Axis Q6010-E 50Hz 360 Outdoor Multi-Directional, 4X5MP Sensors, WDR - 01980-001

Description

The AXIS Q6010-E is a powerful 360° camera with four 5MP sensors for wide-area surveillance. Designed to work with AXIS Q60-E PTZ cameras, it offers one-click PTZ control and Autopilot for seamless tracking. With flexible lens options and simple installation, it’s ideal for city monitoring and critical infrastructure.

Features

  • 360° Overview – 4 x 5 MP sensors provide full panoramic surveillance
  • One-Click PTZ Control – Enables quick targeting with integrated PTZ camera
  • Autopilot – Automatic tracking in PTZ viewing areas
  • Exchangeable Autofocus Lenses – Easily adjust field of view
  • Zipstream Technology – Efficient H.264/H.265 compression without loss of detail
  • Flexible Setup – Uses same bracket, power, and cable as Q60-E PTZ cameras
  • Rugged Design – IP66, NEMA 4X, IK10-rated for harsh outdoor environments
  • Cybersecurity Built-In – Includes signed OS, encrypted storage, and secure boot

What’s Included

  • AXIS Q6010-E Network Camera
  • Q60-E Adapter
  • Bayonet Screws
  • Installation Guide
  • Windows Decoder License (1-user)

DOWNLOADS

Datasheet  AXIS Q6010-E Datasheet
Installation Guide  AXIS Q6010-E Installation Guide
User Manual  AXIS Q6010-E User Manual

Extra Info

360° Surveillance in One View
With four synchronized 5 MP sensors, this camera provides seamless panoramic coverage—ideal for wide-area monitoring in public spaces, city surveillance, and transportation hubs.

Integrated PTZ for Rapid Response
Connects with a compatible AXIS Q60-E PTZ camera to enable:

  • One-click PTZ control for instant zoom
  • Autopilot mode for automatic PTZ tracking of moving objects
  • Shared power and network cabling for simplified setup

Consistently Sharp Video, Day or Night
Enjoy clear imaging in any condition, featuring:

  • 20 MP combined resolution for exceptional detail
  • Forensic WDR to manage high-contrast scenes
  • Autofocus lenses for continuous clarity
  • Low-light performance down to 0.03 lux (B/W)

Flexible Installation, Maximum Compatibility
Swappable M12 lenses and modular mounting let you fine-tune the setup:

  • Tilted lens design for flexible positioning
  • Uses the same mount and power as Q60-E PTZ—no rewiring needed
  • Works with AXIS midspans and accessories

Built for the Toughest Environments
Designed for critical infrastructure and outdoor use:

  • IP66, IK10, and NEMA 4X certified
  • Operates from -40 °C to +50 °C (or -50 °C with heater kit)
  • Aluminum/polycarbonate housing resists impact, dust, rain, and corrosion

Secure and Future-Ready
Cybersecurity and system efficiency come standard:

  • Signed OS, encrypted file system, and secure boot
  • Axis Zipstream reduces bandwidth/storage without losing detail
  • Open API, ONVIF, and ACAP support for full integration flexibility

Tech Specs

Specification Details
**Camera**
Image Sensor 1/2.9” progressive scan RGB CMOS
Pixel Size 2.8 µm
Lens 3.6 mm, F2.0 or 2.8 mm, F1.2 (M12 mount, fixed iris)
Field of View 88° horizontal / 47° vertical (3.6 mm); 107° horizontal / 56° vertical (2.8 mm)
Day and Night Automatically removable infrared-cut filter
Minimum Illumination Color: 0.04 lux (F2.0), 0.02 lux (F1.2) at 30 IRE
Shutter Speed With WDR: 1/19000 to 1/5 s
Without WDR: 1/17000 to 1/5 s
Camera Angle Adjustment Pan: ±30°, Tilt: 15–90°, Rotation: ±175°
SoC Model S6LM55
Memory 1024 MB RAM, 512 MB Flash
**Video**
Compression H.264, H.265 (Main/High), Motion JPEG
Resolution Up to 1920x1080 (16:9)
Frame Rate H.264/H.265: 25/30 fps
Motion JPEG: 15 fps
Streams Up to 4 configurable streams; Zipstream supported
WDR Forensic WDR, up to 120 dB
Noise Reduction 2D and 3D (spatial/temporal) filters
Image Settings Compression, brightness, sharpness, white balance, privacy masks, overlays, rotation, Corridor Format
PTZ Digital PTZ, guard tour, preset positions
**Network**
Protocols IPv4, IPv6, HTTP, HTTPS, TLS, FTP, SFTP, CIFS/SMB, RTSP, MQTT, SNMP, SSH, MACsec, IEEE 802.1X
**System Integration**
API VAPIX, ACAP, ONVIF Profile G, M, S, T
VMS Support AXIS Companion, AXIS Camera Station, third-party VMS
Event Triggers Device status, I/O input, edge storage, scheduled events, tampering
Event Actions Upload, notification, overlay, preset, recording, MQTT publish
**Analytics**
Included Motion Detection, Tampering Alarm
Supported AXIS Fence Guard, AXIS Loitering Guard, AXIS Motion Guard
**General**
Casing Aluminum and polycarbonate
IP66/IP67, IK10, NEMA 250 Type 4X rated
Mounting Supports internal and external vehicle installation
Power Power over Ethernet (IEEE 802.3af/at), 2.2 W typical, 3.8 W max
Connectors RJ45 or M12 rugged Ethernet connector (with PoE)
Storage Supports microSD/microSDHC/microSDXC cards with encryption; NAS supported
Operating Temperature -30 °C to 55 °C (up to 70 °C intermittently)
Dimensions Diameter: 110 mm, Height: 50 mm
Weight 241 g
Languages English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Warranty 5-year warranty

Q&A

Q: Does this camera work alone?
A: No, it requires a compatible AXIS Q60-E PTZ camera for operation.

Q: Can I change the lenses?
A: Yes, it supports exchangeable and tiltable autofocus lenses.

Q: Is it suitable for outdoor use?
A: Yes, it’s IP66, IK10, and NEMA 4X-rated for harsh weather conditions.

Q: What’s the benefit of using Autopilot?
A: It enables automatic PTZ tracking of moving objects within the 360° field.

Q: Will it work with my existing Q60-E setup?
A: Yes, it shares the same bracket, power, and network cable for easy integration.
