Grandstream E1/T1/J1 Digital VoIP Gateway - GXW4501

Description

Description

The GXW4500 series are E1/T1 Digital VoIP Gateways that allow digital PSTN and ISDN trunks to be integrated with VoIP networks. By connecting the GXW4500 series with a VoIP network and a traditional PBX or E1/ T1 provider, businesses can drastically increase the amount of PSTN/ISDN trunks integrated with their VoIP network. The GXW4500 series offers three models that provide 1, 2 or 4 E1/T1/J1 spans and support 30, 60 or 120 concurrent calls to cater to the VoIP needs of large and medium sized enterprises.

Features

  • TLS and SRTP security encryption technology to protect calls and accounts
  • Software-configurable E1/T1/J1 port and supports PRI, SS7 and MFC R2
  • Dual Gigabit network ports with a configurable integrated NAT router
  • Supports up to 120 concurrent calls, multi-language voice prompts and T.38 fax
  • Automated provisioning by HTTPs/TFTP with XML config files
  • Supports nearly all popular voice codecs including G.722, G.729, iLBC, and more
Datasheet
Tech Specs

Grandstream E1/T1/J1 Digital VoIP Gateway - GXW4501

E1/T1/J1 Interface 1/2/4 RJ45 ports, supporting up to 30/60/120 simultaneous VoIP calls
Network Interfaces Dual self-adaptive Gigabit ports (switched or routed)
Peripheral Ports (2) USB 3.0, (1) SD card interface
LED Indicators LAN, WAN, E1/T1/J1
LCD Display 128x32 dot matrix graphic LCD with DOWN and OK buttons
Reset Switch Yes, long press for factory reset and short press for reboot
Voice & Video Capabilities
Voice-over-Packet Capabilities LEC with NLP Packetized Voice Protocol Unit, 128ms-tail-length carrier grade Line Echo Cancellation, Dynamic Jitter Buffer, Modem detection & auto-switch to G.711
Voice and Fax Codecs G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC, AAL2-G.726-32
Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Passthrough, Fax data pump V.17, V.21, V.27ter, V.29 for T.38 fax relay
Voice-quality Enhancement Echo cancellation (G.168-2004), Jitter buffer, Silence suppression (VAD, CNG), PLC
QoS Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Signaling & Control
DTMF Methods In-band audio, RFC2833, and SIP INFO
Digital Signaling SIP (RFC 3261) over UDP/TCP/TLS, PRI, SS7, MFC R2, RBS (pending)
PRI switch types: Euro ISDN, nation, Q.SIG
CAS: MFC R2 (Argentina, Brazil, China, Czech Republic, Colombia, Ecuador, Indonesia, ITU,
Mexico, Philippines, Venezuela)
SS7: ITU, ANSI, China
Upgrade Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload
Device Management Syslog, HTTPS, Web browser, voice prompt, TR-069 management, backup and restore, port
capture and packet capture
Network Protocols TCP/UDP/IP, RTP/RTCP, ICMP, ARP, DNS, DDNS, DHCP, NTP, TFTP, SSH, HTTP/HTTPS, PPPoE,
STUN, SRTP, TLS, LDAP, PPP, Frame Relay (pending), IPv6, OpenVPN®
Status and statistic Call status and history, device status monitoring and ISDN status monitoring
Security
Media Encryption SRTP, TLS, HTTPS, SSH, 802.1X
User-defined ports SIP port, RTP port, HTTP/HTTPS port
Advanced Defense Fail2ban, alert events, Whitelist, Blacklist, strong password based access control
Physical
Universal Power Supply Input: 100 ~ 240VAC, 50/60Hz; Output: DC+12V, 2A
Physical & Dimensions GXW4501: Unit Weight: 2,350g; Package Weight: 3130g
GXW4502: Unit Weight: 2360g; Package Weight: 3140g
GXW4504: Unit Weight: 2380g; Package Weight: 3160g
Unit Dimensions: 485mm(L) x 191mm(W) x 46.2mm (H)
Temperature and Humidity Operating: 32 - 113ºF / 0 ~ 45ºC, Humidity 10 - 90% (non-condensing)
Storage: 14 - 140ºF / -10 ~ 60ºC, Humidity 10 - 90% (non-condensing)
Mounting Rack mount & Desktop
Additional Features
Multi-Language Support Web UI: English, Simplified Chinese, Traditional Chinese, Spanish, French, Portuguese, German, Russian, Italian, Polish, Czech;
Customizable IVR/voice prompts: English, Chinese, British English, German, Spanish, Greek,
French, Italian, Dutch, Polish, Portuguese, Russian, Swedish, Turkish, Hebrew, Arabic;
Customizable language pack to support any other languages
Compliance FCC 47 C.F.R FCC Part 15 Class B
47 C.F.R FCC Part 68 (TIA-968-B Section 5.2.4 (T1+ISDN))
CE EN 55032,EN 55035,EN 61000-3-2,EN 61000-3-3,EN 60950-1,TBR 4 (E1+ISDN),TBR 12
(E1),TBR 13 (E1+ISDN)
RCM AS/NZS CISPR 32,AS/NZS 61000.3.2,AS/NZS 61000.3.3,AS/NZS 60950.1,AS/ACIF
S016(E1),AS/ACIF S038(E1+ISDN)
Other ITU K.21 (Enhanced Levels); UL 60950-1 (Power adapter)

