| **Camera** |
|
| Image Sensor |
3 × 1/2.3” progressive scan CMOS |
| Lens |
3 × fixed-focus lenses, 5.0 mm, F2.8 |
| Field of View |
Combined 180° horizontal coverage |
| Day/Night |
IR-cut filter (removable) |
| Min Illumination |
Color: 2 lux; B/W: 0.4 lux |
| Shutter Speed |
1/23,250 s to 2/5 s |
| Adjustment |
Pan ±180°, Tilt 18°–75° |
| **Video** |
|
| Resolution |
3 × (3840×2880 to 320×240) |
| Frame Rate |
3 × 4K: 30 fps, 3 × 11 MP: 20 fps, 3 × 5 MP: 30 fps (16:9) |
| Compression |
H.264 (Baseline/Main/High), Motion JPEG |
| Streaming |
Multi-streaming with controllable frame rate and bandwidth (VBR/CBR) |
| Image Settings |
WDR (dynamic contrast), privacy masking, color, sharpness, overlays |
| PTZ |
Digital PTZ, preset positions, guard tour |
| **Network & Security** |
|
| Protocols |
IPv4/v6, HTTP/HTTPS, RTSP/RTP, FTP, SFTP, SMTP, SNMP, SSH, TLS, SOCKS, UPnP, Bonjour, MQTT |
| Security |
Password protection, IP filtering, HTTPS, IEEE 802.1X, Digest auth, access logs, certificate mgmt |
| Power |
PoE+ IEEE 802.3at Class 4; Max 23.1 W, Typical 16.7 W |
| Connectors |
Shielded RJ45 (10/100/1000BASE-T) |
| Storage |
Network-Attached Storage (NAS) support |
| **System Integration** |
|
| APIs |
VAPIX®, ACAP, ONVIF Profile S |
| Analytics |
Video motion detection, active tampering alarm, Axis Cross Line Detection |
| Events |
Motion, tampering, edge storage events |
| Event Actions |
Upload (FTP, email, HTTP), notifications, overlay text, video recording |
| Installation Aids |
Pixel counter |
| **General** |
|
| Casing |
IK10 & IP66-rated aluminum with transparent polycarbonate cover |
| Weather Shield |
Repaintable, protects from sun, rain, snow |
| Operating Temp |
-40 °C to 55 °C (start-up at -40 °C) |
| Humidity |
10–100% RH (condensing) |
| Storage Temp |
-40 °C to 65 °C |
| Dimensions |
205 × 205 × 172 mm |
| Weight |
2.2 kg (including weather shield) |
| Certifications |
EN 55022, FCC Part 15, NEMA 250 4X, IK10, and more |
| Languages |
Multiple language support |
| Warranty |
5-year warranty |
