| **Camera** |
|
| Image Sensor |
1/1.8” progressive scan RGB CMOS |
| Lens |
Varifocal 4.3–8.6 mm, F1.5, IR corrected, remote zoom and focus, P-Iris control |
| Field of View |
Horizontal: 100°–53°, Vertical: 54°–30° |
| Day/Night |
Automatically removable IR-cut filter |
| Minimum Illumination |
Color: 0.14 lux at 50 IRE, F1.5B/W: 0 lux at 50 IRE, F1.5 |
| IR Illumination |
Optimised IR, range up to 40 m (130 ft) |
| Shutter Speed |
1/8500 s to 1/5 s |
| Angle Adjustment |
Pan ±190°, Tilt -10° to +80°, Rotation ±190° |
| System on Chip (SoC) |
ARTPEC-8 |
| Memory |
2048 MB RAM, 8192 MB Flash |
| Compute Capabilities |
Deep Learning Processing Unit (DLPU) |
| **Video** |
|
| Compression |
H.264 (Baseline/Main/High), H.265 (Main), Motion JPEG |
| Resolutions |
3840x2160 to 160x90 |
| Frame Rate |
25/30 fps with 50/60 Hz power line frequency |
| Streaming |
Multiple configurable streams in H.264/H.265/MJPEG, Zipstream, VBR/ABR/MBR |
| WDR |
Forensic WDR, up to 120 dB (scene dependent) |
| Image Settings |
Saturation, contrast, brightness, sharpness, white balance, exposure control, tone mapping, defogging, mirroring, overlays, privacy masks, Corridor Format, polygon masks |
| Multi-view Streaming |
Up to 2 cropped-out view areas in full frame rate |
| PTZ |
Digital PTZ, preset positions |
| **Audio** |
|
| Audio Streaming |
Simplex, two-way audio via edge-to-edge technology |
| Audio Encoding |
LPCM, AAC-LC, G.711, G.726, Opus (8/16/48 kHz) |
| Audio Input/Output |
3.5 mm mic/line-in, external mic input, digital input with ring power, AGC, network speaker pairing |
| **Network** |
|
| Protocols |
IPv4/6, HTTP/2, HTTPS, TLS, FTP, SFTP, RTSP, RTP, SRTP, SNMP, MQTT, SIP, ICMP, UPnP, LLDP, SSH, NTP, mDNS, etc. |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE, 4-pin terminal block (1 digital input/output), 3.5 mm audio jack |
| **System Integration** |
|
| API |
VAPIX, AXIS Camera Application Platform (ACAP), ONVIF (G/M/S/T), SIP |
| Event Triggers |
Analytics, motion detection, tampering, audio detection, input/output, manual trigger, schedule, system status, MQTT |
| Event Actions |
Record/upload to SD/NAS, HTTP/S/email, overlay text, toggle I/O, MQTT publish, SIP calls |
| **Analytics** |
|
| Included |
AXIS Object Analytics, Motion Detection, Audio Detection, Tampering Alarm |
| Object Detection |
Humans, vehicles (cars, buses, trucks, bikes), up to 10 scenarios |
| Advanced Features |
Bounding boxes, polygon areas, ONVIF Motion Alarm, WDR/defog mode toggle |
| **Cybersecurity** |
|
| Software Security |
Signed firmware, secure boot, password protection, SD card encryption, Axis Edge Vault |
| Hardware Security |
TPM 2.0, secure keystore (CC EAL4 certified) |
| Network Security |
IEEE 802.1X, HTTPS/TLS 1.2/1.3, MACsec, brute-force protection, centralized certificate management |
| **General** |
|
| Casing |
IP66-, IK10-, NEMA 4X-rated, polycarbonate dome and casing |
| Power |
PoE IEEE 802.3af/at Type 1 Class 3Typical: 5.5 W, Max: 11.2 W |
| Storage |
microSD/microSDHC/microSDXC with AES-XTS 256-bit encryption, NAS support |
| Operating Conditions |
-40 °C to 50 °C (-40 °F to 122 °F), startup at -30 °C, 10–100% RH (condensing) |
| Dimensions |
Ø 149 mm × H 107 mm (with weathershield) |
| Weight |
900 g (2.0 lb) |
| Languages |
EN, DE, FR, ES, IT, RU, ZH (Simplified/Traditional), JA, KO, PT, PL, NL |
| Warranty |
5-year warranty |
