Camera
|
|
Camera
|
|
Image Sensor
|
1/3" CMOS
|
|
Max. Resolution
|
2560 (H) × 1440 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.005 lux@F1.6 (Color,30 IRE)
0.0005 lux@F1.6 (B/W,30 IRE)
0 lux (Illuminator on)
|
| S/N Ratio |
>56 dB |
|
Illumination Distance
|
10 m (32.81 ft) (IR);
30 m (98.43 ft) (Floodlight)
|
|
Illuminator On/Off Control
|
Auto; Manual
|
|
Illuminator Number
|
1 (IR LED); 2 (Floodlight, color can be switched between
warm and cool)
|
|
Floodlight Brightness
|
1500-2400 lm
|
|
Floodlight Color
Temperature
|
3000K±200K (warm);
6000K±300K (cool) |
|
Floodlight Modes
|
Motion Activation
Manual
Schedule
PIR Activation
|
|
Pan/Tilt/Rotation Range
|
Camera:
Pan: –85° to +85°
Tilt: –90° to +45°
Rotation: 0° to +360°
Floodlight:
Tilt: –90° to +90°
Rotation: –145° to +145°
|
|
PIR Sensor Distance
|
10 m (the height of the device is 3 m, placed at an angle
of 30° from the horizontal)
|
|
PIR Detection Range
|
270°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm
|
|
Max. Aperture
|
F1.6
|
|
Field of View
|
H: 98°; V: 55°; D: 115°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
1.0 m (3.28 ft)
|
| DORI Distance |
Detect |
Observe |
Recognize |
Identify |
61.2 m
(200.79 ft) |
24.5 m
(80.38 ft) |
12.2 m
(40.03 ft) |
6.1 m
(20.01 ft) |
|
Video
|
|
Video Compression
|
H.264B; H.264; H.264H; H.265; MJPEG
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Main stream:
2560 × 1440@(1–25 fps)
2560 × 1440@(1–30 fps)
Sub stream 1:
704 × 576@(1–25 fps)
704 × 480@(1–30 fps)
Sub stream 2:
640 × 480@(1 fps–25 fps)
640 × 480@(1 fps–30 fps)
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be subjected
to the total encoding capacity
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 ×
1080); 1.3M (1280 × 960); 1M (1280 × 720); D1 (704 ×
576/704 × 480); VGA (640 × 480); CIF (352 × 288/352
× 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H264: 32 kbps–8192 kbps;
H265: 32 kbps–8192 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/180°
|
|
Privacy Masking
|
Yes
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Built-in Speaker
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; G.726; PCM
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network
disconnection; IP conflict; illegal access; security
exception; motion detection; video tampering; sence
changing; SMD (human, animal and vehicle); audio
detection; intensity change
|
|
Network
|
|
Wi-Fi
|
IEEE802.11a/b/g/n/ac 2.4–2.4835GHz & 5.18–5.85GHz
|
|
Cyber Security
|
Video encryption; configuration encryption; Digest;
WSSE; account lockout; security logs; generation and
importing of X.509 certification; HTTPS; trusted boot;
trusted execution; trusted upgrade
|
|
Storage
|
Micro SD card (support max. 256 GB); FTP; SFTP; NAS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
CE-RED: Radio Equipment Directive 2014/53/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
FCC ID: FCC PART 15C
|
|
Power
|
|
Power Supply
|
100–240 VAC
|
|
Power Consumption
|
Basic: 5.2 W (100–240 VAC )
Max. (Illuminator+IPC): 48.3 W (100–240 VAC )
|
|
Environment
|
|
Operating Temperature
|
–20 °C to +50 °C (–4 °F to +122 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Storage Temperature
|
–20 °C to +50 °C (–4 °F to +122 °F)
|
|
Protection
|
IP65
|
|
Structure
|
|
Casing
|
Metal + Plastic
|
|
Product Dimensions
|
270.7 mm × 217.2 mm × 195.6 mm (10.66" × 8.55" ×
7.70") (L × W × H)
|
|
Net Weight
|
1.40 kg (3.08 lb)
|
|
Gross Weight
|
1.88 kg (4.14 lb)
|
