The Axis Q6078-E is a high-performance 4K Ultra HD PTZ network camera built for demanding outdoor surveillance environments. With a powerful 40x optical zoom, fast and accurate pan/tilt/zoom control, and crystal-clear imaging day or night, it’s engineered for large-area monitoring like city surveillance, airport terminals, and industrial sites — as well as high-end residential properties seeking serious coverage.
Built for the harshest climates and equipped with smart analytics, this camera offers unmatched situational awareness and detail from a distance — all while reducing bandwidth and storage with advanced compression.
Features
-
Ultra HD 4K Resolution – Captures extremely fine details for reliable identification at long distances.
-
40x Optical Zoom Lens – See clearly across large areas like parking lots, perimeters, or campuses.
-
Axis Lightfinder 2.0 – Delivers full-color video in near-darkness without needing extra lighting.
-
Axis Zipstream with H.265 – Cuts bandwidth and storage use without compromising image quality.
-
Arctic Temperature Control – Operates from -40°C to 50°C, perfect for exposed outdoor setups.
-
Built-in Cybersecurity Tools – Protects your video stream with signed firmware and secure boot.
-
Shock Detection & Vandal Resistance – Durable enough for public and high-risk environments.
-
Intelligent Video Analytics – Enables reliable detection, tracking, and classification of people and vehicles.
-
High-Speed PTZ Performance – Instantly reposition the camera to follow incidents in real time.
Downloads
Extra Info
Lightfinder 2.0 for True Color at Night
The Axis Q6078-E uses Lightfinder 2.0 technology to produce bright, color-accurate video in extremely low light — ideal for locations where lighting is limited but identification is critical. Whether monitoring a gated driveway at night or watching a dimly lit construction site, you’ll get clarity without the need for extra lighting.
Advanced Zoom & Scene Coverage
With a 40x optical zoom and high-resolution 4K sensor, this camera excels at wide-area surveillance with the ability to zoom in on specific incidents without losing clarity. Monitor a full city block or zoom into a license plate from far across a parking lot — all from a single mounted position.
Reliable Performance in Any Climate
Arctic Temperature Control ensures startup in extreme cold down to -40°C. With IP66, NEMA 4X, and IK10 ratings, it’s protected against water, dust, wind, and physical impact — making it perfect for exposed, vulnerable outdoor installations.
Smarter Surveillance with Built-In Analytics
Axis Object Analytics lets you automatically detect and classify people and vehicles. You can set virtual trip wires or zones, reducing false alarms and improving situational awareness without relying on third-party software.
Secure, Efficient Video Streaming
Axis Zipstream with H.265 ensures you retain high-quality footage while significantly reducing your bandwidth and storage demands — ideal for large systems or remote storage setups.
Tech Specs
| Camera Image Sensor |
1/1.8" progressive scan CMOS |
| Lens |
Motorized varifocal
Focal length: 6.25–250 mm
Horizontal field of view: 63.4°–2.00°
Vertical field of view: 37.6°–1.13°
Maximum aperture: F1.5–F4.85 |
| Optical Zoom |
40x |
| Minimum Illumination |
Color: 0.18 lux (30 IRE, F1.5)
B/W: 0.01 lux (30 IRE, F1.5) |
| Shutter Speed |
1/66500 s to 1 s |
| Pan/Tilt Range |
Pan: 360° endless
Tilt: -90° to +90° |
| Pan/Tilt Speed |
Pan: 0.05°/s to 700°/s
Tilt: 0.05°/s to 500°/s |
| Preset Positions |
256 |
| Day/Night Functionality |
Automatically removable IR-cut filter |
| Video Compression |
H.264 (MPEG-4 Part 10/AVC)
H.265 (HEVC)
Motion JPEG |
| Resolution |
3840x2160 to 160x90 |
| Frame Rate |
Up to 25/30 fps (50/60 Hz) in all resolutions |
| Video Streaming |
Multiple, individually configurable streams
Controllable frame rate and bandwidth
Axis Zipstream technology in H.264 and H.265 |
| Image Settings |
Compression, color, brightness, sharpness, white balance, exposure control,
exposure zones, fine tuning of behavior at low light, rotation, text and image overlay,
dynamic text, 3D privacy masking |
| Wide Dynamic Range |
120 dB WDR – Forensic Capture |
| Electronic Image Stabilization |
Yes |
| Audio Support |
Two-way audio via AXIS T91A03 Audio and I/O Interface (sold separately) |
| Event Triggers |
Analytics, edge storage events, input signal, manual trigger, PTZ preset, virtual inputs |
| Event Actions |
Record video, send notifications, email, HTTP, TCP, capture to edge storage |
| Built-in Analytics |
Axis Object Analytics
Autotracking 2
Motion detection
Audio detection
Shock detection
Tampering alarm |
| Storage Options |
MicroSD/microSDHC/microSDXC slot
Support for recording to NAS (Network Attached Storage) |
| Operating Conditions |
-40°C to 50°C (-40°F to 122°F)
Humidity 10–100% RH (condensing) |
| Arctic Temperature Control |
Ensures safe start-up down to -40°C (-40°F) |
| Outdoor Rating |
IP66, NEMA 4X, IK10 |
| Casing |
Aluminum and polycarbonate
Color: White NCS S 1002-B |
| Power Requirements |
High PoE (IEEE 802.3bt Type 4 Class 8)
Max 74 W |
| Connectors |
RJ45 with High PoE |
| Dimensions |
Height: 233 mm (9.2 in)
Diameter: 160 mm (6.3 in) |
| Weight |
3.1 kg (6.8 lb) |
| Certifications |
IEC/EN/UL 60950-22, 62368-1
FCC Part 15 Subpart B, ICES-003 Class A
EN 55032 Class A, EN 55035
EN 50121-4, EN 61000-6-1, -6-2, -6-3, -6-4 |
| Included Accessories |
Installation guide, Windows decoder 1-user license, Cable gaskets |
| Optional Accessories |
AXIS T91 mounting accessories, AXIS Surveillance Cards, AXIS T91A03 Audio & I/O Interface |
Q&A
Q: Is this camera suitable for residential use or only for commercial setups?
A: While it’s built for large-scale environments, homeowners who want advanced monitoring — such as for large estates or gated communities — can also benefit from the powerful zoom, low-light clarity, and weather resistance.
Q: Can this camera operate in snow or extreme heat?
A: Yes. With Arctic Temperature Control, the Q6078-E starts up and functions in temperatures as low as -40°C and as high as 50°C, making it ideal for extreme weather conditions.
Q: Does it support smart motion detection or analytics?
A: Yes. It comes with Axis Object Analytics, enabling you to set rules for detecting people or vehicles and triggering alerts based on movement patterns.
Q: Is the camera secure from cyber threats?
A: Absolutely. The camera includes signed firmware, secure boot, and other cybersecurity features designed to protect the integrity of your video feed.
Q: What kind of mounting does it support?
A: The Q6078-E is designed for flexible ceiling and wall mounts. It can be installed on poles, corners, or parapets with Axis accessories (sold separately).
