The Axis M3075-V is a compact, ultra-discreet indoor dome camera designed for precision surveillance in retail shops, offices, banks, and schools. It delivers crisp 2 MP video with true WDR, built-in IR for low-light conditions, and even HDMI output for live view on local monitors. Easy to install and tamper-resistant, the M3075-V offers built-in analytics, audio detection, and Axis’s Zipstream technology for efficient bandwidth use. It’s an ideal fit for professional-grade security with minimal visual impact.
Features
-
Built-in IR Illumination – Captures clear video even in total darkness, perfect for 24/7 indoor monitoring.
-
Wide Dynamic Range (WDR) – Handles scenes with varied lighting, such as entrances and glass-front areas.
-
HDMI Output – Directly connect to a monitor for live, on-site viewing without additional hardware.
-
Wide-Angle Fixed Lens – Covers a broad area with minimal distortion, ideal for room corners and small spaces.
-
Compact, Vandal-Resistant Design – IK08-rated dome withstands tampering, great for high-traffic indoor zones.
-
Built-in Microphone – Enables audio detection and recording for a complete situational picture.
-
Axis Zipstream with H.264/H.265 – Reduces bandwidth and storage use without compromising image quality.
-
Edge Storage & Remote Access – Store footage locally on microSD or stream securely via Axis Companion.
-
AXIS Object Analytics – Detects and classifies humans and vehicles out of the box, saving monitoring time.
Downloads
Extra Info
Smart Low-Light Performance
The Axis M3075-V is equipped with built-in IR LEDs and Wide Dynamic Range to ensure sharp, balanced images in low light and high-contrast environments. Whether monitoring a dim hallway or a backlit entrance, details remain visible and usable.
Discreet Yet Durable
Its compact and low-profile dome design blends into ceilings, while the IK08 vandal-resistant housing defends against intentional damage—making it an excellent choice for customer-facing spaces.
Direct Monitoring via HDMI
The HDMI output lets you plug the camera directly into a local display for real-time viewing without a recorder. Ideal for retail counters or reception areas where immediate visual confirmation is needed.
Integrated Audio for Detection
With its built-in microphone, the M3075-V can trigger events based on audio cues—useful in environments where visual alerts alone aren’t enough, such as detecting raised voices or glass breaking.
Intelligent Video Analytics
Preloaded with AXIS Object Analytics, the camera can intelligently detect and differentiate between people and vehicles. This cuts down on false alarms and improves response times, especially in unmanned setups.
Tech Specs
| Camera Model |
AXIS M3075-V |
| Image Sensor |
1/2.9" progressive scan RGB CMOS |
| Minimum Illumination |
Color: 0.11 lux at 50 IRE (F2.0)
B/W: 0 lux with IR illumination on |
| IR Illumination |
OptimizedIR
Range up to 20 m (65 ft) |
| Lens |
Fixed lens, 2.8 mm
Horizontal FOV: 106°
Vertical FOV: 59°
Fixed iris, F2.0 |
| Day/Night Functionality |
IR-cut filter with auto switch |
| Video Compression |
H.264 (Baseline, Main, High Profile)
H.265 (Main Profile)
Motion JPEG |
| Video Streaming |
Multiple configurable streams
Controllable frame rate and bandwidth
Zipstream for H.264 and H.265 |
| Resolutions |
1920x1080 (1080p) to 320x180 |
| Frame Rate |
Up to 25/30 fps (50/60 Hz) |
| Video Analytics |
AXIS Object Analytics (with classification)
Motion detection, audio detection, tampering alarm |
| Audio Capabilities |
Built-in microphone
One-way audio |
| Network Interface |
RJ45 10/100 Mbps Ethernet |
| Security |
Password protection
IP address filtering
HTTPS encryption
IEEE 802.1x (EAP-TLS), etc. |
| Supported Protocols |
IPv4, IPv6, HTTP, HTTPS, SSL/TLS, QoS, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMP, etc. |
| Storage Options |
microSD/microSDHC/microSDXC slot
Support for recording to network-attached storage (NAS) |
| Connectors |
RJ45 for Ethernet
HDMI Type D (micro) output |
| HDMI Output |
1080p resolution
Configurable video stream |
| Operating Conditions |
0°C to 40°C (32°F to 104°F)
Humidity: 10–85% RH (non-condensing) |
| Storage Conditions |
–40°C to 65°C (–40°F to 149°F) |
| Vandal Resistance |
IK08-rated |
| Mounting Options |
Ceiling or wall mount (kit included) |
| Power |
Power over Ethernet (PoE) IEEE 802.3af Type 1 Class 2
Max. 4.3 W |
| Dimensions |
Height: 48 mm (1.9 in)
Ø: 101 mm (4.0 in) |
| Weight |
210 g (0.46 lb) |
| Included Accessories |
Installation guide, Windows decoder license, drill template, cable gasket |
| Optional Accessories |
T94B01P Conduit Back Box
T94B02M J-Box/Gang Box Plate
AXIS TP3701 Plenum Box |
| Regulatory Approvals |
EMC, Safety, Environment, Network |
| Warranty |
5-year limited hardware warranty |
| Product SKU |
02357-001 |
Q&A
Q: Can this camera be used outdoors?
A: No, the M3075-V is designed for indoor use only. It does not have weatherproof housing.
Q: Does it support local video display without a recorder?
A: Yes, it features an HDMI output for direct connection to a monitor—perfect for real-time local viewing.
Q: What kind of night vision does it have?
A: It includes built-in IR LEDs with a range suitable for small to medium indoor spaces, allowing clear footage even in complete darkness.
Q: Can I record audio with this camera?
A: Yes, the built-in microphone allows for audio recording and event-triggered detection based on sound.
Q: What analytics are included?
A: AXIS Object Analytics comes built-in, enabling detection and classification of people and vehicles out of the box.
Q: Does it support edge storage?
A: Yes, the M3075-V includes a microSD card slot for onboard recording.
