Specification |
Details |
**Camera** |
|
Image Sensor |
1/2.8" progressive scan RGB CMOS |
Lens |
3.4–8.9 mm varifocal, remote zoom/focus, IR corrected, P-Iris control |
Field of View |
H: 100°–36°, V: 53°–20° |
Day/Night |
Automatic IR-cut filter |
Min. Illumination |
Color: 0.1 lux / B&W: 0.02 lux |
Shutter Speed |
1/66500 s to 2 s |
Angle Adjustment |
Pan ±180°, tilt ±75°, rotation ±175° |
SoC |
ARTPEC-8 |
Memory |
1024 MB RAM, 8192 MB Flash |
**Video** |
|
Compression |
H.264, H.265, Motion JPEG with Zipstream |
Resolution |
1920x1080 to 160x90 |
Frame Rate |
Up to 60 fps (no WDR), 30 fps (with WDR) |
WDR |
Forensic WDR: up to 120 dB |
Image Settings |
Saturation, contrast, sharpness, rotation, privacy masks, tone mapping |
PTZ |
Digital PTZ, preset positions |
**Audio** |
|
Audio Input/Output |
Mic in, line in, line out, full duplex, AGC support |
Audio Encoding |
LPCM, AAC-LC, G.711, G.726, Opus |
**Network** |
|
Protocols |
IPv4/6, HTTP/HTTPS, TLS, FTP, RTSP, MQTT, SNMP, SIP, etc. |
Connectors |
RJ45 10BASE-T/100BASE-TX PoE, Terminal block for I/O and audio |
**System Integration** |
|
API |
VAPIX, ONVIF (G/M/S/T), ACAP, SIP, cloud connection |
Event Triggers |
Motion, audio, input, schedule, tampering, edge storage |
Event Actions |
Notifications, overlays, LED, MQTT publish, recording |
Built-in Tools |
Remote zoom/focus, pixel counter, level grid |
**Analytics** |
|
Included |
AXIS Object Analytics, Motion Detection, Tampering Alarm |
Object Detection |
Humans, vehicles (cars, buses, trucks, bikes), up to 10 scenarios |
Advanced Features |
Bounding boxes, trajectories, metadata, ONVIF Motion Alarm |
**Cybersecurity** |
|
Software Security |
Signed OS, digest auth, AES SD encryption, brute force delay |
Hardware Security |
Edge Vault, secure boot, signed firmware, secure keystore |
Network Security |
IEEE 802.1X, HTTPS/HSTS, TLS 1.2/1.3, X.509 PKI |
**General** |
|
Casing |
IP52-, IK10-rated, white polycarbonate dome |
Power |
PoE IEEE 802.3af/at Type 1 Class 2, typical: 3W, max: 5.1W |
Storage |
microSD/microSDHC/microSDXC with encryption, NAS support |
Operating Conditions |
0 °C to 50 °C, 10–85% RH |
Dimensions |
Ø 149 mm × H 103 mm |
Weight |
650 g |
Languages |
EN, DE, FR, ES, IT, RU, ZH (Simplified), JA, KO, PT, PL, TR, etc. |
Warranty |
5-year warranty |
