The AXIS M3126-LVE is a compact and affordable 4MP outdoor dome camera designed to deliver reliable surveillance performance in demanding environments. Featuring Lightfinder, Forensic WDR, OptimizedIR, and advanced cybersecurity features, it provides excellent image quality day and night. Ideal for schools, retail stores, office buildings, warehouses, and perimeter monitoring applications.
Features
-
4MP Resolution – Captures detailed video for enhanced situational awareness and forensic evidence.
-
Lightfinder Technology – Delivers clear color images in low-light conditions.
-
Forensic WDR – Maintains image detail in scenes with bright and dark areas.
-
OptimizedIR – Provides reliable surveillance in complete darkness.
-
3.1 mm Fixed Lens – Wide field of view ideal for general-purpose surveillance.
-
Compact Outdoor Design – Easy to install in a wide range of locations.
-
H.265 with Zipstream – Optimizes bandwidth and storage usage.
-
Axis Edge Vault – Hardware-based cybersecurity protection.
-
Remote Maintenance – Efficient management and firmware updates.
What's Included:
- AXIS M3126-LVE Dome Camera
- Weather Shield
- Installation Hardware
- Terminal Connectors
- Quick Installation Guide
- Windows Decoder License
DOWNLOADS
Key Info
Reliable Outdoor Surveillance
The AXIS M3126-LVE combines high-quality imaging technologies with a rugged outdoor-ready design. Its compact footprint makes it suitable for a wide range of installations while delivering dependable surveillance performance.
Excellent Image Quality Day and Night
Advanced imaging technologies ensure clear and usable footage in challenging environments.
-
Lightfinder for improved color images in low light
-
Forensic WDR for balanced exposure in difficult lighting conditions
-
OptimizedIR for monitoring in complete darkness
-
4MP Resolution for enhanced detail and identification
Efficient Video Management
The camera supports advanced compression technologies and edge storage capabilities to reduce bandwidth requirements while maintaining image quality.
- Zipstream technology
- H.264 and H.265 compression
- Edge storage support
- Remote management capabilities
Built for Outdoor Security
- IP66 and IP67 weather protection
- IK10 vandal resistance
- Axis Edge Vault cybersecurity platform
- Reliable operation in demanding environments
Tech Specs
| Specification |
Details |
| Model |
M3126-LVE (02918-001) |
| Camera Type |
Outdoor Dome Camera |
| Image Sensor |
1/2.7" Progressive Scan RGB CMOS |
| Resolution |
2688 × 1512 (4MP) |
| Lens |
3.1 mm Fixed Lens, F2.0 |
| Field of View |
Horizontal: 106°, Vertical: 58° |
| Frame Rate |
Up to 30 fps |
| Day/Night Function |
Automatic IR-cut Filter |
| Minimum Illumination |
Color: 0.19 lux, B/W: 0 lux with IR on |
| Lightfinder |
Yes |
| Wide Dynamic Range |
Forensic WDR |
| IR Illumination |
OptimizedIR |
| Video Compression |
H.264, H.265, Motion JPEG, Zipstream |
| Memory |
1024 MB RAM, 512 MB Flash |
| Storage |
microSD/microSDHC/microSDXC Support |
| Network Interface |
RJ45 10/100 Ethernet |
| Power |
PoE IEEE 802.3af Class 3 |
| Protection Ratings |
IP66, IP67, IK10, NEMA 4X |
| Operating Temperature |
-30°C to 50°C |
| Warranty |
5-Year Warranty |
Q&A
Q: Is the M3126-LVE suitable for outdoor installations?
Yes. The camera is designed for outdoor environments and is rated IP66, IP67, IK10, and NEMA 4X.
Q: Does the camera provide clear images at night?
Yes. OptimizedIR enables reliable surveillance in complete darkness while Lightfinder improves image quality in low-light conditions.
Q: What field of view does the camera provide?
The 3.1 mm fixed lens offers a wide horizontal field of view of approximately 106°, making it suitable for general surveillance applications.
Q: Does the camera support edge storage?
Yes. The M3126-LVE supports microSD, microSDHC, and microSDXC cards for onboard recording.
Q: What applications is the M3126-LVE best suited for?
It is ideal for schools, retail stores, office buildings, warehouses, parking areas, and perimeter monitoring.
Q: Does the camera include cybersecurity protection?
Yes. Axis Edge Vault provides hardware-based security features that help protect the device and sensitive cryptographic keys.
