System |
Main Processor |
Embedded processor |
Operating System |
Android 8.1 |
Network Protocol |
IPv4, TCP, SIP, UDP, RTSP |
Basic |
Screen Type |
Capacitive screen |
Display Screen |
10 inch TFT LCD |
Resolution |
1024×600 |
Video Compression |
H.264 |
Audio Compression |
PCM |
Audio Input |
1 omnidirectional microphone |
Audio Output |
Built-in 1.5W speaker |
Audio Mode |
Two-way voice call |
Audio Enhancement |
Echo suppression/DNR |
Audio Bit Rate |
16KHz, 16Bit |
Function |
Information Release |
Text announcements released by the management center can be viewed |
Communication Mode |
Full digital |
Elevator Control |
You can control the elevator through the indoor monitor |
Leave Videos or Text Messages |
Yes (SD card is needed) |
DND Mode |
Do not disturb period can be set. |
Extension Number |
Villa: 4
Apartment: 9
|
Wi-Fi |
Yes |
Wireless Standard |
IEEE802.11b/802.11g/802.11n |
Wireless Frequency Range |
2.4GHz |
Wireless Security-Encryption |
64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Storage |
Micro SD storage, the maximum space is 256GB |
Port |
RS-485 |
1 |
Alarm Input |
8 |
Alarm Output |
1 |
Power Output |
1 12V/100mA |
Door Bell |
Yes, use alarm input port |
Network Port |
1 10M/100M Ethernet |
Alarm |
SOS |
Yes |
Performance |
Housing Material |
PC+ABS |
Regular |
Color |
Black |
Power Supply |
12V DC 1A
Standard POE |
Installation |
Surface mount |
Certifications |
CE
FCC |
Accessory |
Surface mount bracket, alarm ribbon cable, RS-485 cable, and power-supply pins are provided |
Product Dimensions |
260 mm×170 mm×15 mm (10.24"×6.69"×0.59") (ports are not counted) 260 mm×170 mm×25.4 mm (convex) (10.24"×6.69"×1") (ports are counted) |
Operating Temperature |
-10°C to +55°C (+14°F to +131°F) |
Operating Humidity |
10%RH–95%RH (Non-condensing) |
Operating Altitude |
Less than 3,000 meters (9842.52 ft) |
Power Consumption |
≤1.5W (standby), ≤7W (working) |
Net Weight |
770g (1.70lb) |
Gross Weight |
1.1kg (2.43lb) |
