**Camera** |
|
Image Sensor |
1/2.8” progressive scan RGB CMOS |
Pixel Size |
2.9 µm |
Lens |
Varifocal 4.3–137 mm, F1.4–4.0H-FOV: 60°–2.3°, V-FOV: 39°–1.3°Remote zoom/focus, P-Iris, 62 mm filter thread |
Minimum Focus Distance |
1.2 m (3.9 ft) |
Day/Night Mode |
Removable IR-cut (day), IR-pass 720 nm (night) |
Minimum Illumination |
Color: 0.06 lux (F1.4), B/W: 0.01 lux (F1.4), 0 lux with IR |
Shutter Speed |
Up to 1/111000 s to 2 s (up to 90 fps) |
Camera Angle Adjustment |
Pan ±180°, Tilt 0 to -90°, Roll -90 to 270° |
SoC |
ARTPEC-8 with Deep Learning Processing Unit |
Memory |
2048 MB RAM, 8192 MB Flash |
**Video** |
|
Video Compression |
H.264 (Baseline/Main/High), H.265 (Main), Motion JPEG |
Resolution |
4:3: 1400x1050 to 160x12016:9: 1920x1080 to 320x180 |
Frame Rate |
WDR: up to 30 fpsNo WDR: up to 90 fps |
Streaming |
Up to 20 configurable streamsZipstream, low latency, VBR/ABR/MBR |
SNR |
>55 dB |
WDR |
Forensic WDR up to 120 dB |
Multi-View Streaming |
Up to 8 cropped views |
Noise Reduction |
2D (spatial), 3D (temporal) |
Image Settings |
Saturation, contrast, sharpness, exposure, defog, distortion correction, overlays, mirroring, corridor format |
Scene Profiles |
Forensic, vivid, traffic overview |
PTZ |
Digital PTZ, optical zoom, presets, guard tour, directional indicator |
**Audio** |
|
Features |
AGC, 10-band EQ, mic/speaker pairing, spectrum visualizer |
Audio I/O |
Mic in, line-in, line-out, digital in, 12 V ring power |
Audio Encoding |
LPCM, AAC-LC, G.711, G.726, Opus |
**Network** |
|
Protocols |
IPv4/6, HTTP/S, FTP/SFTP, CIFS/SMB, SMTP, mDNS, UPnP, SNMP, RTSP/RTP/SRTP, MQTT, SIP, SSH, LLDP, CDP, IEEE 802.1X/AR, NTP/NTS, etc. |
**System Integration** |
|
APIs |
VAPIX, ACAP (Native/CV SDK), ONVIF Profiles G/M/S/T |
Event Triggers |
Health, temp, digital/audio, I/O, motion, tampering, schedule, MQTT |
Event Actions |
Overlays, light control, recordings, image/video clip send, WDR, MQTT, SNMP |
Installation Aids |
Pixel counter, remote zoom/focus, leveling assistant |
**Analytics** |
|
Included Applications |
AXIS Object Analytics, Scene Metadata, Privacy Shield, VMD, tampering, audio detection |
Supported Applications |
License Plate Verifier, Perimeter Defender, Speed Monitor, ACAP 3rd-party |
AXIS Object Analytics |
Detects/classifies humans/vehiclesScenarios: line crossing, time in area, crossline countingTrajectory visual, bounding boxes |
Scene Metadata |
Human, face, vehicle, license plate detection + attributes |
**Cybersecurity** |
|
Hardware Security |
Axis Edge Vault, TPM 2.0 (FIPS 140-2 Level 2), secure boot, signed OS/video |
Network Security |
IEEE 802.1X, HTTPS, TLS 1.2/1.3, firewall, NTS, X.509 |
Documentation |
Hardening Guide, SBOM, Security Model, Vulnerability Policy |
**General** |
|
Casing |
IP66/67, IK10 body, IK08 glass, NEMA 4X, anti-glare |
Power |
PoE (IEEE 802.3af/at/bt), DC (10–28 V), AC (20–24 V)PoE-out supported |
Connectors |
RJ45 (PoE), RJ45 (PoE-out), I/O (2x), audio (3.5 mm), DC input |
IR Illumination |
Optimised IR with 850 nm IR LEDsRange: 100 m+ |
Storage |
microSD/microSDHC/microSDXC, NASAES-XTS encrypted |
Operating Conditions |
-40 °C to 60 °C, Max 74 °C intermittent, 10–100% RH |
Storage Conditions |
-40 °C to 65 °C, 5–95% RH |
Dimensions |
EPA: 0.0478 m² (0.51 ft²) |
Weight |
3200 g (7.05 lb) |
Included Accessories |
Camera, terminal block, RJ45 cable, connector guard, gaskets, installation guide, auth key |
Optional Accessories |
T8415 Installer Tool, surveillance cards, mounts (axis.com) |
VMS Compatibility |
AXIS Companion, AXIS Camera Station, Device Manager, partner VMS |
Languages |
English, French, German, Spanish, Chinese, Japanese, Korean, Polish, more |
Warranty |
5-year warranty |
