| Specification |
Details |
| **Camera** |
|
| Image Sensor |
1/2.8” progressive scan RGB CMOS |
| Lens |
3.4–8.9 mm varifocal, remote zoom/focus, IR corrected, P-Iris control |
| Field of View |
H: 100°–36°, V: 53°–20° |
| Day/Night |
Automatic IR-cut filter |
| Min. Illumination |
Color: 0.1 lux / B&W: 0 lux (with IR) |
| IR Illumination |
OptimizedIR, range up to 40 m |
| Shutter Speed |
1/66500 s to 2 s |
| Angle Adjustment |
Pan: ±180°, Tilt: ±75°, Rotation: ±175° |
| SoC |
ARTPEC-8 |
| Memory |
1024 MB RAM, 8192 MB Flash |
| **Video** |
|
| Compression |
H.264 (Baseline/Main/High), H.265 (Main), Motion JPEG |
| Resolutions |
Up to 1920x1080 |
| Frame Rate |
Up to 60 fps (no WDR), up to 30 fps (with WDR) |
| Streaming |
Multiple configurable streams, Zipstream (H.264/H.265) |
| WDR |
Forensic WDR: Up to 120 dB |
| Image Settings |
Contrast, brightness, sharpness, tone mapping, privacy mask, etc. |
| PTZ |
Digital PTZ, preset positions |
| **Audio** |
|
| Audio Input/Output |
External mic input, line in/out, digital input/output |
| Audio Streaming |
Two-way, full duplex, supports AAC, G.711, G.726, Opus |
| **Network** |
|
| Protocols |
IPv4/6, HTTP/2, HTTPS, TLS, FTP, SFTP, SNMP, RTSP, MQTT, SIP, etc. |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE, Terminal block for audio and I/O |
| **System Integration** |
|
| API |
VAPIX, ONVIF (G/M/S/T), ACAP, SIP, cloud connection |
| Event Triggers |
System status, I/O, motion, audio, schedule, tampering, MQTT |
| Event Actions |
Record, upload, email, overlays, MQTT publish, SIP call |
| Built-in Tools |
Remote zoom/focus, pixel counter, level grid |
| **Analytics** |
|
| Included |
AXIS Object Analytics, Motion Detection, Tampering Alarm |
| Object Detection |
Humans, vehicles (cars, buses, trucks, bikes), up to 10 scenarios |
| Advanced Features |
Bounding boxes, trajectory tracking, metadata overlays, ONVIF alerts |
| **Cybersecurity** |
|
| Software Security |
Signed firmware, password protection, SD card encryption |
| Hardware Security |
Secure boot, Axis Edge Vault, secure keystore |
| Network Security |
IEEE 802.1X, HTTPS/HSTS, TLS 1.2/1.3, NTS, firewall |
| **General** |
|
| Casing |
IK10-rated, IP52, polycarbonate dome and casing |
| Power |
PoE IEEE 802.3af/at Type 1 Class 3, typical: 4.8 W, max: 8.9 W |
| Storage |
microSD/microSDHC/microSDXC with AES encryption, NAS supported |
| Operating Conditions |
0 °C to 50 °C, 10–85% RH (non-condensing) |
| Dimensions |
Ø 149 mm × H 103 mm |
| Weight |
650 g |
| Languages |
EN, DE, FR, ES, IT, RU, ZH, JA, KO, PT, PL, etc. |
| Warranty |
5-year warranty |
