| **Camera** |
|
| Image Sensor |
1/2.8” progressive scan RGB CMOS, 0.1 lux sensitivity |
| Lens |
1.9 mm; HFOV: 140° (1080p) / 112° (720p), VFOV: 91° / 62°; F2.2 |
| Shutter Speed |
1/22000 s to 1/25 s (50 Hz), 1/22000 s to 1/30 s (60 Hz) |
| **Video** |
|
| Compression |
H.264 (High Profile) |
| Resolution |
1920×1080, 1280×720 |
| Frame Rate |
25 fps (50 Hz), 30 fps (60 Hz) |
| Features |
WDR, Electronic Image Stabilization (720p), Zipstream |
| **Audio** |
|
| Encoding |
AAC-LC |
| Input |
Built-in microphone and speaker |
| Enhancements |
Voice enhancement |
| **Connectivity** |
|
| Wireless |
Wi-Fi 5 (2.4/5 GHz), Bluetooth® 5.1 |
| Connectors |
Pogo pin pads |
| **General** |
|
| Battery |
Li-ion 1600 mAh; up to 7 hrs (720p), 5.5 hrs (1080p), 11.5 hrs standby |
| Storage |
128 GB encrypted storage (AES256), up to 45 hrs of video |
| Mounting |
AXIS TW1106 Magnet Mount included; KlickFast™ optional |
| Interface |
Status indicators, voice/audio/vibration feedback |
| Sensors |
6-axis gyroscope, accelerometer |
| Operating Conditions |
-20 °C to 45 °C; Max 50 °C (intermittent); 10–100% RH |
| Charging Conditions |
0–35 °C; 4–7.5 hrs charging time depending on temp |
| Weight |
85 g (0.19 lb); 117 g (0.26 lb) with magnet mount |
| **Approvals** |
|
| EMC |
EN 55032 B, EN 55035, EN 61000-6-1/-2, FCC Part 15 B, ICES-3(B), RCM |
| Safety |
IEC/EN/UL 62368-1 ed.3 |
| Environment |
IEC 60068 series, IP54-rated, drop tested to 1.5 m |
| Wireless |
EN/FCC/RSS compliance; see datasheet for full list |
| Cybersecurity |
ETSI EN 303 645, Edge Vault, signed video, secure boot, CJIS-compliant |
| **Sustainability** |
|
| Substance Control |
RoHS, REACH, PVC/BFR/CFR-free per JEDEC/ECA JS709 |
| Environmental Policy |
axis.com/environmental-responsibility |
