Axis M4216‑LV 4 MP, Indoor Mini Dome, DLPU & Edge Analytics, Varifocal 3–6 mm Lens, IP42 IK08, 02113‑001

Description

The AXIS M4216-LV is a compact 4 MP indoor dome camera with a varifocal lens, remote zoom/focus, and edge-based deep learning analytics. It delivers clear images in any light with Optimised IR, Lightfinder, and WDR, making it ideal for retail, schools, and public spaces.

Features

  • 4 MP Resolution – High-quality image capture with support for WDR and Lightfinder.
  • Varifocal Lens – 3–6 mm lens with remote zoom and focus for flexible coverage.
  • Deep Learning on the Edge – DLPU supports intelligent analytics such as AXIS Object Analytics.
  • Optimised IR Illumination – Infrared LEDs with a 20m range for night-time surveillance.
  • HDMI Output – Display real-time video feed on public view monitors.
  • Flexible System Integration – Supports VAPIX, ONVIF (G/M/S/T), and AXIS Camera Application Platform.
  • Smart Event Triggers – Motion, tampering, temperature, virtual input, and more.
  • Cybersecurity Features – Axis Edge Vault, signed firmware, secure boot, SD card encryption.

What's Included:

  • AXIS M4216-LV Camera
  • Installation Guide
  • Windows® Decoder 1-user License

DOWNLOADS

Datasheet  AXIS M4216-LV Datasheet
Installation Guide  AXIS M4216-LV Installation Guide
User Manual  AXIS M4216-LV User Manual

Key Info

Compact, Repaintable, and Flexible
The AXIS M4216-LV is designed to blend in with interiors and can be repainted. Its modular design works with a wide range of accessories for discreet and efficient installations.

Deep Learning & Analytics
Supports object detection and classification for humans and vehicles. Analytics features include line crossing, object in area, and time in area.

Public Viewing Ready
Equipped with HDMI output, perfect for customer-facing monitoring setups in retail and business environments.

Built for Secure Integration
Secure boot, Axis Edge Vault, and network authentication ensure data protection and safe device deployment.

Tech Specs

Specification Details
**Camera**
Image Sensor 1/2.7" CMOS, progressive scan
Lens 3–6 mm varifocal, F1.9–2.7, remote zoom/focus
Field of View H: 100°–45°, V: 72°–34°
Day/Night IR-cut filter, 0 lux with IR on
Min. Illumination Color: 0.18 lux, B/W: 0.03 lux
IR Illumination Optimised IR, 20m range
SoC CV25 with DLPU
Memory 1024 MB RAM, 512 MB Flash
**Video**
Compression H.264, H.265, Motion JPEG
Resolution Up to 2304x1728
Frame Rate Up to 25/30 fps
Streaming Multiple streams, Zipstream, HDMI output
WDR Up to 110 dB
Image Settings Brightness, sharpness, privacy mask, rotation, corridor format
PTZ Digital PTZ
**Audio**
Input/Output Via optional AXIS T61 Audio and I/O Interfaces
**Network**
Protocols IPv4/6, HTTPS, TLS, RTSP, MQTT, HDMI, etc.
Connectors RJ45 10/100 BASE-TX PoE, HDMI Type D
**System Integration**
API VAPIX, ONVIF (G/M/S/T), ACAP
Event Triggers Motion, tampering, temperature, schedule, MQTT, HDMI
Event Actions Record, notify, upload, overlay, MQTT publish
**Analytics**
Included AXIS Object Analytics, Face Detector, Motion Detection
Object Detection Humans, vehicles (cars, buses, trucks, bikes)
Advanced Features Bounding boxes, trajectory lines, perspective config
**Cybersecurity**
Software Security Signed firmware, brute force protection, SD encryption
Hardware Security Axis Edge Vault, Secure Boot, TPM
Network Security IEEE 802.1X, TLS 1.2/1.3, HTTPS, IP filtering
**General**
Casing IK08, IP42, aluminum/polycarbonate, hard-coated dome
Power PoE IEEE 802.3af, Max 9.7W
Storage microSD/microSDHC/microSDXC, NAS support
Operating Conditions 0 °C to 45 °C, 10–85% RH
Dimensions H: 71 mm, Ø: 121 mm
Weight 375 g
Languages Multiple incl. EN, DE, FR, ZH, JA, PT
Warranty 5-year warranty

Q&A

Q1: Does the M4216-LV support public viewing monitors?
A: Yes, it features HDMI output for direct connection to a monitor.

Q2: Can this camera classify vehicles and people?
A: Yes, using AXIS Object Analytics processed by the DLPU.

Q3: Is this camera vandal-resistant?
A: Yes, it's IK08-rated and built with a hard-coated dome.

Q4: Does it support audio recording?
A: Audio input/output is supported via optional AXIS T61 accessories.

Q5: Is this suitable for harsh environments?
A: It’s designed for indoor use with IP42 rating, and handles temperatures from 0 °C to 45 °C.

Videos

Read more

Product form

Axis M4216‑LV 4 MP, Indoor Mini Dome, DLPU & Edge Analytics, Varifocal 3–6 mm Lens, IP42 IK08, 02113‑001

SKU: M4216-LV Datasheet
Part Number: 02113-001

🟢 IN STOCK— Delivery in 1–3 days.
