The Axis P5655-E PTZ Network Camera is a high-performance, cost-effective surveillance solution engineered for demanding environments. Offering crystal-clear HDTV 1080p resolution with an impressive 32x optical zoom, it excels in capturing intricate details across vast indoor and outdoor areas. Equipped with advanced imaging technologies like Forensic WDR and Lightfinder 2.0, this camera delivers superior video quality even in the most challenging lighting conditions. Its robust design, coupled with advanced security features and intelligent analytics, makes it an ideal choice for reliable and proactive monitoring in applications ranging from industrial facilities and public spaces to expansive commercial properties.
Features
-
Exceptional Low-Light Performance: Lightfinder 2.0 technology delivers richer colors and sharper images of moving objects even in extreme low-light conditions.
-
Optimal Clarity in High Contrast: Forensic WDR (Wide Dynamic Range) ensures clear visibility of details in both very bright and very dark areas of a scene, providing forensic value.
-
Precision Zoom Capability: A powerful 32x optical zoom allows for detailed monitoring of distant objects and expansive areas with precise pan and tilt control.
-
All-Weather and Vandal-Resistant: Rated IP66, NEMA 4X, and IK10, this camera is built to withstand harsh weather, corrosion, dust, and significant impacts, ensuring continuous operation outdoors.
-
Advanced Data Compression: Axis Zipstream technology with H.264 and H.265 support significantly reduces bandwidth and storage requirements without compromising critical image detail.
-
Stable and Clear Footage: Electronic Image Stabilization (EIS) minimizes the effects of camera vibrations and shaking, delivering consistently smooth and usable video.
-
Enhanced Cybersecurity: Features like signed firmware and secure boot provide robust protection against unauthorized access and malware, safeguarding your surveillance system.
-
Intelligent Object Analytics: Built-in AXIS Object Analytics allows for precise detection and classification of humans and vehicles, reducing false alarms and streamlining incident response.
-
Quick Focus Recall: Focus Recall functionality enables instant, sharp focus in predefined challenging lighting conditions or specific areas, improving operational efficiency.
Downloads
Extra Info
Crystal Clear Vision in Any Light
The P5655-E leverages two powerful Axis technologies to ensure superior image quality around the clock. Forensic WDR intelligently balances extreme light and dark areas within the same scene, revealing crucial details that would otherwise be lost to glare or shadow. Complementing this, Lightfinder 2.0 captures more saturated colors and sharper images of moving objects in low-light environments, transforming dimly lit scenes into actionable video.
Effortless Precision & Focus
With its 32x optical zoom, this camera allows operators to zoom in on specific areas of interest from a distance without losing image quality. The unique Focus Recall feature provides instant sharp focus in predefined areas, significantly improving PTZ performance in dynamic or challenging lighting conditions by eliminating the need for manual adjustments. Coupled with Electronic Image Stabilization (EIS), footage remains steady and clear, even when the camera is subject to vibrations, making it ideal for installations on poles or in high-wind areas.
Built for the Toughest Environments
Designed for resilience, the P5655-E boasts comprehensive environmental protection. Its IP66 rating confirms complete protection against dust and powerful water jets, while the NEMA 4X rating offers additional resistance against corrosion and windblown dust, rain, sleet, and external ice formation. An IK10 impact resistance rating ensures the camera can withstand significant force, deterring vandalism and providing reliable performance in exposed locations. It operates reliably in temperatures ranging from -30°C to 50°C (-22°F to 122°F).
Optimized Data Management
Axis Zipstream technology is engineered to optimize your network and storage efficiency. By intelligently analyzing the video stream in real-time, it preserves critical forensic details while significantly reducing bandwidth and storage consumption. This intelligent compression, supporting both H.264 and H.265 video formats, ensures you capture all vital information without overburdening your infrastructure.
Intelligent Analytics for Proactive Security
Beyond basic motion detection, the P5655-E is equipped with advanced analytics capabilities. AXIS Object Analytics, powered by an ARTPEC-7 chip with a machine learning processing unit, enables the camera to detect and classify humans and vehicles. This significantly reduces false alarms, allowing security personnel to focus on genuine threats. Features like AXIS Video Motion Detection, audio detection, and Advanced Gatekeeper further automate surveillance tasks, making your security system more proactive and efficient.
Robust Cybersecurity
Security is paramount with the P5655-E. Signed firmware ensures that only genuine, unaltered Axis firmware can be installed, preventing malicious modifications. Secure boot guarantees that the camera starts up free from malware, providing a high level of defense against cyberattacks and ensuring system integrity from the moment it powers on.
