| **Camera** |
|
| Image Sensor |
1/1.8” progressive scan RGB CMOS |
| Lens |
4.3–8.6 mm varifocal, IR corrected, P-Iris |
| Field of View |
H: 103°–52°, V: 56°–30° |
| Minimum Illumination |
Color: 0.06 lux / B&W: 0.01 lux |
| IR |
Optimised IR with automatic IR-cut filter |
| PTRZ |
Remote pan ±190°, tilt -8° to +75°, roll ±97° |
| SoC |
ARTPEC-8 with DLPU |
| Memory |
2048 MB RAM, 8192 MB Flash |
| **Video** |
|
| Compression |
H.264 (Baseline/Main/High), H.265 (Main), Motion JPEG |
| Resolutions |
Up to 2688x1512 (16:9), 2016x1512 (4:3), 1280x800 (16:10) |
| Frame Rate |
Up to 60 fps (no WDR), 30 fps (with Forensic WDR) |
| WDR |
Forensic WDR up to 120 dB |
| Streaming |
Multi-stream, Zipstream, VBR/ABR/MBR support |
| EIS |
Built-in gyroscope-based electronic image stabilization |
| **Audio** |
|
| Audio Input/Output |
Mic input, line-in, network speaker pairing |
| Audio Formats |
AAC, G.711, G.726, LPCM, Opus |
| **Network** |
|
| Protocols |
IPv4/6, HTTP/2, HTTPS, TLS, FTP, SFTP, RTSP, RTP, SRTP, MQTT, SNMP, mDNS, etc. |
| Connectors |
RJ45 PoE (10/100/1000), terminal blocks for I/O and power |
| **System Integration** |
|
| API |
VAPIX, ONVIF (G/M/S/T), ACAP, SIP (VoIP), one-click cloud connection |
| Events |
Motion, tampering, I/O, audio, edge storage, MQTT, system status |
| Event Actions |
Recording, upload, alerts, overlays, LED, SNMP trap, MQTT publish |
| Built-In Tools |
PTRZ, pixel counter, level grid, auto roll |
| **Analytics** |
|
| Included |
AXIS Object Analytics, Scene Metadata, Tampering Alarm, Audio Detection |
| Object Classes |
Humans, vehicles (cars, buses, bikes, trucks) |
| Scenarios |
Line crossing, object in area, time in area, occupancy detection |
| Advanced Features |
Visual trajectories, color-coded bounding boxes, ONVIF event support |
| **Cybersecurity** |
|
| Software |
Signed OS, digest auth, OAuth 2.0, SD encryption |
| Hardware |
Axis Edge Vault, TPM 2.0, secure boot, signed video, secure keystore |
| Network |
IEEE 802.1X, TLS 1.2/1.3, MACsec, HTTPS, NTS, X.509 PKI |
| **General** |
|
| Casing |
IK10, IP66, NEMA 4X-rated; aluminum with polycarbonate dome |
| Power |
PoE IEEE 802.3at Class 4, 10–28V DC; max: 25W |
| Storage |
microSD/microSDHC/microSDXC with AES encryption; NAS support |
| Operating Conditions |
-50 °C to 55 °C; 10–100% RH (condensing) |
| Dimensions |
Ø 184 mm × H 141 mm |
| Weight |
2100 g (4.6 lb) |
| Languages |
EN, DE, FR, ES, IT, ZH, JA, KO, PT, PL, NL, RU, etc. |
| Warranty |
5-year warranty |
