| Camera |
1 MP CMOS sensor, 120 dB WDR, low-light support |
| Field of View |
Horizontal: 107° • Vertical: 61° • Diagonal: 122° |
| Video Compression |
H.264 |
| Video Resolution |
Main: WVGA, 720P, D1 • Sub: CIF, WVGA, QVGA, 1080P, D1 |
| Frame Rate |
PAL: 25 fps • NTSC: 30 fps |
| Video Bit Rate |
256 Kbps – 4 Mbps |
| Light Compensation |
Auto IR with ICR auto switch |
| Audio Compression |
G.711a, G.711u, PCM |
| Audio Input/Output |
Built-in microphone and speaker |
| Audio Enhancement |
Echo suppression, digital noise reduction |
| Audio Mode |
Two-way bidirectional talk |
| Main Processor |
Embedded processor |
| Operating System |
Embedded Linux |
| Button Type |
1 mechanical call button |
| Protocols |
SIP, P2P, IPv4, DNS, RTSP, RTP, TCP, UDP |
| Unlock Modes |
IC card, DMSS app remote unlock, indoor monitor |
| Card Capacity |
Up to 10,000 cards |
| Motion Detection |
Supported |
| Tamper Alarm |
Supported |
| Interfaces |
RS-485 ×1, Electric Lock ×1, Exit Button ×1, Door Status Input ×1, RJ-45 (10/100 Mbps) |
| Casing |
PC + Acrylic, Color: Black |
| Protection |
IP65 (sealant required), IK10 vandal resistance |
| Installation |
Surface mount |
| Dimensions |
135 × 70.4 × 34.4 mm (5.31″ × 2.77″ × 1.35″) |
| Operating Temperature |
–30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity |
10%–90% RH (non-condensing) |
| Power Supply |
Standard PoE or 12 V DC 1 A |
| Power Consumption |
≤ 1 W standby, ≤ 5 W working |
| Weight |
326 g (0.72 lb) |
| Certifications |
CE, FCC, UL |
