| **Camera** |
|
| Image Sensor |
1/2.7” progressive scan RGB CMOS |
| Lens |
3–6 mm, varifocal, F1.9–2.7, remote zoom/focus |
| Field of View |
H: 100°–45°, V: 72°–34° |
| Day/Night |
Automatic IR-cut filter |
| Min. Illumination |
Color: 0.18 lux, B/W: 0.03 lux |
| Shutter Speed |
1/37500 s to 1/5 s |
| Angle Adjustment |
Pan ±180°, Tilt -40° to +65°, Rotation ±105° |
| SoC |
CV25 with DLPU |
| Memory |
1024 MB RAM, 512 MB Flash |
| **Video** |
|
| Compression |
H.264 (Main/High), H.265 (Main/High), Motion JPEG |
| Resolutions |
2304x1728 to 320x240 |
| Frame Rate |
Up to 25/30 fps with 50/60 Hz |
| Streaming |
Multiple streams, Zipstream, VBR/MBR |
| WDR |
Up to 110 dB |
| Image Settings |
Brightness, contrast, sharpness, color, exposure, WDR, overlays, rotation, privacy mask |
| PTZ |
Digital PTZ |
| HDMI Output |
1080p @ 25/30 fps, 720p @ 50/60 fps |
| **Audio** |
|
| Audio Input/Output |
Via optional AXIS T61 Audio & I/O Interface |
| **Network** |
|
| Protocols |
IPv4, IPv6, HTTP, HTTPS, TLS, FTP, SFTP, SNMP, RTSP, RTP, SSH, MQTT, UPnP, ONVIF, etc. |
| Connectors |
RJ45 (10/100 BASE-TX PoE), HDMI type D |
| **System Integration** |
|
| API |
VAPIX, ONVIF (G/M/S/T), ACAP, one-click cloud connect |
| Event Triggers |
Temperature events, network loss, IP change, motion detection, manual trigger, storage alerts |
| Event Actions |
Email, upload, HTTP(S), TCP, SNMP trap, MQTT publish, overlays, video/image buffer |
| Built-in Tools |
Remote zoom, remote focus |
| **Analytics** |
|
| Included |
AXIS Object Analytics, Video Motion Detection, Face Detector, Tampering Alarm |
| Object Detection |
Humans, vehicles (cars, buses, trucks, bikes), up to 10 scenarios |
| Advanced Features |
Bounding boxes, perspective, polygon areas, ONVIF Motion Alarm |
| **Cybersecurity** |
|
| Software Security |
Signed firmware, secure boot, encrypted SD storage, Axis Edge Vault |
| Network Security |
IEEE 802.1X, HTTPS/TLS, secure keystore |
| **General** |
|
| Casing |
IK08, IP42, polycarbonate/aluminum, hard-coated dome |
| Power |
PoE IEEE 802.3af/at Type 1 Class 2, typical 2.8 W, max 4.4 W |
| Storage |
microSD/SDHC/SDXC, SD encryption, NAS support |
| Operating Conditions |
0 °C to 45 °C (32 °F to 113 °F), 10–85% RH |
| Dimensions |
Ø 121 mm × H 71 mm |
| Weight |
350 g (0.77 lb) |
| Languages |
EN, DE, FR, ES, IT, RU, ZH, JA, KO, PT, etc. |
| Warranty |
5-year warranty |
