| Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac/ax |
| Antennas |
2 dual band internal antennas
2.4GHz, gain 3dBi / 5 GHz, gain 4dBi |
| Wi-Fi Data Rates |
5G:
IEEE 802.11ax: 7.3 Mbps to 1201 Mbps;
IEEE 802.11ac: 6.5 Mbps to 867 Mbps;
IEEE 802.11n: 6.5Mbps to 300Mbps;
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
2.4G:
IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps;
IEEE 802.11n: 6.5Mbps to 300Mbps;
IEEE 802.11b: 1, 2, 5.5, 11 Mbps;
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio
interference in the operating environment and mix of devices in the network |
| Frequency Bands |
2.4GHz radio: 2400-2483.5MHz
5GHz radio: 5150-5850MHz |
| Channel Bandwidth |
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz |
| Wi-Fi and System Security |
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and
critical data/control lockdown via digital signatures, unique security certificate and random
default password per device |
| MIMO |
2x2:2 2.4GHz
2x2:2 5GHz |
| Coverage Range |
Up to 175 meters
*coverage range can vary based on environment |
| Maximum TX Power |
5G: 22dBm
2.4G: 24dBm
*Maximum power varies by country, frequency band and MCS rate |
| Receiver Sensitivity |
2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps;
802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11;
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
802.11ac 20MHz: -67dBm@MCS8; 802.11ac: 40MHz: -63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9 ;
802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11;802.11ax 80MHz: -56dBm @
MCS11 |
