Camera |
|
Image Sensor |
1/1.8” 4Megapixel progressive scan CMOS |
Effective Pixels |
2688 (H) × 1520 (V) |
RAM/ROM |
512 MB/128 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
Minimum Illumination |
0.002 Lux@F1.6 |
IR Distance |
Distance up to 50 m (164 ft) |
IR On/Off Control |
Auto/Manual |
IR LEDs |
2 |
Lens |
|
Lens Type |
Fixed-focal |
Mount Type |
Board-in |
Focal Length |
2.8 mm, 3.6 mm, 6.0 mm |
Max. Aperture |
F1.6 |
Angle of View |
H: 113°, V: 60°/H: 89°, V: 48°/H: 56°, V: 31° |
Aperture Type |
Fixed |
Close Focus Distance |
1.3 m (4.27 ft)/1.9 m (6.23 ft)/3.8 m (12.47 ft) |
Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range |
Pan: 0?–355?; Tilt: 0?–75?; Rotation: 0?–355? |
Artificial Intelligence |
|
Face Capture |
Support face image capture |
Perimeter Protection |
Tripwire, Intrusion (Human & Vehicle classification) |
People Counting |
Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection |
General Intelligence |
|
Event Trigger |
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly |
General Intelligence |
Object Abandoned/Missing |
Video |
|
Compression |
H.265+, H.265, H.264+, H.264, H.264B, H.264H, |
Streaming Capability |
3 Streams |
Resolution |
2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
Frame Rate |
Main Stream: 2688 × 1520 (1 fps–25/30 fps) |
Bit Rate Control |
CBR/VBR |
Bit Rate |
H.264: 32 Kbps–8192 Kbps |
Day/Night |
Auto(ICR)/Color/B/W |
BLC Mode |
BLC/HLC/WDR (140 dB) |
White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detection |
Off/On (4 Zone, Rectangle) |
Region of Interest |
Off/On (4 Zone) |
Electronic Image Stabilization (EIS) |
N/A |
Smart IR |
Support |
Defog |
Support |
Digital Zoom |
N/A |
Flip |
0°/90°/180°/270° |
Mirror |
Off/On |
Privacy Masking |
Off/On (4 Area, Rectangle) |
Audio |
|
Compression |
N/A |
Network |
|
Ethernet |
RJ-45 (10/100 Base-T) |
Protocol |
HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, |
Web Viewer |
IE (versions newer than IE8), Chrome, |
Management Software |
Smart PSS, DSS, P2P |
Smart Phone |
iOS, Android |
Certifications |
|
Certifications |
CE-LVD: EN60950-1 |
Interface |
|
Video Interface |
N/A |
Audio Interface |
N/A |
RS485 |
N/A |
Alarm |
N/A |
Electrical |
|
Power Supply |
DC 12V (±30%), PoE (802.3af) (Class 0) |
Power Consumption |
<5.8W |
Environmental |
|
Operating Conditions |
-30° C to +60° C (-22° F to +140° F)/10%RH–95%RH |
Storage Conditions |
-30° C to +60° C (-22° F to +140° F) |
Ingress Protection |
IP67 |
Vandal Resistance |
IK10 |
Construction |
|
Casing |
Metal |
Dimensions |
?122.0 mm × 88.9 mm (4.80” × 3.50”) |
Net Weight |
0.45 kg (0.99 lb) |
Gross Weight |
0.61 kg (1.34 lb) |
