Description
Launched by Dahua Technology, WizSense is a series of wide-range AI products and solutions that adopt independent AI chips and deep learning algorithms. It can recognize humans and vehicles in an image with high accuracy, enabling users to focus on real targets. WizSense focuses on humans and vehicles, benefiting everyone with intelligent functions, simple configuration and inclusive products.
SMD 3.0: With intelligent algorithm, Dahua Smart Motion Detection technology
can categorize the targets that trigger motion detection and filter the
motion detection alarm triggered by non-concerned targets to realize
effective and accurate alarm
WizSense Series - Engineered to provide smart, simple and affordable security. WizSense series cameras support an independent AI chip with a deep learning algorithm to provide a more intelligent and simple security solution focused on human and vehicle detection. This helps filter out false alerts triggered by bugs, changes in light, leaves, trees and animals.
Supports Smart Motion Detection Plus (SMD+) dramatically reduces false alarms in motion detection by only detecting humans and vehicles, greatly reducing false alerts triggered by bugs, changes in light, leaves, trees and animals. Target is tracked and triggers real-time alerts to a smart device through the iOS/Android app.
Through advanced video algorithms, Dahua's Intelligent Video Surveillance (IVS) technology supports smart functions such as Tripwire and Intrusion Detection.
Starlight technology generates clear images in near-complete darkness. A high-performing sensor and special algorithms work together to capture images in low-light and no-light environments.
Features
- 2MP 1/2.8" CMOS image sensor, low luminance, and high definition image.
- Outputs max. 2MP (1920 × 1080)@25/30 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in IR LED, and the max. illumination distance is 50 m.
- ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
- Abnormality detection: Motion detection, privacy masking, no SD card, SD card full, SD card error, network disconnection, IP conflict, and illegal access
- Support low power push alarm function; support the intergration of solar energy.
- Support the camera to get the power information through 485 link, and OSD overlay display.
- Alarm: 2 in,2 out; audio: 1 in, 1 out; 1 RS-485; supports max. 256 G Micro SD card.
- 12 VDC power supply.
- IP67 protection.
- SMD 3.0.
Downloads
Tech Specs
Camera |
Image Sensor |
1/2.8” CMOS |
Effective Pixels |
1920 (H) × 1080 (V) |
ROM |
128 MB |
RAM |
512 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
Min. Illumination |
0.002 Lux@F1.6(Color,30IRE)
0.0002 Lux@F1.6(B/W,30IRE)
0 lux (Illuminator on)
|
S/N Ratio |
> 56 dB |
Illumination Distance |
50 m (273 ft) (IR) |
Illuminator On/Off Control |
Auto; Manual |
Illuminator Number |
2 (IR LED) |
Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: –60°–0°
Rotation: 0°–360°
|
Lens |
Lens Type |
Fixed-focal |
Mount Type |
M12 |
Focal Length |
2.8mm; 3.6mm; 6mm |
Max. Aperture |
2.8mm:F1.6
3.6mm:F1.6
6mm:F1.6
|
Field of View |
2.8 mm: Horizontal 107° × Vertical 56° × Diagonal 127°
3.6 mm: Horizontal 88° × Vertical 44° × Diagonal 105°
6 mm: Horizontal 54° × Vertical 29° × Diagonal 63°
|
Iris Type |
Fixed |
Close Focus Distance |
2.8 mm: 0.7 m (2.5 ft)
3.6 mm: 1.3 m (4.25 ft)
6 mm: 2.8 m (9.15 ft)
|
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
2.8 mm |
43.9 m
(144 ft)
|
17.5 m
(57.4 ft)
|
8.8 m
(28.8 ft)
|
4.4 m
(14.4 ft)
|
3.6 mm |
58.9 m
(193 ft)
|
23.6 m
(77.4 ft)
|
11.8 m
(38.4 ft)
|
5.9 m
(19.4 ft)
|
6 mm |
88.3 m
(289.6 ft)
|
35.3 m
(115.8 ft)
|
17.7 m
(58 ft)
|
8.8 m
(28.8 ft)
|
Professional, Intelligent |
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
SMD 3.0 |
Less false alarm, longer detection distance |
IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
Video |
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
Smart Codec |
Smart H.265+; Smart H.264+ |
AI Coding |
AI Coding AI H.265; AI H.264 |
Video Frame Rate |
Main stream: 1920 × 1080@(1 fps–30 fps)
Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
Third stream:1920 × 1080@(1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
Stream Capability |
3 streams |
Resolution |
1080p (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288) |
Bit Rate Control |
CBR; VBR |
Video Bit Rate |
H.264:512kbps -8192kbps
H.265:256kbps -7424kbps
|
Day/Night |
Auto (ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
Gain Control |
Auto; manual |
Noise Reduction |
3D NR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest (RoI) |
Yes (4 areas) |
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower) |
Mirror |
Yes |
Privacy Masking |
8 areas |
Audio |
Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
Built-in MIC |
Yes |
Alarm |
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
Network |
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
Network Protocol |
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
User/Host |
20 (Total bandwidth: 64 M) |
Storage |
FTP;SFTP; Micro SD card (support max. 256 GB); NAS |
Browser |
IE: IE8/9/11
Chrome
Firefox
|
Management Software |
Smart PSS;DSS;DMSS |
Mobile Client |
iOS;Android |
4G |
4G_LTE: B1/B3/B5/B7/B8/B20/B28/B38/B40/B41
3G_WCDMA : B1/B5/B8
2G_GSM :B3/B5/B8
|
Certification |
Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
|
Port |
RS-485 |
1 (baud rate range:1200 bps–115200 bps) |
Audio Input |
1 channel (RCA port) |
Audio Output |
1 channel (RCA port) |
Alarm Input |
2 channels in: 5 mA 3 V–5 VDC |
Alarm Output |
2 channels out: 300 mA 12 VDC |
Power |
Power Supply |
12 VDC |
Power Consumption |
Basic: 3.3 W (12 VDC);
Max. (WDR+H.265+IR+4G): 5.9W (12 VDC)
|
Environment |
Operating Temperature |
–30 °C to +60 °C (–22 °F to +140 °F) |
Operating Humidity |
≤ 95% |
Storage Temperature |
–30 °C to +70 °C (–22 °F to +163 °F) |
Protection |
IP67 |
Structure |
Casing |
Metal + plastic |
Dimensions |
227.6 mm × 204.2mm × 87.2 mm (9.0" × 8.0" × 3.4") |
Net Weight |
945 g (2.1 lb) |
Gross Weight |
1440 g (3.1 lb) |
