The Axis Q6075-E is a rugged, high-speed PTZ camera built for extreme outdoor surveillance, offering crystal-clear HDTV 1080p resolution, 40x optical zoom, and advanced analytics-ready capabilities. Perfect for city surveillance, transportation hubs, and perimeter protection, this camera delivers sharp, detailed views day or night—even in challenging weather conditions. Engineered with Axis’ Lightfinder and Speed Dry technologies, it excels in low-light scenarios and offers fast focus during rain or moisture exposure. Its durable IP66-rated casing and built-in cybersecurity features ensure dependable performance in demanding environments.
Features
-
40x Optical Zoom – Capture fine details like faces and license plates from long distances.
-
Autotracking 2 with Orientation Aid – Smart follow and tracking of moving targets across wide areas.
-
Axis Lightfinder Technology – Delivers full-color images in near darkness, ideal for 24/7 monitoring.
-
Electronic Image Stabilization – Reduces blur from wind or vibrations, critical for pole or mast-mounted setups.
-
IK10, IP66, NEMA 4X Rated Housing – Resists impacts, heavy rain, snow, and dust for uninterrupted performance.
-
High-Speed Pan/Tilt Mechanism – Cover large zones quickly with ultra-smooth motion and instant responsiveness.
-
Advanced Security Features – Signed firmware, secure boot, and Axis Edge Vault for robust cybersecurity.
-
Zipstream with H.264/H.265 – Reduces bandwidth and storage usage without compromising video quality.
-
Built for Public Surveillance – Ideal for parking lots, airports, stadiums, industrial sites, and city streets.
Downloads
Extra Info
Precision Control in Every Condition
The Q6075-E’s high-speed PTZ mechanism gives operators the power to zoom in quickly and follow activity smoothly across a scene. Whether monitoring traffic, tracking a suspicious individual, or scanning a perimeter, this camera responds instantly with pinpoint accuracy.
Exceptional Low-Light Imaging
Using Axis Lightfinder, the Q6075-E can capture detailed color video in near-total darkness without switching to black-and-white mode. This gives security teams greater context at night, from identifying clothing color to recognizing vehicles.
Engineered for Harsh Environments
With its NEMA 4X, IP66, and IK10 ratings, this camera is designed to withstand everything from high winds and snow to vandal attacks. Its built-in heater and dehumidifying membrane ensure reliable operation even in sub-zero conditions.
Efficient, Secure Streaming
The camera uses Axis Zipstream, supporting both H.264 and H.265, which significantly reduces storage and bandwidth while maintaining high-quality footage—especially important for 24/7 surveillance in high-traffic areas.
Smarter Surveillance with Autotracking 2
Autotracking 2 automatically detects and follows moving objects, giving operators greater situational awareness with less manual input. Combined with Orientation Aid, it makes navigating large outdoor spaces intuitive and efficient.
Tech Specs
| Camera Image Sensor |
1/2.8" progressive scan CMOS |
| Min Illumination |
Color: 0.1 lux (50 IRE, F1.6)
B/W: 0.01 lux (50 IRE, F1.6) |
| Shutter Speed |
1/30000 s to 1/3 s |
| Lens |
4.25–170 mm, F1.6–4.95
Horizontal field of view: 63.4°–1.8°
Vertical field of view: 38.3°–1.0° |
| Optical Zoom |
40x |
| Digital Zoom |
12x |
| Pan Range |
360° endless |
| Tilt Range |
−20° to +90° |
| Pan Speed |
0.05°/s to 450°/s |
| Tilt Speed |
0.05°/s to 450°/s |
| Video Compression |
H.264 (Baseline, Main, High profiles)
H.265 (Main profile)
Motion JPEG |
| Resolution |
1920x1080 (HDTV 1080p) to 320x180 |
| Frame Rate |
Up to 50/60 fps (50/60 Hz) |
| Video Streaming |
Multiple individually configurable streams
Controllable frame rate and bandwidth
VBR/MBR H.264/H.265 |
| Image Settings |
Compression, color, brightness, sharpness,
white balance, exposure control, exposure zones,
WDR: Forensic Capture 120 dB
Dynamic contrast, tone mapping
Text/image overlay, privacy masks |
| Day/Night Functionality |
Automatically removable IR-cut filter |
| PTZ Features |
100 preset positions
Tour recording and guard tours
Autotracking 2, Orientation Aid
Click-in-image, focus recall
Advanced gatekeeper
PTZ limits |
| Video Analytics |
Autotracking 2
Motion detection
Object counting
Audio detection
Support for AXIS Camera Application Platform |
| Audio |
Two-way audio
Audio input/output
AAC-LC, G.711, G.726 |
| Network Protocols |
IPv4/IPv6, HTTP, HTTPS, SSL/TLS, QoS, FTP, SFTP,
CIFS/SMB, SMTP, Bonjour, UPnP™, SNMP v1/v2c/v3,
DNS, NTP, RTSP, RTP, TCP, UDP, IGMP, DHCP, ARP,
SOCKS, SSH, LLDP, MQTT |
| Security Features |
Signed firmware
Secure boot
Axis Edge Vault with TPM module
IEEE 802.1X, HTTPS, password protection |
| Operating Conditions |
−40°C to 50°C (−40°F to 122°F)
Humidity 10–100% RH (condensing) |
| Storage |
SD/SDHC/SDXC slot
Support for encryption and recording
Network-attached storage (NAS) |
| Power |
High Power over Ethernet (High PoE)
Midspan included (60 W) |
| Power Consumption |
Typical: 21.3 W
Max: 60 W |
| Casing |
Aluminum, IP66, IK10, NEMA 4X rated
Clear polycarbonate dome with hard coating |
| Dimensions |
Ø 236 x 295 mm (Ø 9.3 x 11.6 in) |
| Weight |
3.0 kg (6.6 lb) |
| Included Accessories |
Installation guide
Windows decoder 1-user license
Drill template, cable gaskets
Axis High PoE midspan 1-port (60 W) |
| Warranty |
5-year Axis warranty |
Q&A
Q: Can the Axis Q6075-E be used in extreme weather conditions?
A: Yes, it’s rated IP66, IK10, and NEMA 4X for protection against dust, water, impacts, and harsh weather, including snow, rain, and wind.
Q: How far can the camera zoom in clearly?
A: The Q6075-E has a 40x optical zoom, enabling clear views of distant objects like license plates or people hundreds of feet away.
Q: Does this camera work well at night?
A: Absolutely. With Axis Lightfinder, it captures full-color video even in very low-light conditions, making it ideal for night surveillance.
Q: What security features are included?
A: It includes signed firmware, secure boot, and Axis Edge Vault to ensure hardware integrity and prevent unauthorized access.
Q: What kind of areas is this camera best for?
A: It’s ideal for wide-area surveillance such as airports, city streets, stadiums, industrial zones, parking lots, and critical infrastructure.
