Designed for demanding indoor or outdoor environments, the Axis M4227-LVE delivers full 360° situational awareness in crisp 5MP detail. Its rugged, vandal-resistant build and discreet dome profile make it a reliable choice for schools, offices, public buildings, and retail spaces. With built-in infrared (IR) night vision and advanced analytics support, this camera helps you secure large open areas without blind spots — day or night.
Features
-
360° Panoramic Coverage – See everything in all directions from a single camera, ideal for open-plan areas.
-
Built-In IR Illumination – Delivers clear monochrome footage in total darkness up to 15 meters.
-
Vandal-Resistant IK10 Housing – Withstands impacts and tampering in high-risk or public environments.
-
Outdoor-Ready Design – IP42-rated for protection against dust, rain, and humidity, perfect for entrances or covered outdoor areas.
-
Fixed 1.27mm Panoramic Lens – Ultra-wide-angle lens captures a full room with no need for mechanical movement.
-
Compact and Low-Profile – Blends into ceilings and walls discreetly in schools, offices, and retail settings.
-
Advanced Video Compression – Axis Zipstream with H.264/H.265 reduces storage and bandwidth without compromising quality.
-
Flexible Deployment – Mounts on walls or ceilings, works standalone or integrated with existing surveillance systems.
-
Edge Storage Support – Built-in microSD slot enables local video storage for redundancy or standalone use.
Downloads
Extra Info
360° Panoramic Monitoring
The Axis M4227-LVE uses a fixed panoramic lens with a 6MP image sensor to give complete 360° situational awareness. This allows you to monitor an entire room or open area with just one camera, reducing blind spots and lowering system costs by replacing multiple cameras.
Reliable Night Surveillance
With integrated infrared (IR) LEDs and an illumination range of up to 15 meters, this camera provides clear images even in pitch-black environments. Whether it’s a warehouse at night or a school hallway after hours, you can count on dependable coverage.
Durable Outdoor and Vandal Protection
Built for exposed locations, the M4227-LVE features an IK10 vandal-resistance rating and an IP42 enclosure. This protects against both physical impact and challenging weather conditions like humidity or light rain — making it a solid pick for entrances, garages, and public transit stations.
Efficient Bandwidth Management
Axis Zipstream technology ensures high-quality video while conserving bandwidth and storage. This is ideal for installations where network or storage resources are limited, especially with continuous recording needs.
Flexible Installation
Compatible with wall and ceiling mounts, the compact design makes it easy to deploy in discreet locations without drawing attention. It’s also compatible with major video management systems (VMS) and supports edge storage for backup.
Tech Specs
| Camera Image Sensor |
1/1.8" Progressive Scan RGB CMOS |
| Min. Illumination |
Color: 0.18 lux at 50 IRE
BW: 0.03 lux at 50 IRE
0 lux with IR illumination on |
| IR Illumination |
Built-in IR LEDs
Range: Up to 15 m (49 ft)
OptimizedIR |
| Lens |
Fixed lens, 1.27 mm
Horizontal FOV: 180°
Vertical FOV: 180°
Diagonal FOV: 180° |
| Shutter Speed |
1/28000 s to 1/5 s |
| Camera Angle Adjustment |
Rotation: ±100° |
| Video Compression |
H.264 (Main Profile)
H.265 (Main Profile)
Motion JPEG |
| Resolution |
2016x2016 (4 MP)
1792x1792
1280x1280
960x960 |
| Frame Rate |
Up to 30 fps in all resolutions |
| Video Streaming |
Multiple configurable streams
Axis Zipstream technology in H.264 and H.265 |
| Panoramic Views |
360° overview
Double panorama
Quad view
View area |
| Day/Night Functionality |
Automatically removable IR-cut filter |
| Wide Dynamic Range |
WDR: Forensic Capture |
| Image Settings |
Compression, color, brightness, sharpness, contrast, local contrast, white balance
Day/night threshold, exposure control, exposure zones
Text/image overlay, privacy masks, mirroring, rotation |
| Edge Storage |
MicroSD/microSDHC/microSDXC slot
Support for recording to network-attached storage (NAS) |
| Operating Conditions |
-30 °C to 50 °C (-22 °F to 122 °F)
Humidity: 10–100% RH (condensing) |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F) |
| Casing |
Polycarbonate casing with aluminum back
Polycarbonate clear dome
Color: White NCS S 1002-B
Vandal-resistant IK10, IP42-rated |
| Dimensions |
Height: 57 mm (2.2 in)
Diameter: 149 mm (5.9 in) |
| Weight |
0.56 kg (1.2 lb) |
| Power |
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 |
| Power Consumption |
Typical: 5.4 W
Maximum: 8.2 W |
| Security |
Signed firmware
Secure boot
HTTPS encryption
IEEE 802.1X network access control
User access log |
| Included Accessories |
Installation guide, Windows decoder, drill hole template, connector guard |
| Optional Accessories |
AXIS T94B01P Conduit Back Box
AXIS T91A23 Tile Grid Ceiling Mount
AXIS TP3701-E and TP3702-E Dome Covers
For full list, see axis.com |
| Compliance |
EMC: EN 55032 Class A, EN 55035, FCC Part 15 Subpart B Class A
Safety: IEC/EN/UL 62368-1
Environment: IEC 60068-2-1, 2-2, 2-14, 2-30
Vibration, Impact, Temperature, Humidity tested |
| Warranty |
5-year Axis Limited Hardware Warranty |
Q&A
Q: Can this camera see in complete darkness?
A: Yes, it has built-in infrared (IR) illumination with a range of up to 15 meters for clear night-time imaging.
Q: Is this camera suitable for outdoor use?
A: Yes, the camera is IP42-rated and designed for covered outdoor spaces like entrances, hallways, or porches. It is also vandal-resistant (IK10), making it suitable for high-traffic public areas.
Q: Can it replace multiple cameras in a large room?
A: Absolutely. Its 360° panoramic lens can monitor an entire open space from a single point, reducing the need for multiple units.
Q: Does it support local video recording?
A: Yes, it has a built-in microSD card slot for edge storage, which can be used for local backup or standalone operation.
Q: What video management systems is it compatible with?
A: The Axis M4227-LVE supports ONVIF and is compatible with most major VMS platforms for easy integration.
