Get complete situational awareness in a single, compact unit. The Axis P3827-PVE delivers seamless 180° panoramic views with four precisely aligned varifocal lenses. Perfect for monitoring wide areas like parking lots, school campuses, shopping centers, and building perimeters, this powerful camera ensures minimal blind spots and high image usability in any light. With advanced features like Axis Lightfinder and Forensic WDR, it’s built to perform in challenging conditions while minimizing bandwidth and storage use.
Features
-
180° Panoramic View – Covers large open spaces with no blind spots, reducing the need for multiple cameras.
-
Four Varifocal Lenses – Adjust focal lengths for precision monitoring of wide or targeted zones.
-
Axis Lightfinder Technology – Delivers true-to-life color and detail even in near-darkness.
-
Forensic WDR – Preserves critical detail in high-contrast scenes like entranceways or parking areas.
-
Robust Outdoor Protection – IP66, NEMA 4X, and IK10 ratings ensure durability in harsh weather or vandal-prone areas.
-
Efficient Zipstream Compression – Cuts bandwidth and storage costs without losing critical forensic detail.
-
Integrated IR Illumination – Reliable night-time coverage even in pitch-dark environments.
-
Edge Analytics Support – Enables smart functions like line crossing or motion detection, reducing false alerts.
-
Discreet Dome Design – A low-profile look ideal for educational campuses, city surveillance, or storefronts.
Downloads
Extra Info
Seamless Stitching for Total Coverage
Unlike traditional multi-sensor cameras that produce disjointed images, the P3827-PVE delivers a seamless 180° panoramic view thanks to factory-aligned lenses and image stitching. This means fewer gaps, better situational awareness, and cleaner evidence in critical moments.
Optimized for Challenging Light
In environments where lighting changes drastically—like entrances or corridors with strong sunlight and shadows—Forensic WDR and Lightfinder work together to ensure details are captured clearly. Lightfinder gives you full-color imaging in low light, while WDR balances extremes of brightness and dark.
Built for the Outdoors
Its tough design withstands both natural elements and human tampering. IP66-rated for water and dust, IK10-rated for impact resistance, and NEMA 4X-certified, it’s ideal for public-facing deployments, including transportation hubs and building exteriors.
Smarter Surveillance with Built-In Analytics
The camera supports edge analytics—meaning it can detect motion, count people, or identify perimeter breaches without needing external processing. Installers and users alike benefit from faster deployment and fewer false positives.
Efficient Without Compromise
With Axis Zipstream and H.264/H.265 support, this camera offers high-quality footage without draining network resources. It’s ideal for systems with multiple cameras or long-term video retention requirements.
Tech Specs
| Camera Models |
AXIS P3827-PVE |
| Image Sensor |
1/2.5" progressive scan RGB CMOS |
| Minimum Illumination |
Color: 0.15 lux at 30 IRE
B/W: 0.03 lux at 30 IRE |
| Shutter Speed |
1/31500 s to 1/2 s |
| Lens |
Varifocal 4 × lenses
Focal length: 3.3–5.9 mm
Horizontal field of view: 180°
Vertical field of view: 56°–103° |
| Aperture |
F2.2 |
| Day/Night Function |
Automatically removable infrared-cut filter |
| Pan/Tilt/Zoom |
Digital PTZ |
| Video Compression |
H.264 (MPEG-4 Part 10/AVC)
H.265 (HEVC)
Motion JPEG |
| Resolutions |
8000×1440 to 320×240 |
| Frame Rate |
Up to 20 fps in all resolutions |
| Video Streaming |
Multiple individually configurable streams
Axis Zipstream technology in H.264/H.265 |
| Image Settings |
Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones,
WDR: Forensic WDR, dynamic text and image overlay, mirroring, rotation,
privacy masks, polygon privacy masks, barrel distortion correction |
| Wide Dynamic Range |
Forensic WDR |
| Light Sensitivity |
Axis Lightfinder |
| IR Illumination |
OptimizedIR
Range: 20 m (65 ft)
Wavelength: 850 nm |
| Audio |
Two-way audio
Audio input/output via 3.5 mm jack |
| Event Triggers |
Analytics, edge storage events, input signal, time control, recurring schedule, virtual input |
| Event Actions |
File upload, email notification, HTTP/HTTPS notification, SNMP trap,
overlay text/image, status LED, video/audio recording to edge storage,
audio clip play, PTZ control, guard tour, external output activation |
| Video Analytics |
Motion detection, tampering alarm, audio detection, edge analytics via ACAP |
| Network Protocols |
IPv4, IPv6, HTTP, HTTPS, SSL/TLS, QoS, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMP v1/v2c/v3,
DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
| Security |
Signed firmware, secure boot, Axis Edge Vault, encrypted video
HTTPS, IEEE 802.1x, IP address filtering, brute force delay protection, user access control |
| Edge Storage |
MicroSD/microSDHC/microSDXC slot
Support for recording to NAS (network-attached storage) |
| Connectors |
RJ45 10BASE-T/100BASE-TX/1000BASE-T
3.5 mm mic/line in, 3.5 mm line out
2-pin terminal block for power input (24 V DC)
6-pin terminal block for I/O |
| Power |
Power over Ethernet (PoE) IEEE 802.3bt Type 4 Class 8
DC input: 24 V DC, max. 30 W |
| Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F)
Humidity: 10–100% RH (condensing) |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F) |
| Ingress Protection |
IP66, IP6K9K, NEMA 4X |
| Impact Resistance |
IK10 |
| Vandal Resistance |
Yes |
| Dimensions |
Height: 151 mm (6 in)
Diameter: 250 mm (9.8 in) |
| Weight |
2.5 kg (5.5 lb) |
| Casing |
Aluminum base, polycarbonate dome, vandal-resistant polycarbonate casing with dehumidifying membrane |
| Mounting Options |
Wall, pole, corner, ceiling, pendant, parapet, and junction box mount
Mounting accessories sold separately |
| Certifications |
UL, CE, EAC, RCM, VCCI, KC, BIS, NOM, FCC, ICES, RoHS, WEEE, REACH |
| Included Accessories |
Installation guide, Windows decoder 1-user license, drill template, connector guards |
| Warranty |
5-year limited warranty |
Q&A
Q: What is the field of view on the Axis P3827-PVE?
A: It provides a seamless 180° horizontal panoramic view using four varifocal lenses with factory-calibrated stitching.
Q: Can this camera be used outdoors?
A: Yes, it is IP66-, IK10-, and NEMA 4X-rated, making it suitable for harsh weather and vandal-prone locations.
Q: Does the camera have night vision?
A: Yes, it includes integrated infrared (IR) illumination and Lightfinder technology for excellent low-light performance.
Q: Is it suitable for large commercial or city surveillance?
A: Absolutely. It’s ideal for wide-area monitoring in places like stadiums, campuses, airports, and parking lots.
Q: Does it support smart analytics?
A: Yes, it supports edge analytics for motion detection, line crossing, and more via the AXIS Camera Application Platform.
Q: Will this work with existing VMS platforms?
A: Yes, it's ONVIF Profile G, S, and T compliant, ensuring broad compatibility with most video management systems.
