Camera |
Image Sensor |
1/2.8”8Megapixel progressive CMOS |
Max. Resolution |
3840 (H) × 2160 (V) |
ROM |
128 MB |
RAM |
512 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
Min. Illumination |
0.007 Lux@F1.5 (Color, 30IRE)
0.0007 Lux@F1.5 (B/W, 30IRE)
0 Lux (Illuminator on)
|
S/N Ratio |
> 56 dB |
Illumination Distance |
40 m (131.2 ft) |
Illuminator On/Off Control |
Auto/Manual |
Illuminator Number |
2 (IR LED) |
Pan/Tilt/Rotation Range |
Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355° |
Lens |
Lens Type |
Motorized vari-focal |
Mount Type |
?14 |
Focal Length |
2.7 mm–13.5 mm |
Max. Aperture |
F1.5 |
Field of View |
Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal: 138°–36° |
Iris Type |
Fixed |
Close Focus Distance |
0.8 m (2.6 ft) |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
W |
85.3 m (279.9 ft) |
34.1 m
(111.9 ft)
|
17.0 m
(55.8 ft)
|
8.5 m
(27.9 ft)
|
T |
280.0 m (918.6 ft) |
112.0 m (367.5 ft) |
56.0 m
(183.7 ft)
|
28.0 m
(91.9 ft)
|
Professional, intelligent |
Perimeter Protection |
Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
Video |
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
Smart Codec |
Smart H.265+/ Smart H.264+ |
Video Frame Rate |
Main stream:
3840 × 2160 @(1–20 fps by default)
3840 × 2160 @(1–25/30 fps when AI function disabled)
sub stream:
704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps)
third stream:
1920 × 1080 @(1–25/30 fps)
|
Stream Capability |
3 streams |
Resolution |
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
Bit Rate Control |
CBR/VBR |
Video Bit Rate |
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
Day/Night |
Auto (ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
|
Scene Self-adaptation
(SSA)
|
Yes |
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest (RoI) |
Yes (4 areas) |
Smart Illumination |
Yes |
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.) |
Mirror |
Yes |
Privacy Masking |
4 areas |
Audio |
Audio Compression |
G.711a; G.711Mu; G726 |
Alarm |
Alarm Event |
- ZAS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
-ZS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; defocus detection; SMD; safety exception |
Network |
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
User/Host |
20 (Total bandwidth: 72 M) |
Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
Browser |
IE: IE8; IE9; IE11
Chrome
Firefox |
Management Software |
Smart PSS; DSS; DMSS |
Mobile Phone |
IOS; Android |
Certification |
Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
Port |
Audio Input |
1 channel (RCA port) (Only - ZAS supports) |
Audio Output |
1 channel (RCA port) (Only - ZAS supports) |
Alarm Input |
1 channel in: 5mA 3V–5V DC (Only - ZAS supports) |
Alarm Output |
1 channel out: 300mA 12V DC (Only - ZAS supports) |
Power |
Power Supply |
12V DC/PoE (802.3af) |
Power Consumption |
Basic power consumption: 2.7W (12V DC); 3.3W (PoE)
Max. power consumption (WDR + H.265 + IR LED intensity): 6.8W (12V DC); 8.2W (PoE)
|
Environment |
Operating Conditions |
–30°C to +60°C (–22°F to +140°F)/Less than 95% RH |
Storage Conditions |
–40°C to +60°C (–40°F to +140°F) |
Protection Grade |
IP67; IK10 |
Structure |
Casing |
Metal |
Dimensions |
88.9 mm × ?122 mm (3.5" × ?4.8") |
Net Weight |
492 g (1.1 lb) |
Gross Weight |
663 g (1.5 lb) |
