The Axis Q9307-LV is a compact, vandal-resistant dome camera built for high-traffic indoor environments that demand proactive security. Designed with advanced AI-based analytics, cybersecurity features, and reliable low-light performance, it’s an ideal choice for schools, public transport stations, retail, and government facilities. With built-in microphone and speaker, it supports two-way communication, deterrence, and remote interaction. Its unobtrusive design blends seamlessly into any environment, making it a smart, effective choice for 24/7 indoor monitoring.
Features
-
Built-In Deep Learning Analytics – Detect intrusions, loitering, and unusual motion with precision, reducing false alarms.
-
Enhanced Cybersecurity – Secure boot, signed firmware, and TPM module protect against cyber threats and unauthorized access.
-
Integrated Audio – Includes microphone and speaker for real-time communication or automated voice alerts.
-
Lightfinder 2.0 Technology – Delivers sharp, color images even in near darkness for around-the-clock clarity.
-
Forensic Wide Dynamic Range (WDR) – Maintains detail in scenes with extreme light contrast, ideal for entryways or lobbies.
-
Compact and Vandal-Resistant – IK10-rated dome resists tampering, perfect for high-risk public environments.
-
Zipstream with H.264/H.265 – Reduces bandwidth and storage usage while preserving video quality.
-
Fixed Wide-Angle Lens – Covers more area with fewer blind spots, reducing camera count in installations.
-
Q9300 Series Reliability – Part of Axis’ premium line with long-term firmware support and industrial-grade components.
Downloads
| Datasheet |
AXIS Q9307-LV Dome Camera
|
| Installation Guide |
Installation guide AXIS Q9307 LV Dome Camera
|
Extra Info
Smarter Surveillance with Deep Learning
The Axis Q9307-LV features a powerful deep learning processing unit (DLPU), enabling advanced analytics directly on the device. This includes real-time object classification and behavioral analysis — making it ideal for detecting threats before they escalate. Unlike basic motion detection, it can distinguish between people, vehicles, and irrelevant motion like tree branches or passing shadows.
Cybersecure by Design
Security isn’t just physical. The Q9307-LV includes advanced cybersecurity tools like signed firmware, secure boot, and a built-in TPM (Trusted Platform Module) to ensure your camera hasn’t been tampered with. These features provide peace of mind for institutions handling sensitive data or operating in regulated environments.
Reliable Footage, Day or Night
With Lightfinder 2.0, the Q9307-LV delivers true color footage even in challenging low-light conditions, helping identify key details like clothing color or faces. Combined with Forensic WDR, this makes the camera highly effective in locations with large windows or mixed lighting.
Built for Demanding Spaces
The camera’s compact, tamper-resistant form factor is ideal for use in public indoor areas like buses, subways, government offices, and healthcare facilities. The microphone and speaker support two-way communication for remote warnings, access control, or assistance.
Tech Specs
| Camera Model |
Axis Q9307-LV |
| Image Sensor |
1/2.7" Progressive scan RGB CMOS |
| Lens |
Fixed lens
Focal length: 2.4 mm
Horizontal field of view: 111°
Vertical field of view: 61° |
| Minimum Illumination |
Color: 0.05 lux at 1/30 s (50 IRE, F2.0)
Black & white: 0.01 lux at 1/30 s (50 IRE, F2.0) |
| Shutter Speed |
1/66500 s to 1/2 s |
| Camera Angle Adjustment |
Pan: 180°
Tilt: 55°
Rotation: 180° |
| Video Compression |
H.264 (MPEG-4 Part 10/AVC), Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC), Main Profile
Motion JPEG |
| Resolutions |
2592x1944 to 160x120 |
| Frame Rate |
Up to 30 fps in all resolutions (WDR off)
Up to 25 fps (WDR on) |
| Video Streaming |
Multiple, individually configurable streams
Axis Zipstream technology in H.264 and H.265 |
| Image Settings |
Color, brightness, sharpness, contrast, local contrast, white balance, exposure control, exposure zones, compression, dynamic text and image overlay, mirroring, rotation, day/night shift level |
| Wide Dynamic Range |
Forensic WDR |
| Low Light Technology |
Axis Lightfinder 2.0 |
| Audio |
Two-way audio
Built-in microphone (digital MEMS)
Built-in speaker (mono)
Frequency range: 200 Hz – 7 kHz
Max sound pressure level: 80 dB at 0.5 m |
| Audio Streaming |
Full duplex
Audio encoding: AAC-LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz |
| Network Interface |
1x RJ45 10/100 Mbps |
| Security |
Signed firmware, secure boot, Axis Edge Vault, TPM (FIPS 140-2 level 2 certified), HTTPS, network authentication, IEEE 802.1X |
| Edge Storage |
MicroSD/microSDHC/microSDXC card slot
Support for recording to network-attached storage (NAS) |
| Operating Conditions |
-20 °C to 50 °C
(-4 °F to 122 °F)
Humidity: 10–85% RH (non-condensing) |
| Storage Conditions |
-40 °C to 65 °C
(-40 °F to 149 °F) |
| Power |
Power over Ethernet (PoE) IEEE 802.3af Type 1 Class 3
Typical: 3.9 W
Maximum: 7.7 W |
| Casing |
Polycarbonate dome, aluminum base
Color: White NCS S 1002-B |
| Dimensions |
Height: 53 mm (2.1 in)
Diameter: 101 mm (4.0 in) |
| Weight |
370 g (0.82 lb) |
| Approvals |
EMC: EN 55032 Class A, EN 55035, EN 50121-4, IEC 62236-4, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KN35
Safety: IEC/EN/UL 62368-1
Environment: IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-30
IEC/EN 62262 IK10
IEC/EN 60529 IP42 (mounted on ceiling) |
| Sustainability |
PVC free
Environmentally friendly design |
| Included Accessories |
Installation guide
Windows® decoder 1-user license
Drill template |
| Optional Accessories |
AXIS TP3801-E Adapter Plate
AXIS TP3803 Conduit Back Box
AXIS Surveillance Cards |
| Warranty |
5-year Axis warranty |
Q&A
Q: Can the Axis Q9307-LV be used in outdoor environments?
A: No, this model is designed specifically for indoor use. While it’s vandal-resistant, it’s not rated for weather exposure.
Q: Does this camera support night vision?
A: While it doesn’t have infrared LEDs, it uses Axis Lightfinder 2.0 for excellent low-light performance, capturing color images in near-darkness.
Q: What kind of analytics are built-in?
A: The Q9307-LV includes AI-powered intrusion detection, object classification (humans, vehicles), loitering detection, and more — all processed on the edge without requiring a server.
Q: Is this camera compatible with third-party VMS systems?
A: Yes. Axis cameras use open standards like ONVIF and are compatible with most major video management systems.
Q: Does it support audio recording and communication?
A: Yes, it has a built-in microphone and speaker, enabling two-way audio for real-time communication or prerecorded warnings.
