| Specification |
Details |
| **Camera** |
|
| Image sensor |
1/2.8” progressive scan RGB CMOS |
| Lens |
Varifocal, 3.4–8.9 mm, F1.8 Horizontal field of view: 100°–36° Vertical field of view: 53°–20° Remote zoom and focus, P-Iris control, IR corrected
|
| Day and night |
Automatically removable infrared-cut filter |
| Minimum illumination |
With Lightfinder 2.0: Color: 0.1 lux at 50 IRE, F1.8 B/W: 0.02 lux at 50 IRE, F1.8 0 lux with IR illumination on
|
| Shutter speed |
1/66500 s to 2 s |
| Camera angle adjustment |
Pan ±180°, tilt +75°, rotation ±175° |
| System on chip (SoC) |
ARTPEC-8 |
| Memory |
1024 MB RAM, 8192 MB Flash |
| Compute capabilities |
Deep learning processing unit (DLPU) |
| **Video** |
|
| Video compression |
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG
|
| Resolution |
1920x1080 to 160x90 (16:9) |
| Frame rate |
With WDR: 25/30 fps (60/50 Hz) Without WDR: 50/60 fps (60/50 Hz)
|
| Video streaming |
Up to 20 unique and configurable video streams Axis Zipstream in H.264/H.265 Controllable frame rate and bandwidth VBR/ABR/MBR Low latency mode
|
| Multi-view streaming |
Up to 2 cropped view areas |
| Image settings |
Saturation, contrast, brightness, sharpness, white balance, day/night threshold, tone mapping, exposure zones, defogging, compression, rotation (0°, 180°), overlays, privacy masks |
| Pan/Tilt/Zoom |
Digital PTZ, preset positions |
| **Audio** |
|
| Audio streaming |
Two-way (full/half duplex) |
| Audio encoding |
24bit LPCM, AAC-LC 8/16/32/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz |
| Audio input/output |
Mic input (with 5 V power), line in/out, digital in/out with ring power, AGC |
| **Network** |
|
| Security |
Axis Edge Vault, signed firmware/OS/video, secure boot, AES-encrypted SD IEEE 802.1X (EAP-TLS), HTTPS, TLS v1.2/1.3, NTS, IP filtering
|
| Protocols |
IPv4/v6, HTTP/HTTPS, FTP/SFTP, CIFS/SMB, SMTP, mDNS, UPnP, SNMP, DDNS, NTP, RTSP/RTP, SRTP, TCP/UDP, IGMP, SSH, SIP, MQTT, syslog, IEEE 802.1AR |
| **System Integration** |
|
| API |
Open API, VAPIX, ACAP (Native & CV SDK), ONVIF (Profiles G, M, S, T), SIP, cloud connect |
| **Analytics** |
|
| Included analytics |
AXIS License Plate Verifier, Scene Metadata, Video Motion Detection, Audio Detection, Tampering |
| Detection capabilities |
Vehicle types, license plates, object location and attributes |
| Event actions |
Recording, notifications, I/O trigger, light/audio control, overlays |
| **General** |
|
| Casing |
IK10, IP66, NEMA 4X-rated polycarbonate dome |
| Mounting |
Bracket with junction box holes, ¼”-20 UNC tripod thread |
| Power |
PoE IEEE 802.3af/802.3at Type 1 Class 3 Typical: 4.8 W, Max: 10.7 W
|
| Connectors |
RJ45 (network), 4-pin terminal (I/O), 4-pin terminal (audio) |
| IR illumination |
Optimised IR, 850 nm LEDs, range up to 40 m |
| Storage |
microSD/microSDHC/microSDXC with encryption, NAS supported |
| Operating conditions |
-40 °C to 50 °C Max: 74 °C (NEMA TS 2) Humidity: 10–100% RH
|
| Storage conditions |
-40 °C to 65 °C Humidity: 5–95% RH
|
| Dimensions |
Without weathershield: Height 104 mm, Ø 149 mm |
| Weight |
With weathershield: 800 g |
| Included accessories |
Camera, weathershield, drill template, install guide, Resistorx tool, cable gaskets, connectors, license key |
| Optional accessories |
Recessed/pedant mounts, digital mic, surveillance cards |
| Video management software |
AXIS Companion, AXIS Camera Station, and partner VMS |
| Languages |
English, German, French, Spanish, Italian, Russian, Chinese (Simplified & Traditional), Japanese, Korean, Portuguese, Polish |
| Warranty |
5-year Axis warranty |
