Features
Built-in mic and speaker support two-way voice and audio clip playback. Alerts or announcements can be triggered automatically.
Built-in PIR Sensor
Detects movement through heat signatures, offering more accurate motion detection, especially in low-light or nighttime conditions.
Reliable Night Vision
Integrated IR LEDs provide up to 10 meters (32 feet) of coverage in total darkness.
Tech Specs
| Specification |
Details |
| **Camera** |
|
| Image Sensor |
1/3" progressive scan RGB CMOS |
| Lens |
2.8 mm, F2.0, fixed, 110° horizontal FOV |
| Day/Night |
Removable IR cut filter, IR illumination up to 10 m |
| Min. Illumination |
Color: 0.25 lux / B&W: 0.05 lux / 0 lux with IR |
| PTZ |
Digital PTZ |
| **Video** |
|
| Compression |
H.264 (Baseline/Main/High), Motion JPEG |
| Resolution |
1920x1080 to 320x240 |
| Frame Rate |
Up to 25/30 fps (50/60 Hz) |
| Streaming |
Multiple configurable streams, Zipstream, VBR/MBR |
| Image Settings |
WDR, white balance, contrast, overlays, rotation, privacy masks |
| **Audio** |
|
| Streaming |
Two-way, half duplex |
| Audio Formats |
LPCM, AAC-LC, G.711, G.726, Opus |
| I/O |
Built-in mic and speaker (82 dB-SPL at 0.5 m) |
| **Network** |
|
| Wireless |
IEEE 802.11a/b/g/n, 2.4 GHz and 5.2 GHz |
| Security |
WPA/WPA2, HTTPS, IEEE 802.1X, IP filtering, WPS |
| Protocols |
IPv4/6, HTTP/S, FTP, CIFS, RTSP, SNMP, TCP/IP, DHCP, etc. |
| **System Integration** |
|
| API |
VAPIX, ONVIF S/G/T, ACAP |
| Events |
Motion detection, PIR, audio, edge storage |
| Actions |
IR LED, audio playback, video buffering, file upload, notification |
| **Analytics** |
|
| Included |
Motion Guard, Fence Guard, Loitering Guard, Audio Detection, Tampering Alarm |
| Supported |
AXIS Camera Application Platform (ACAP) |
| **Cybersecurity** |
|
| Features |
Signed firmware, brute force delay protection |
| Storage |
microSD/microSDHC/microSDXC, NAS |
| **General** |
|
| Casing |
White polycarbonate/aluminum, PVC-free, 64% recycled plastic |
| Power |
4.75–5.25 V DC, 2.7W typical, 5.0W max |
| PIR Sensor |
Up to 6 m (19.7 ft) range |
| Operating Conditions |
0°C to 40°C (32°F to 104°F), 10–85% RH |
| Dimensions |
106 x 60 x 37 mm |
| Weight |
128 g (0.28 lb) |
| Warranty |
5-year warranty |
Q&A
Q1: Does this camera work over Wi-Fi?
A: Yes, it supports both 2.4 GHz and 5 GHz bands with internal antennas and WPS button pairing.
Q2: Can I use this for two-way audio?
A: Yes, it has a built-in microphone and speaker for communication and audio alerts.
Q3: Does it work in low light?
A: Yes, with IR illumination and PIR motion detection, it performs well in total darkness.
Q4: Is storage included?
A: It supports microSD cards and NAS. Some bundles may include a 64 GB card.
Q5: Is the warranty really 5 years?
A: Yes, the AXIS M1065-LW comes with a 5-year warranty from Axis.
