Grandstream 802.11ac Wave-2 3×3:3Enterprise Wi-Fi Access Point - GWN7615

Description

Description

The GWN7615 include support for advanced QoS, low-latency real-time applications, mesh networks , captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7615 can be us ed to create a scalable solution as big or small as needed for the deployment scenario, from office buildings to reta il locations, hotels and more.To ensure easy installation and management, the GWN7615 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7615 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management pl atforms. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstr eam’s Wi-Fi-capable IP phones.

Features

  • 1.75Gbps aggregate wireless throughput and 2x Gigabit wireline ports
  • Dual-band 3x3:3 MU-MIMO technology
  • Self power adaptation upon auto detection of PoE or PoE+
  • Support 200+ concurrent Wi-Fi client devices
  • Up to 175-meter coverage range
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premisebased software controller
  • 3 Year Warranty
Datasheet
Tech Specs

Grandstream 802.11ac Wave-2 3×3:3Enterprise Wi-Fi Access Point - GWN7615

Wi-Fi Standards IEEE 802.11 a/b/g/n/ac (Wave-2)
Antennas 3 dual band internal antennas
2.4GHz, gain 3dBi
5 GHz, gain 3dBi
Wi-Fi Data Rates IEEE 802.11ac: 6.5 Mbps to 1300Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 450 Mbps
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between
devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands 2.4 GHz Radio: 2412 – 2484 MHz
5 GHz Radio: 5180-5825 MHz
Channel Bandwidth 2.4G: 20 and 40MHz
5G: 20, 40, and 80MHz
Wi-Fi and System Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control
lockdown via digital signatures, unique security certificate and random default password per
device
MIMO O 3×3:3 2.4G(MIMO)
3×3:3 5G(MU-MIMO)
Coverage Range Up to 175 meters
*coverage range can vary based on environmen
Maximum TX Power 2.4G: 26 dBm
5G: 24 dBm
*Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity 2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:-
63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
SSIDs 2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:-
63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
Concurrent Clients 200+
Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock
Mounting Indoor wall mount or ceiling mount, kits included
LEDs 3 x tri-color LEDs for device tracking and status indication
Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS 802.11e/WMM, VLAN, TOS
Network Management Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN Manager offers premise-based software controller for up to 3,000 GWN APs
Power and Green Energy Efficiency PoE 802.3af/ 802.3at;
Max Consumption: 12.5W
Environmental Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Physical Unit Dimension: 205.4 x 205.4 x 45.9mm; Unit Weight: 500g
Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 867.3g
Package Content GWN7615 802.11ac Wireless AP, Mounting Kits, Quick Start Guide
Compliance FCC, CE, RCM, IC

Grandstream 802.11ac Wave-2 3×3:3Enterprise Wi-Fi Access Point - GWN7615

Product form

SKU: GWN7615

$219.96 $199.00 Incl. GST

    • Guaranteed secure & safe checkout.

      paypal
    • FREE Express Courier Shipping for all orders over $100
    • 30-Day Returns Policy
    • Back to Base Australian Warranty & Tech Support
    • Australian Stock, No Grey Import Products

    Description

    Description

    The GWN7615 include support for advanced QoS, low-latency real-time applications, mesh networks , captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7615 can be us ed to create a scalable solution as big or small as needed for the deployment scenario, from office buildings to reta il locations, hotels and more.To ensure easy installation and management, the GWN7615 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7615 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management pl atforms. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstr eam’s Wi-Fi-capable IP phones.

    Features

    • 1.75Gbps aggregate wireless throughput and 2x Gigabit wireline ports
    • Dual-band 3x3:3 MU-MIMO technology
    • Self power adaptation upon auto detection of PoE or PoE+
    • Support 200+ concurrent Wi-Fi client devices
    • Up to 175-meter coverage range
    • Advanced QoS to ensure real-time performance of low-latency applications
    • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
    • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premisebased software controller
    • 3 Year Warranty
    Datasheet
    Tech Specs

    Grandstream 802.11ac Wave-2 3×3:3Enterprise Wi-Fi Access Point - GWN7615

    Wi-Fi Standards IEEE 802.11 a/b/g/n/ac (Wave-2)
    Antennas 3 dual band internal antennas
    2.4GHz, gain 3dBi
    5 GHz, gain 3dBi
    Wi-Fi Data Rates IEEE 802.11ac: 6.5 Mbps to 1300Mbps
    IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    IEEE 802.11n: 6.5 Mbps to 450 Mbps
    IEEE 802.11b: 1, 2, 5.5, 11Mbps
    IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    *Actual throughput may vary depending on many factors including environmental conditions, distance between
    devices, radio interference in the operating environment and mix of devices in the network
    Frequency Bands 2.4 GHz Radio: 2412 – 2484 MHz
    5 GHz Radio: 5180-5825 MHz
    Channel Bandwidth 2.4G: 20 and 40MHz
    5G: 20, 40, and 80MHz
    Wi-Fi and System Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control
    lockdown via digital signatures, unique security certificate and random default password per
    device
    MIMO O 3×3:3 2.4G(MIMO)
    3×3:3 5G(MU-MIMO)
    Coverage Range Up to 175 meters
    *coverage range can vary based on environmen
    Maximum TX Power 2.4G: 26 dBm
    5G: 24 dBm
    *Maximum power varies by country, frequency band and MCS rate
    Receiver Sensitivity 2.4G
    802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
    802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
    5G
    802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:-
    63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
    SSIDs 2.4G
    802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
    802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
    5G
    802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:-
    63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
    Concurrent Clients 200+
    Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports
    Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock
    Mounting Indoor wall mount or ceiling mount, kits included
    LEDs 3 x tri-color LEDs for device tracking and status indication
    Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
    QoS 802.11e/WMM, VLAN, TOS
    Network Management Embedded controller can manage up to 50 local GWN APs
    GWN.Cloud offers a free cloud management platform for unlimited GWN APs
    GWN Manager offers premise-based software controller for up to 3,000 GWN APs
    Power and Green Energy Efficiency PoE 802.3af/ 802.3at;
    Max Consumption: 12.5W
    Environmental Operation: 0°C to 40°C
    Storage: -10°C to 60°C
    Humidity: 10% to 90% Non-condensing
    Physical Unit Dimension: 205.4 x 205.4 x 45.9mm; Unit Weight: 500g
    Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 867.3g
    Package Content GWN7615 802.11ac Wireless AP, Mounting Kits, Quick Start Guide
    Compliance FCC, CE, RCM, IC
