| **Camera** |
|
| Image Sensor |
1/2.8” progressive scan RGB CMOS |
| Lens |
CS-mount, IR-corrected P-Iris lensVarifocal 2.8–8 mm, F1.3 |
| Field of View |
Horizontal: 112°–39°Vertical: 58°–21° |
| Day/Night |
IR-cut filter, automatically removable |
| Minimum Illumination |
Color: 0.11 lux, B/W: 0.01 lux (at 50 IRE, F1.3)At 50/60 fps: Color 0.22 lux, B/W 0.02 lux |
| Shutter Speed |
1/66500 s to 2 s |
| SoC |
ARTPEC series |
| Memory |
512 MB RAM, 256 MB Flash |
| **Video** |
|
| Compression |
H.264 (Baseline/Main/High), Motion JPEG |
| Resolutions |
HDTV 1080p (1920×1080 to 160×90) |
| Frame Rate |
Up to 50/60 fps (without WDR), 25/30 fps (with WDR) |
| Streaming |
Multiple configurable streams, Axis Zipstream in H.264VBR/ABR/MBR support |
| Multi-View Streaming |
Up to 8 individually cropped view areas |
| WDR |
Forensic WDR up to 120 dB |
| Image Settings |
Compression, brightness, contrast, sharpness, white balance, exposure zones, rotation (Corridor Format), dynamic overlay, privacy masks |
| PTZ |
Digital PTZ, uploadable PTZ drivers (Pelco D pre-installed) |
| **Audio** |
|
| Audio Streaming |
Two-way, full duplex |
| Audio Encoding |
LPCM, AAC-LC, G.711, G.726, Opus (8/16/32/48 kHz) |
| Audio I/O |
3.5 mm mic/line-in, 3.5 mm line-out, built-in microphone (can be disabled) |
| **Network** |
|
| Protocols |
IPv4/6, HTTP/2, HTTPS, SSL/TLS, FTP, SFTP, CIFS/SMB, SNMP v1/2c/3, RTSP, RTP, SRTP, IGMP, MQTT, LLDP, mDNS, NTP, DHCP, DNS, ARP, TCP, UDP, SSH |
| Security |
HTTPS encryption, IEEE 802.1X, digest auth, password protection, signed firmware, brute-force delay, access logs |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE, terminal blocks for I/O, RS485/RS422, mic in, line out, DC power, P-Iris |
| **System Integration** |
|
| API |
VAPIX, ACAP, ONVIF (G/S/T), AXIS Video Hosting System (One-Click) |
| Event Triggers |
Motion, tampering, audio detection, edge storage, schedule, external input |
| Event Actions |
Recording, email, TCP/HTTP notifications, FTP/SFTP upload, overlay text, PTZ actions, audio clip playback |
| Built-In Tools |
Focus assistant, remote back focus, pixel counter |
| **Analytics** |
|
| Included |
AXIS Video Motion Detection, tampering alarm, audio detection |
| Supported |
AXIS Guard Suite (Motion/Fence/Loitering Guard), AXIS Perimeter Defender, AXIS Digital Autotracking, ACAP for third-party apps |
| **Cybersecurity** |
|
| Software Security |
Signed firmware, brute force protection, digest authentication, password protection |
| Storage Security |
SD card encryption (AES-XTS-Plain64 256bit) |
| **General** |
|
| Casing |
Metal (zinc), white NCS S 1002-BTripod screw mount, included stand |
| Power |
8–28 V DC (max 7.3 W), PoE IEEE 802.3af/at (max 6.8 W) |
| Storage |
microSD/microSDHC/microSDXC with encryptionNAS recording supported |
| Operating Conditions |
0 °C to 55 °C (32 °F to 131 °F), 10–85% RH (non-condensing) |
| Storage Conditions |
–40 °C to 65 °C (–40 °F to 149 °F), 5–95% RH |
| Dimensions |
205 × 78 × 46 mm (8.1 × 3.1 × 1.8 in) |
| Weight |
630 g (1.4 lb) |
| Languages |
EN, DE, FR, ES, IT, RU, ZH (Simplified/Traditional), JA, KO, PT, PL |
| Warranty |
3-year warranty (extendable) |
