**Camera** |
|
Image Sensor |
Visual: 1/2.8” CMOS, Thermal: 640x480 uncooled microbolometer |
Lens |
Visual: 4.3–137.6 mm, F1.4–4.0 (32× optical zoom); Thermal: 35–105 mm athermalized, F1.6 |
Field of View |
Visual: H: 58.5°–2.4° / V: 35°–1.3°; Thermal: H: 18°–6° / V: 13.5°–4.5° |
Day/Night |
Visual: IR-cut filter automatically removable |
Minimum Illumination |
Visual Color: 0.06 lux (50 IRE), B/W: 0.01 lux; Thermal NETD: <50 mK |
IR Illumination |
Not applicable (uses thermal for dark conditions) |
Shutter Speed |
1/66500 s to 2 s |
PTZ Capabilities |
360° endless pan, Tilt: –90° to +45°, 256 presets, ±0.01° precision |
SoC |
ARTPEC-7 |
Memory |
2048 MB RAM, 512 MB Flash |
**Video** |
|
Compression |
H.264 (Baseline/Main/High), H.265 (Main), Motion JPEG |
Resolutions |
Visual: Up to 1920x1080; Thermal: 640x480 (scaled to 800x600) |
Frame Rate |
Visual: Up to 60 fps; Thermal: Up to 8.3 fps |
Streaming |
Multiple configurable streams; Zipstream (H.264/H.265); VBR/ABR/MBR |
WDR |
Forensic WDR: Up to 120 dB |
Image Settings |
Contrast, brightness, sharpness, defog, overlay, privacy mask (32), tone mapping |
PTZ Functions |
Guard tours, directional indicators, preset recall, focus window |
**Audio** |
|
Audio Input/Output |
3.5 mm mic/line-in; Audio in (simplex); Noise and echo cancellation |
Audio Encoding |
LPCM, AAC-LC, G.711, G.726, Opus |
**Network** |
|
Protocols |
IPv4/6, HTTP/2, HTTPS, TLS, FTP, SFTP, SNMP, RTSP, RTP, MQTT, mDNS, LLDP, CDP |
Connectors |
SFP slot, RJ45 (10/100/1000BASE-T), terminal block I/O, 3.5 mm audio in |
Security |
IP filtering, IEEE 802.1X, TLS 1.2/1.3, HTTPS/HSTS, MACsec, NTS, Edge Vault, TPM 2.0 |
**System Integration** |
|
API |
VAPIX, ONVIF (G/M/S/T), ACAP, SIP (VoIP integration) |
Event Triggers |
Audio, video motion, PTZ, I/O, temperature, storage, system status |
Event Actions |
Recording, notifications, IR control, MQTT publish, FTP/email upload |
Built-in Tools |
Pixel counter, focus assistant |
**Analytics** |
|
Included |
AXIS Motion Guard, Fence Guard, Loitering Guard, Orientation Aid PTZ, audio detection |
Object Detection |
Human presence, vehicle detection, custom analytics via ACAP |
Advanced Features |
Autotracking, scheduling, overlays, SNMP traps, WDR modes |
**Cybersecurity** |
|
Software Security |
Signed firmware, password protection, brute-force delay, SD card encryption |
Hardware Security |
Secure boot, TPM 2.0, Edge Vault, signed video, encrypted keystore |
Network Security |
IEEE 802.1X, HTTPS, TLS 1.2/1.3, MACsec, NTS, X.509 PKI |
**General** |
|
Casing |
IP66, IK10, NEMA 4X-rated aluminum, UV-stabilized thermoplastic shield |
Power |
20–28 V AC/DC; Typical 16 W, Max 204 W |
Storage |
microSD/microSDXC (encrypted), NAS support |
Operating Conditions |
–40 °C to 55 °C; Humidity 10–100% RH; Wind up to 52 m/s |
Dimensions |
244 × 360 × 582 mm |
Weight |
Approx. 15.1 kg (Zoom model) |
Languages |
EN, DE, FR, ES, IT, RU, ZH (Simplified/Traditional), JA, KO, PT, PL, TR, TH, VI |
Warranty |
5-year warranty |
