The AXIS P5676-LE PTZ Camera is a high-performance, 4 MP camera designed for robust outdoor surveillance, offering exceptional detail and broad coverage. It features 30x optical zoom and integrated IR illumination, ensuring clear imaging even in challenging light conditions or near total darkness. With advanced analytics like AXIS Object Analytics, it intelligently detects and classifies people and vehicles, making it ideal for monitoring large areas such as parking lots, industrial sites, and urban environments. This camera provides comprehensive situational awareness and includes built-in cybersecurity features to protect your system from unauthorized access.
Features
-
30x Optical Zoom Lens – Capture fine details from long distances, ideal for parking lots, large properties, and public spaces.
-
Axis Lightfinder 2.0 – Delivers sharp color images even in near-total darkness for critical low-light performance.
-
Optimized IR with 250m Range – See clearly at night with built-in infrared LEDs that automatically adapt to the scene.
-
Intelligent Object Analytics – Built-in AI distinguishes between people and vehicles to reduce false alerts and improve security focus.
-
360° Endless Pan and High-Speed Tilt – Track activity in real-time with full area coverage and rapid repositioning.
-
Outdoor-Ready Design (IK10/IP66/IP67/NEMA 4X) – Built to withstand extreme weather, impact, and dust in demanding environments.
-
Autotracking 2 with Orientation Aid – Automatically follow moving targets with intuitive visual support, reducing manual monitoring.
-
Signed Firmware and Secure Boot – Advanced cybersecurity protections ensure device integrity and data safety.
-
Flexible Installation with Edge Storage – Store footage on-board and deploy in remote or network-limited areas with microSD support.
Downloads
Extra Info
Advanced Imaging in Any Light
The Axis P5676-LE combines 4MP resolution with Axis Lightfinder 2.0 and Forensic WDR to provide high-contrast, low-noise footage even in challenging lighting. Whether it's a dimly lit alley or bright backlight from a vehicle's headlights, this camera adapts for accurate identification.
True Long-Range Night Vision
Thanks to Optimized IR that reaches up to 250 meters, this camera is well-suited for securing large outdoor areas like commercial yards, perimeter fences, or industrial zones. The IR adjusts automatically based on zoom, so you always get even, usable images without overexposure.
Precision Tracking & AI Detection
With Autotracking 2 and built-in analytics, the P5676-LE doesn’t just observe — it acts. It intelligently follows moving people or vehicles, highlights direction, and supports operators with real-time alerts and visual cues. Great for active deterrence and forensic review.
Rugged Build for Any Environment
The robust aluminum housing meets IP66, IP67, NEMA 4X, and IK10 standards, making it suitable for harsh outdoor conditions including rain, snow, heat, vandalism, or dust. It operates between –40 °C to 60 °C, giving you confidence it won’t fail when conditions get tough.
Cybersecurity Built-In
The camera is equipped with Axis Edge Vault, a secure cryptographic module that protects the camera ID and simplifies secure device onboarding. Signed firmware and Secure Boot help ensure only trusted code runs on the device — ideal for privacy-focused installations.
Ideal Use Cases
Perfect for parking surveillance, building entrances, warehouses, stadiums, campuses, city intersections, and any environment where long-range detail, flexible monitoring, and reliability are key.
Tech Specs
| Brand |
Axis Communications |
| Model |
AXIS P5676-LE |
| Product Type |
Pan-Tilt-Zoom (PTZ) Network Camera |
| Image Sensor |
1/1.8" progressive scan CMOS |
| Lens |
Motorized varifocal
f = 6.9–206 mm, F1.5–4.8 |
| Optical Zoom |
30× |
| Digital Zoom |
12× |
| Horizontal Field of View |
61.8°–2.3° |
| Vertical Field of View |
36.5°–1.3° |
| Minimum Illumination |
Color: 0.03 lux (50 IRE, F1.5)
B/W: 0.003 lux (50 IRE, F1.5)
0 lux with IR illumination on |
| IR Illumination |
Optimized IR up to 250 m (820 ft) |
| Shutter Speed |
1/33500 s to 2 s |
| Pan Range |
360° endless |
| Tilt Range |
–90° to +90° |
| Pan Speed |
0.05°/s to 450°/s |
| Tilt Speed |
0.05°/s to 450°/s |
| Presets |
256 positions |
| Video Resolution |
4 MP: 2688x1512 (16:9) |
| Video Compression |
H.264 (MPEG-4 Part 10/AVC), H.265 (HEVC), MJPEG |
| Frame Rate |
Up to 60 fps at 2688x1512 |
| WDR (Wide Dynamic Range) |
120 dB |
| Day/Night Functionality |
Automatically removable IR-cut filter |
| Audio Support |
Two-way audio
G.711, G.726, G.722.1, LPCM, Opus |
| Edge Storage |
MicroSD/microSDHC/microSDXC slot
Support for SD card encryption |
| Network Interface |
RJ45 10BASE-T/100BASE-TX PoE |
| Power |
High PoE (IEEE 802.3bt Type 4, Class 8)
Typical 24 W, max 74 W |
| Operating Conditions |
–40 °C to 60 °C (–40 °F to 140 °F)
Humidity 10–100% RH (condensing) |
| Storage Conditions |
–40 °C to 65 °C (–40 °F to 149 °F) |
| Protection Rating |
IP66, IP67, NEMA 4X, IK10 |
| Vandal Resistance |
IK10-rated metal casing |
| Dimensions |
Ø 205 mm × 291 mm (Ø 8.1 in × 11.5 in) |
| Weight |
Approx. 3.3 kg (7.3 lb) |
| Included Accessories |
Installation guide, Windows decoder license,
Connector kit, Resistorx L-key, Desiccant bag |
| Optional Accessories |
Wall, ceiling, pole, and corner mounts
AXIS Surveillance Cards |
| Cybersecurity Features |
Signed firmware
Secure Boot
TPM module
Axis Edge Vault with hardware-based secure storage |
| Analytics |
Object classification (human, vehicle)
Autotracking 2
Orientation aid
Motion detection, fence guard, object counting |
| ONVIF Compliance |
Profile G, S, T conformant |
| Supplier SKU |
AXIS-02049-001 |
Q&A
Q: Can this camera be used outdoors in extreme weather?
A: Yes. The P5676-LE has IP66/IP67, NEMA 4X, and IK10 ratings for water, dust, and impact resistance, with an operating range from –40 °C to 60 °C.
Q: How far can it see at night?
A: The built-in Optimized IR illuminators reach up to 250 meters (820 feet), automatically adjusting based on zoom level for balanced nighttime viewing.
Q: Does it support smart motion detection?
A: Yes. It includes advanced analytics with object classification, line crossing, intrusion detection, and autotracking for human and vehicle targets.
Q: Can it record video locally?
A: Absolutely. It has a microSD card slot that supports edge storage with optional encryption, ideal for backup or standalone operation.
Q: What mounting options are available?
A: A variety of accessories are supported, including mounts for walls, ceilings, poles, and corners, making it flexible for almost any installation.
Q: Is this camera secure against cyber threats?
A: Yes. It features signed firmware, Secure Boot, and Axis Edge Vault for secure device identity and data protection.
