Smart Event |
IVS |
Tripwire; intrusion |
Video |
Video Compression |
H.265; H.264; H.264B; MJPEG (only supported by the sub stream) |
Smart Codec |
Smart H.265+/ Smart H.264+ |
Video Frame Rate |
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps)
|
Stream Capability |
2 streams |
Resolution |
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240) |
Bit Rate Control |
CBR/VBR |
Video Bit Rate |
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
|
Day/Night |
Auto(ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control |
Auto/Manual |
Noise Reduction |
3D NR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest(RoI) |
Yes (4 areas) |
Smart Illumination |
Yes |
Image Rotation |
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.) |
Mirror |
Yes |
Privacy Masking |
4 areas |
Alarm |
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; safety exception; |
Network |
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour |
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
User/Host |
20 |
Storage |
FTP; Micro SD card (support max. 256 G); NAS; SFTP |
Browser |
IE
Chrome
Firefox
|
Management Software |
Smart PSS; DSS; DMSS |
Mobile Phone |
IOS; Android |
Certification |
Certifications |
CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
Power |
Power Supply |
12V DC/PoE (802.3af) |
Power Consumption |
< 6.4W |
Environment |
Operating Conditions |
-30°C to +60°C (-22°F to +140°F)/less than ? 95% RH |
Storage Temperature |
-40°C to +60°C (-40°F to +140°F) |
Protection |
IP67 |
Structure |
Casing |
Metal |
Dimensions |
108.3 mm × ?122 mm (4.26" × ?1.80") |
Net Weight |
0.69 kg (1.52 lb) |
Gross Weight |
0.88 kg (1.94 lb) |
