Specification |
Details |
**Camera** |
|
Image Sensor |
1/2.8” progressive scan RGB CMOS |
Lens |
9 mm: 3–9 mm F1.3 • 22 mm: 9–22 mm F1.6, Remote focus & zoom, P-Iris |
Field of View |
105°–36° (9 mm), 36°–15° (22 mm) |
Min. Illumination |
0.11 lux color, 0.02 lux B/W (9 mm); 0.17 lux color, 0.03 lux B/W (22 mm) |
Day/Night |
IR-cut filter (automatically removable) |
Shutter Time |
1/143000 to 2 s |
Angle Adjustment |
Pan 360°, Tilt -5° to 80°, Rotation ±95° |
**Video** |
|
Compression |
H.264 (Baseline/Main/High), Motion JPEG |
Resolution |
Up to 1920x1080 |
Frame Rate |
Up to 60 fps (1080p), Up to 120 fps (720p) |
Streaming |
Multiple streams, Zipstream, VBR/MBR |
WDR |
Forensic WDR: Up to 120 dB |
Image Settings |
Scene profiles, white balance, privacy mask, stabilization, rotation, etc. |
PTZ |
Digital PTZ, preset positions, 3x optical zoom (9 mm), 2.4x (22 mm) |
**Audio** |
|
Input/Output |
3.5 mm mic/line in, line out |
Streaming |
Full-duplex |
Compression |
LPCM, AAC LC, G.711, G.726, Opus |
**Network** |
|
Protocols |
IPv4/6, HTTP/S, SSL/TLS, FTP, SNMP, RTSP/RTP, SRTP, MQTT, LLDP, etc. |
Connectors |
RJ45 PoE, I/O terminal block |
**System Integration** |
|
API |
VAPIX, ONVIF (S/G), ACAP, AXIS Guardian |
Events |
Motion, audio, tampering, edge storage, I/O, shock detection |
Actions |
Upload, notifications, overlays, SNMP, etc. |
Built-in Tools |
Remote zoom/focus, leveling assist, pixel counter |
**Analytics** |
|
Included |
AXIS Guard Suite, tampering alarm, motion detection |
Supported |
AXIS Perimeter Defender, Digital Autotracking, ACAP apps |
**Cybersecurity** |
|
Hardware |
Secure boot, Axis Edge Vault |
Network |
IEEE 802.1X, TLS/HTTPS, brute force protection |
**General** |
|
Casing |
IP66, IP67, IP6K9K, IK10+, NEMA 4X, dehumidifying membrane |
Power |
PoE IEEE 802.3af/at, 8–28 V DC, or 20–24 V AC |
Storage |
microSD/microSDHC/microSDXC, SD encryption, NAS support |
Operating Conditions |
-50 °C to 60 °C, 10–100% RH |
Dimensions |
Varies (w/ housing) • Weight: 1.8 kg |
Languages |
EN, DE, FR, ES, IT, RU, ZH, JA, KO, PT, TR, and more |
Warranty |
3-year warranty + Axis Extended Warranty option |
