Get wide coverage and exceptional clarity from a single compact unit with the AXIS P4707-PLVE. Designed for demanding outdoor surveillance, this dual-sensor panoramic camera captures high-detail video in low light, manages multiple angles simultaneously, and blends advanced Axis image technologies for maximum reliability. Perfect for securing large open areas like parking lots, building entrances, intersections, and commercial properties—day or night, rain or shine.
Features
-
Dual-Sensor Coverage: Monitor two different areas at once with a single camera—ideal for wide entrances, intersections, and open spaces.
-
Remote Varifocal Lenses: Adjust zoom and focus remotely for precise setup and maximum flexibility during installation.
-
Lightfinder and Forensic WDR: Capture high-detail color footage in near darkness and manage extreme lighting contrasts with ease.
-
Integrated IR Illumination: Enjoy reliable nighttime visibility up to 30 meters with built-in IR LEDs per channel.
-
Compact, Discreet Design: Minimize hardware footprint while maximizing coverage—great for professional environments.
-
Zipstream Compression: Reduce storage and bandwidth use without sacrificing critical video details.
-
Outdoor-Ready Build: With IP66, IK10, and NEMA 4X ratings, it’s engineered to withstand dust, rain, vandalism, and tough climates.
-
Built-In Deep Learning Analytics: Detect, classify, and track objects more accurately—ideal for reducing false alarms.
-
P-Series Technology Platform: Get high-performance processing and enhanced cybersecurity with Axis ARTPEC-8 chip.
Downloads
Extra Info
Dual Coverage, One Mount
The AXIS P4707-PLVE includes two independently controlled sensors in a single housing. Each sensor can be aimed and configured separately, allowing full control over surveillance zones without installing multiple cameras.
Built for Harsh Environments
With robust IP66 and IK10 ratings, plus NEMA 4X compliance, this camera is ready for outdoor use in tough environments. Whether facing high winds, dust, rain, or attempts at vandalism, it delivers uninterrupted performance.
Smart Video Capabilities
Equipped with Axis Object Analytics, this model provides reliable motion detection, object classification, and perimeter defense. Deep learning enables smarter alerts that focus on human or vehicle activity—ideal for proactive monitoring.
Superior Low-Light Imaging
Axis Lightfinder and Forensic WDR technologies deliver vivid color and clarity even in low-light or high-contrast scenes. It’s especially useful for identifying faces, license plates, or suspicious activity in challenging lighting conditions.
Efficient Storage and Management
Axis Zipstream technology, optimized for H.264 and H.265, compresses video intelligently to keep storage needs low—without compromising image quality.
Tech Specs
| Camera Models |
AXIS P4707-PLVE |
| Camera Type |
Dual-sensor panoramic camera with IR and remote zoom |
| Image Sensor |
1/2.8" progressive scan RGB CMOS (per channel) |
| Minimum Illumination |
Color: 0.15 lux
B/W: 0.03 lux
0 lux with IR illumination on |
| IR Illumination |
Optimized IR with 2 LEDs
Range: Up to 30 m (98 ft) per channel
850 nm wavelength |
| Lens |
Varifocal, 3.1–8.6 mm
Horizontal FOV: 39°–105°
Vertical FOV: 21°–56° |
| Lens Mount |
M12, Remote focus and zoom |
| Day/Night Function |
IR-cut filter with auto switch |
| Shutter Speed |
1/66500 s to 1 s |
| Pan/Tilt/Rotation |
Pan: ±90°
Tilt: 0–92°
Rotation: ±95° |
| Video Compression |
H.264 (Baseline/Main/High), H.265 (Main), MJPEG |
| Resolutions |
4 MP (2304×1728) per channel
Up to 15 fps with WDR
Up to 30 fps without WDR |
| Video Streaming |
Multiple configurable streams per channel
Dynamic FPS
Zipstream for H.264/H.265 |
| Image Enhancements |
Forensic WDR
Lightfinder
Image stabilization
Corridor Format
Color level adjustment |
| Analytics |
AXIS Object Analytics
Motion detection
Tampering alarm
Audio detection |
| Audio |
Two-way audio
Built-in microphone
External microphone input and line output
AAC-LC, G.711, G.726 |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE
Terminal block for I/O, power, and audio
microSD slot |
| Edge Storage |
microSD/microSDHC/microSDXC card slot
Support for recording to NAS |
| Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F)
Humidity: 10–100% RH (condensing) |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F) |
| Ingress Protection |
IP66, IP6K9K, NEMA 4X |
| Impact Resistance |
IK10-rated housing |
| Vandal-Resistant |
Yes |
| Power |
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1
Typical: 10.9 W
Max: 12.95 W |
| Casing |
Aluminum, polycarbonate, and polymer
Recyclable plastics: over 65% |
| Dimensions |
Ø 149 x 112 mm (Ø 5.9 x 4.4 in) |
| Weight |
970 g (2.1 lb) |
| Included Accessories |
Installation guide
Connector kit
Resistorx L-key
AXIS Surveillance microSDXC Card 64 GB |
| Optional Accessories |
Wall mounts, pole mounts, smokes domes, and more
See axis.com for full list |
| Warranty |
5-year Axis limited hardware warranty |
Q&A
Q: How many views can this camera provide?
A: The AXIS P4707-PLVE uses two sensors, allowing you to monitor two areas simultaneously with different fields of view.
Q: Is this suitable for outdoor use?
A: Yes, it’s outdoor-ready with IP66, IK10, and NEMA 4X ratings, offering full protection against dust, water, and impact.
Q: Can I use this camera in complete darkness?
A: Yes, it features built-in IR LEDs (30m range) and Lightfinder technology for excellent low-light and nighttime performance.
Q: What is Lightfinder and Forensic WDR?
A: Lightfinder enhances color and detail in near-dark conditions. Forensic WDR balances scenes with both very bright and dark areas, making critical details more visible.
Q: Can I adjust the camera remotely after installation?
A: Yes, both varifocal lenses can be adjusted remotely, making setup and changes simple without needing a technician onsite.
