Camera |
Image Sensor |
1/2.7”5Megapixel progressive CMOS |
Max. Resolution |
2592 (H) ×1944 (V) |
ROM |
128 MB |
RAM |
512 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
Min. Illumination |
0.005 Lux@F1.6 (Color, 30IRE)
0.0005 Lux@F1.6 (B/W, 30IRE)
0 Lux (Illuminator on)
|
S/N Ratio |
> 56 dB |
Illumination Distance |
50 m (164.0 ft) |
Illuminator On/Off Control |
Auto/Manual |
Illuminator Number |
2 (IR LED) |
Pan/Tilt/Rotation Range |
Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360° |
Lens |
Lens Type |
Fixed-focal |
Mount Type |
M12 |
Focal Length |
2.8 mm; 3.6 mm; 6 mm |
Max. Aperture |
F1.6 |
Field of View |
2.8 mm: Horizontal:98°; vertical: 72°; diagonal: 130°
3.6 mm: Horizontal:80°; vertical: 59° ; diagonal: 106°
6 mm: Horizontal:50°; vertical: 36°; diagonal: 64° |
Iris Type |
Fixed |
Close Focus Distance |
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.3 ft)
6 mm: 3.2 m (10.5 ft) |
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
2.8mm |
56.0 m
(183.7 ft)
|
22.4 m
(73.5 ft)
|
11.2 m
(36.8 ft)
|
5.6 m
(18.4 ft)
|
3.6mm |
80.0 m
(262.5 ft)
|
32.0 m
(105.0 ft)
|
16.0 m
(52.5 ft)
|
8.0 m
(26.3 ft)
|
6mm |
120.0 m (393.7 ft) |
48.0 m
(157.5 ft)
|
24.0 m
(78.7 ft)
|
12.0 m
(39.4 ft)
|
Professional, Intelligent |
Perimeter Protection |
Tripwire; intrusion (Recognition of human and vehicle) |
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
Video |
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG(only supported
by sub stream)
|
Smart Codec |
Smart H.265+/ Smart H.264+ |
Video Frame Rate |
Main stream (2592 × 1944@1–20 fps)
(2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream (1280 × 720@1–25/30 fps)
|
Stream Capability |
3 streams |
Resolution |
5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
Bit Rate Control |
CBR/VBR |
Video Bit Rate |
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps |
Day/Night |
Auto(ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest(RoI) |
Yes (4 areas) |
Smart Illumination |
Yes |
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.) |
Mirror |
Yes |
Privacy Masking |
4 areas |
Audio |
Built-in MIC |
Yes |
Audio Compression |
G.711a; G.711Mu; G726 |
Alarm |
Alarm Event |
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD |
Network |
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP |
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
Interoperability |
ONVIF(Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
Scene Self-adaptation (SSA) |
Yes |
User/Host |
20 (Total bandwidth: 64M) |
Storage |
FTP; SFTP; Micro SD Card (support max. 256 G); NAS |
Browser |
IE: IE8, IE9, IE11
Chrome
Firefox
|
Management Software |
Smart PSS, DSS, DMSS |
Mobile Phone |
IOS; Android |
Certification |
Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
Power |
Power Supply |
12V DC/PoE (802.3af) |
Power Consumption |
<8.1W |
Environment |
Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than 95% |
Storage Conditions |
-40°C to +60°C (-40°F to +140°F) |
Protection Grade |
IP67 |
Structure |
Casing |
Inner core: Metal
Cover: Metal
Decoration ring: Plastic
|
Dimensions |
99.1 mm × ?121.9 mm (3.9" × ?4.8") |
Net Weight |
480 g (1.05 lb) |
Gross Weight |
660 g (1.45 lb) |
