Camera |
|
Image Sensor |
1/2.7” progressive scan RGB CMOS |
Lens |
Varifocal, 3–6 mm, F1.9–2.7 Horizontal FOV: 100°–45° Vertical FOV: 72°–34° Remote focus and zoom, fixed iris |
Day and Night |
Automatic IR-cut filter |
Minimum Illumination |
Lightfinder: Color: 0.18 lux at 50 IRE F2.0 B/W: 0.03 lux at 50 IRE F2.0 |
Shutter Speed |
1/37500 s to 1/5 s |
Camera Adjustment |
Pan ±180° Tilt -40° to +65° Rotation ±105° Can be directed in any direction |
System-on-Chip (SoC) |
Model: CV25 Memory: 1024 MB RAM, 512 MB Flash Compute: Deep Learning Processing Unit (DLPU) |
Video |
|
Compression |
H.264 (Main/High Profiles) H.265 (Main/High Profiles) Motion JPEG |
Resolution |
2304x1728 to 320x240 |
Frame Rate |
Up to 25/30 fps (50/60 Hz power line frequency) |
Streaming |
Multiple configurable streams Axis Zipstream (H.264/H.265) VBR/MBR H.264/H.265 Low latency mode HDMI supported |
Multi-View Streaming |
Up to 2 cropped view areas in full frame rate |
HDMI Output |
1080p (16:9) @25/30 Hz 720p (16:9) @50/60 Hz |
Image Settings |
Compression, color, brightness, sharpness, contrast White balance, exposure control WDR up to 110 dB Text/image overlay, privacy mask Rotation: 0°, 90°, 180°, 270° including Corridor Format |
Pan/Tilt/Zoom |
Digital PTZ |
Audio |
|
Audio I/O |
Two-way audio via portcast technology Voice enhancer |
Network |
|
Network Protocols |
IPv4, IPv6 USGv6, HTTP, HTTPS, TLS, FTP, SFTP, CIFS/SMB, SMTP, mDNS, UPnP, SNMP, DNS, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, DHCP, ARP, SSH, LLDP, CDP, MQTT v3.1.1, ZeroConf |
System Integration |
|
API & Compatibility |
Open API (VAPIX®), AXIS Camera Application Platform ONVIF® Profiles G, M, S, T One-click cloud connect SIP support for VoIP and PBX |
VMS Compatibility |
AXIS Camera Station (Edge, Pro, v5) Axis partner VMS |
Event Triggers |
Device status, edge storage, I/O via AXIS T61, MQTT subscribe, scheduled/recurring events, live stream open |
Event Actions |
MQTT publish, email, HTTP(S), TCP, SNMP trap Overlay text, zoom preset, day/night switch Pre/post alarm video/image Record/upload to SD/NAS/FTP/email External output via AXIS T61 |
Installation Aids |
Remote zoom and focus |
Analytics |
|
Included Applications |
AXIS Live Privacy Shield AXIS Object Analytics AXIS Scene Metadata AXIS Video Motion Detection AXIS Face Detector |
Supported Apps |
AXIS People Counter, AXIS Queue Monitor, 3rd-party apps via ACAP |
AXIS Object Analytics |
Detects humans, vehicles (cars, buses, trucks, bikes) Scenarios: line crossing, object in area, occupancy/time in area Up to 10 scenarios Color-coded bounding boxes Polygon zones, perspective setup ONVIF Motion Alarm |
AXIS Scene Metadata |
Detects humans, faces, vehicles, license plates Attributes: vehicle color, clothing color, confidence, position |
Approvals |
|
EMC |
EN 55032 Class A, EN 55035, EN 61000-6-x, RCM, ICES-3, VCCI, KN32/35, FCC Part 15 |
Safety |
IEC/EN/UL 62368-1, CSA C22.2 No. 62368-1 |
Environment |
IEC 60068 series, IP42, IK08 |
Network |
NIST SP500-267 |
Cybersecurity |
ETSI EN 303 645, BSI IT Security Label |
Cybersecurity |
|
Edge Security |
Signed OS, brute force protection, digest auth, OAuth 2.0, AES-XTS-Plain64 SD encryption Axis Edge Vault, secure boot, secure keystore, signed video |
Network Security |
IEEE 802.1X, 802.1AE, 802.1AR HTTPS/HSTS, TLS v1.2/v1.3 NTS, X.509 PKI, firewall |
General |
|
Casing |
IP42 water/dust resistant IK08 impact-resistant Polycarbonate & aluminum Color: white NCS S 1002-B |
Sustainability |
PVC/BFR/CFR free 43% recycled plastics |
Power |
PoE IEEE 802.3af/802.3at Type 1 Class 2 Typical: 2.8 W Max: 4.4 W |
Connectors |
RJ45 10/100BASE-TX PoE HDMI type D Audio via portcast |
Storage |
microSD/microSDHC/microSDXC SD encryption supported NAS supported |
Operating Conditions |
0 °C to 45 °C (32 °F to 113 °F) Humidity: 10–85% RH (non-condensing) |
Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F) Humidity: 5–95% RH (non-condensing) |
Dimensions |
Height: 71 mm (2.8 in) Diameter: 121 mm (4.76 in) |
Weight |
350 g (0.77 lb) |