Tech Specs
| Specification |
Details |
| Camera Image Sensor |
1/2.8” progressive scan CMOS |
| Wide Dynamic Range |
WDR – Forensic Capture |
| Min. Illumination |
Color: 0.1 lux at 30 IRE
B/W: 0.01 lux at 30 IRE |
| Shutter Speed |
1/66500 s to 1 s |
| Camera Angle of View |
Horizontal: 63.4°–2.2°
Vertical: 38.1°–1.3° |
| Pan Range |
360° endless |
| Tilt Range |
–90° to +90° |
| Pan/Tilt Speed |
Pan: 0.1°/s to 450°/s
Tilt: 0.1°/s to 450°/s |
| Preset Accuracy |
±0.05° |
| Zoom |
32x optical, 12x digital |
| Focal Length |
4.3–137.6 mm |
| Aperture |
F1.6–F4.95 |
| Day/Night Functionality |
Automatically removable IR-cut filter |
| Video Compression |
H.264 (Baseline, Main, High profiles)
Motion JPEG
H.265 (Main profile) |
| Resolution |
1920x1080 to 160x90 |
| Frame Rate |
Up to 60 fps with power line frequency 60 Hz
Up to 50 fps with 50 Hz |
| Video Streaming |
Multiple, individually configurable streams
Dynamic GOP
Dynamic FPS |
| Image Settings |
Compression, Color, Brightness, Sharpness, Contrast, White balance,
Exposure control, Exposure zones, WDR, Noise reduction, Local contrast,
Overlay (text/image), Privacy masks, Image freeze on PTZ |
| Audio |
Two-way audio
Audio encoding: AAC-LC, G.711, G.726, Opus |
| Audio Input/Output |
External microphone input or line input, Line output |
| Network Protocols |
IPv4, IPv6, HTTP, HTTPS, SSL/TLS, QoS, FTP, SFTP, CIFS/SMB, SMTP, Bonjour,
UPnP, SNMP v1/v2c/v3, DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP,
RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
| Security |
Signed firmware, Secure boot, Axis Edge Vault with TPM, HTTPS encryption,
IEEE 802.1x (EAP-TLS), Password protection, IP address filtering,
User access log, Digest authentication, Brute force delay protection |
| Connectors |
RJ45 10BASE-T/100BASE-TX PoE
Audio I/O: 3.5 mm jack
4 configurable I/O ports |
| Edge Storage |
MicroSD/microSDHC/microSDXC card slot
Support for SD card encryption
Support for recording to network-attached storage (NAS) |
| Operating Conditions |
–40 °C to 50 °C (–40 °F to 122 °F)
Humidity 10–100% RH (condensing) |
| Storage Conditions |
–40 °C to 65 °C (–40 °F to 149 °F) |
| Approvals |
EMC: EN 55032 Class A, EN 55024, FCC Part 15 Subpart B Class A,
ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A,
IEC 61000-6-1, IEC 61000-6-2
Safety: IEC/EN/UL 62368-1
Environment: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14,
IEC 60068-2-6, IEC 60068-2-27 |
| Power |
Power over Ethernet (PoE+) IEEE 802.3at Type 2 Class 4 |
| Power Consumption |
Max 25.5 W |
| Casing |
IP66-, NEMA 4X- and IK10-rated metal casing
Built-in heater
Arctic temperature control |
| Dimensions |
Ø 160 x 295 mm (Ø 6.3 x 11.6 in) |
| Weight |
2.4 kg (5.3 lb) |
| Included Accessories |
Installation guide, Windows decoder 1-user license,
AXIS T94A01D Pendant Kit, Connector guard |
| Optional Accessories |
AXIS T91B61 Wall Mount
AXIS T91A47 Pole Mount
AXIS Surveillance Cards
AXIS Media Converter Switch |
| Warranty |
5-year limited warranty |
Q&A
Q: What is the maximum video resolution and optical zoom of the Axis P5655-E? A: The Axis P5655-E provides HDTV 1080p (1920x1080) resolution and features a powerful 32x optical zoom.
Q: Is this camera suitable for outdoor use, and what are its environmental protection ratings? A: Yes, the Axis P5655-E is designed for robust outdoor use. It is IP66-rated for dust and water protection, NEMA 4X-rated for corrosion and environmental resistance, and IK10-rated for impact resistance against vandalism. It can operate in temperatures from -30°C to 50°C (-22°F to 122°F).
Q: How does the camera perform in low-light conditions? A: The camera excels in low-light thanks to Lightfinder 2.0, which captures more saturated colors and sharper images of moving objects, and Forensic WDR, which ensures clarity in scenes with both very bright and very dark areas.
Q: What enhanced security features does the Axis P5655-E offer? A: It includes signed firmware to prevent tampering and secure boot, which ensures the camera starts up free from malware, providing enhanced cybersecurity for your system.
Q: Does the Axis P5655-E support two-way audio? A: Yes, the camera supports two-way audio with external microphone input or line input and line output, along with I/O ports for flexible integration.
Q: What types of intelligent analytics are available with this camera? A: The camera offers advanced analytics capabilities including AXIS Object Analytics (for detection and classification of humans and vehicles), AXIS Video Motion Detection, audio detection, Advanced Gatekeeper, and Autotracker 2.
Q: How does the camera optimize bandwidth and storage for video recording? A: It utilizes Axis Zipstream technology with support for H.264 and H.265 video compression, which significantly lowers bandwidth and storage requirements by preserving important details while reducing unnecessary data.
