System |
Main Processor |
Embedded Processor |
Button Type |
Mechanical |
Basic |
Camera |
1/2.8" 2 MP CMOS HDR Camera |
Field of View |
H: 110°; V: 60° |
WDR |
DWDR |
Noise Reduction |
3D NR |
Video Resolution |
P: 960 (H) × 576 (V)
N: 960 (H) × 480 (V) |
Video Frame Rate |
P: 25 fps
N: 30 fps |
Light Compensation |
Auto IR |
Day/Night |
Auto(ICR)/Color/B/W |
Audio Input |
1 |
Audio Output |
Built-in speaker |
Audio Mode |
Two-way audio (half–duplex) |
Function |
Unlock Mode |
Remote unlock |
Leave Videos |
Yes (SD card inserted in VTH is needed) |
Performance |
Casing Material |
Aluminum Alloy |
Port |
RS-485 |
1 |
Alarm Output |
1 |
Power Output |
1(12 V/200 mA) |
Exit Button |
1 |
Door Status Detection |
1 |
Lock Control |
1 |
Alarm |
Tamper Alarm |
Yes |
General |
Appearance Color |
Silver |
Power Supply |
2- wire controller |
Power Adapter |
Optional |
Installation |
Flush Mount;Surface Mount |
Certifications |
CE; FCC |
Accessory |
Sold separately: surface box, rain cover, flush box, 2-wire controller |
Product Dimensions |
130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12") |
Protection |
IP65
IK07 |
Operating Temperature |
–40 °C to +60°C (–40 °F to +140 °F) |
Operating Humidity |
10%–90% (RH), non-condensing |
Operating Altitude |
0 m–3000 m (0 ft – 9842.52 ft) |
Power Consumption |
≤ 1.5 W (standby), ≤ 10 W (working) |
Gross Weight |
0.326 kg (0.72 lb) |
Storage Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
Storage Humidity |
95% (RH), non-condensing |
