Specification
|
Details
|
|
**Camera**
|
|
|
Image sensor
|
1/2.8” progressive scan RGB CMOS
|
|
Lens
|
Varifocal, 3.4–8.9 mm, F1.8
Horizontal field of view: 100°-36°
Vertical field of view: 53°-20°
Remote zoom and focus, P-Iris control, IR corrected
|
|
Day and night
|
Automatically removable infrared-cut filter
|
|
Minimum illumination
|
With Forensic WDR and Lightfinder 2.0:
Color: 0.1 lux at 50 IRE, F1.8
B/W: 0.02 lux at 50 IRE, F1.8; 0 lux with IR illumination on
|
|
Shutter speed
|
1/66500 s to 2 s
|
|
Camera angle adjustment
|
Pan ±180°, tilt ±75°, rotation ±175°
|
|
System on chip (SoC)
|
ARTPEC-7
|
|
Memory
|
2048 MB RAM, 1024 MB Flash
|
|
Compute capabilities
|
Deep learning processing unit (DLPU)
|
|
**Video**
|
|
|
Video compression
|
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC) Main Profile
Motion JPEG
|
|
Resolution
|
1920x1080 to 160x90
|
|
Frame rate
|
With WDR: 25/30 fps with power line frequency 50/60 Hz
Without WDR: 50/60 fps with power line frequency 50/60 Hz
|
|
Video streaming
|
Multiple, individually configurable streams in H.264, H.265, and Motion JPEG
Axis Zipstream technology for H.264 and H.265
Controllable frame rate and bandwidth
VBR/ABR/MBR H.264/H.265
Low latency mode
|
|
Multi-view streaming
|
Up to 2 individually cropped out view areas in full frame rate
|
|
Image settings
|
Compression, color saturation, brightness, sharpness, contrast, local contrast, white balance, day/night threshold, tone mapping, exposure control (including automatic gain control), exposure zones, defogging, Forensic WDR: up to 120 dB depending on scene, barrel distortion correction, fine tuning of low-light behavior, dynamic text and image overlay, privacy masks, mirroring, rotation: 0°, 90°, 180°, 270°, including Corridor Format
|
|
Pan/Tilt/Zoom
|
Digital PTZ, preset positions
|
|
**Audio**
|
|
|
Audio streaming
|
Full duplex
|
|
Audio encoding
|
24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz
Configurable bit rate
|
|
Audio input/output
|
External microphone input, line input, digital input with ring power, line output, automatic gain control
Two-way audio connectivity via optional AXIS T61 Audio and I/O Interfaces with portcast technology
|
|
**Network**
|
|
|
Security
|
IP address filtering, HTTPS encryption, IEEE 802.1X (EAP-TLS) network access control, user access log, centralized certificate management, signed video, Axis Edge Vault, Axis device ID
|
|
Network protocols
|
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SSH, SIP, LLDP, CDP, MQTT, Syslog, Link-Local address (ZeroConf)
|
|
**System integration**
|
|
|
API
|
Open API for software integration, including VAPIX, metadata, and AXIS Camera Application Platform (ACAP); specifications at axis.com/developer-community. ACAP includes Native SDK and Computer Vision SDK.
One-click cloud connection
|
|
ONVIF
|
ONVIF Profile G, M, S, T
|
|
SIP
|
Support for Session Initiation Protocol (SIP) for integration with VoIP systems
|
|
**Analytics**
|
|
|
Included analytics
|
AXIS Object Analytics, AXIS Video Motion Detection, active tampering alarm, audio detection
|
|
Detection capabilities
|
Object classes: humans, vehicles (cars, buses, trucks, bikes), license plates
Trigger conditions: line crossing, object in area, time in area (BETA)
|
|
Event actions
|
Video recording, image upload, buffering, notifications, overlays, audio clip playback, external output activation, make call
|
|
**General**
|
|
|
Casing
|
IK10, IP66 and NEMA 4X rated polycarbonate with hard-coated dome and dehumidifying membrane
|
|
Mounting
|
Bracket with holes for junction box and wall or ceiling mount, ¼”-20 UNC tripod screw thread
|
|
Power
|
PoE IEEE 802.3at Type 2 Class 4, Typical 7.8 W, max 14.6 W
|
|
Connectors
|
RJ45, I/O: 4-pin terminal block, Audio: 4-pin terminal block
|
|
IR illumination
|
Optimised IR, 850 nm IR LEDs, 40 m range depending on scene
|
|
Storage
|
microSD/microSDHC/microSDXC with encryption, NAS supported
|
|
Operating conditions
|
-40 °C to 50 °C, Max 55 °C intermittent, NEMA TS 2 up to 74 °C, Humidity 10–100% RH
|
|
Storage conditions
|
-40 °C to 65 °C, Humidity 5–95% RH (non-condensing)
|
|
Dimensions
|
Without weathershield: Height: 104 mm, Ø 149 mm
|
|
Weight
|
With weathershield: 800 g
|
|
Included accessories
|
Installation guide, Windows decoder license, drill template, Resistorx T20 L-key, terminal blocks, cable gaskets, connector guard, weathershield
|
|
Optional accessories
|
Mounts, recessed kits, smoked dome, black casing, audio interfaces
|
|
Video management software
|
AXIS Companion, AXIS Camera Station, and others from Axis partners
|
|
Languages
|
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese
|
|
Warranty
|
5-year warranty
|
