| **Camera** |
|
| Image Sensor |
3 x 5 MP 1/2.8” progressive scan RGB CMOS |
| Lens |
Fixed 3.2 mm, F2.0 |
| Field of View |
Horizontal: 180° / Vertical: 90° |
| Day and Night |
Automatically removable infrared-cut filter |
| Min. Illumination |
Color: 0.16 lux, F2.0 / B/W: 0.05 lux, F2.0 |
| Shutter Speed |
1/91000 to 1/25 s (WDR: 1/50000 to 1/25 s) |
| Camera Angle Adjustment |
Pan: ±180° / Tilt: 0° to 50° / Roll: ±5° |
| SoC |
Dual ARTPEC-7 |
| Memory |
2048 MB RAM (x2), 512 MB Flash |
| Compute Capabilities |
Machine Learning Processing Unit (MLPU) |
| **Video** |
|
| Compression |
H.264 (Baseline, Main, High), H.265 (Main), Motion JPEG |
| Resolution |
5120x2560 (13.1 MP) to 608x128 |
| Frame Rate |
13.1 MP @ 25/30 fps (50/60 Hz) with WDR |
| Streaming |
1 configurable stream in H.264, H.265, and Motion JPEG at full frame rate |
| Image Settings |
Saturation, contrast, brightness, sharpness, WDR (up to 120 dB), white balance, overlays, privacy masks, compression, orientation aid, etc. |
| **Audio** |
|
| Audio Streaming |
Two-way via edge-to-edge technology |
| Audio I/O |
External mic input, line input, digital audio input, auto gain control, network speaker pairing |
| Audio Encoding |
LPCM, AAC-LC (up to 48 kHz), G.711, G.726, Opus |
| **Network** |
|
| Security |
Password protection, HTTPS encryption, IEEE 802.1X, signed firmware, digest auth, Axis Edge Vault, TPM 2.0 |
| Protocols |
IPv4/6, HTTP/HTTPS, TLS, FTP/SFTP, CIFS/SMB, RTSP, RTP, SNMP, SSH, LLDP, CDP, MQTT, ICMP, DHCP, ARP, Syslog, mDNS, NTP, etc. |
| **System Integration** |
|
| API |
Open API (VAPIX), ONVIF Profiles G/S/T, AXIS ACAP |
| Event Triggers |
Analytics, I/O input, audio detection, device status, tampering, casing open, shock, edge storage events |
| Event Actions |
Video recording, buffering, text overlays, audio playback, SNMP traps, I/O events, file uploads, MQTT publish |
| Built-in Tools |
Pixel counter, leveling guide |
| **Analytics** |
|
| Included |
AXIS Fence Guard, Motion Guard, Loitering Guard, Video Motion Detection, Audio Detection, Advanced Gatekeeper |
| ACAP Support |
Yes – Supports third-party applications |
| **Cybersecurity** |
|
| Software Security |
Signed OS, password protection, brute force delay, digest auth |
| Hardware Security |
TPM 2.0, encrypted file system |
| Network Security |
IEEE 802.1X, HTTPS, TLS 1.2/1.3, PKI certificates, NTS, host-based firewall |
| **General** |
|
| Casing |
IP66/IP67, IK10, NEMA 4X-rated; hard-coated clear dome, aluminum base, dehumidifying membrane |
| Mounting |
Junction box bracket included; compatible with ¾" (M25) conduit entries |
| Power |
PoE IEEE 802.3at Type 2 Class 4; Typical: 11W, Max: 18W |
| Connectors |
Shielded RJ45, terminal block for I/O (12V DC out, max 50mA), 3.5mm mic/line in |
| Storage |
microSD/SDHC/SDXC with encryption, NAS support |
| Operating Conditions |
-40 °C to 50 °C; 10–100% RH (condensing); up to 74 °C (NEMA TS 2), start-up: -40 °C |
| Dimensions |
Ø 195 mm x 170 mm; With weathershield: Ø 206 mm x 221 mm |
| Weight |
2.2 kg (4.9 lb) |
| Languages |
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese |
| Warranty |
5-year warranty |