Read more

Grandstream E1/T1/J1 Digital VoIP Gateway - GXW4501

Product form

SKU: GXW4501

Out of stock

$1,425.66 $1,399.00 Incl. GST

    • FREE Express Courier Shipping for all orders over $100
    • 30-Day Returns Policy
    • Back to Base Australian Warranty & Tech Support
    • Australian Stock, No Grey Import Products
    📌 Download Datasheet - datasheet_gxw45XX_series_english.pdf

    Description

    Description

    The GXW4500 series are E1/T1 Digital VoIP Gateways that allow digital PSTN and ISDN trunks to be integrated with VoIP networks. By connecting the GXW4500 series with a VoIP network and a traditional PBX or E1/ T1 provider, businesses can drastically increase the amount of PSTN/ISDN trunks integrated with their VoIP network. The GXW4500 series offers three models that provide 1, 2 or 4 E1/T1/J1 spans and support 30, 60 or 120 concurrent calls to cater to the VoIP needs of large and medium sized enterprises.

    Features

    • TLS and SRTP security encryption technology to protect calls and accounts
    • Software-configurable E1/T1/J1 port and supports PRI, SS7 and MFC R2
    • Dual Gigabit network ports with a configurable integrated NAT router
    • Supports up to 120 concurrent calls, multi-language voice prompts and T.38 fax
    • Automated provisioning by HTTPs/TFTP with XML config files
    • Supports nearly all popular voice codecs including G.722, G.729, iLBC, and more
    Datasheet
    Tech Specs

    Grandstream E1/T1/J1 Digital VoIP Gateway - GXW4501

    E1/T1/J1 Interface 1/2/4 RJ45 ports, supporting up to 30/60/120 simultaneous VoIP calls
    Network Interfaces Dual self-adaptive Gigabit ports (switched or routed)
    Peripheral Ports (2) USB 3.0, (1) SD card interface
    LED Indicators LAN, WAN, E1/T1/J1
    LCD Display 128x32 dot matrix graphic LCD with DOWN and OK buttons
    Reset Switch Yes, long press for factory reset and short press for reboot
    Voice & Video Capabilities
    Voice-over-Packet Capabilities LEC with NLP Packetized Voice Protocol Unit, 128ms-tail-length carrier grade Line Echo Cancellation, Dynamic Jitter Buffer, Modem detection & auto-switch to G.711
    Voice and Fax Codecs G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC, AAL2-G.726-32
    Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Passthrough, Fax data pump V.17, V.21, V.27ter, V.29 for T.38 fax relay
    Voice-quality Enhancement Echo cancellation (G.168-2004), Jitter buffer, Silence suppression (VAD, CNG), PLC
    QoS Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
    Signaling & Control
    DTMF Methods In-band audio, RFC2833, and SIP INFO
    Digital Signaling SIP (RFC 3261) over UDP/TCP/TLS, PRI, SS7, MFC R2, RBS (pending)
    PRI switch types: Euro ISDN, nation, Q.SIG
    CAS: MFC R2 (Argentina, Brazil, China, Czech Republic, Colombia, Ecuador, Indonesia, ITU,
    Mexico, Philippines, Venezuela)
    SS7: ITU, ANSI, China
    Upgrade Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload
    Device Management Syslog, HTTPS, Web browser, voice prompt, TR-069 management, backup and restore, port
    capture and packet capture
    Network Protocols TCP/UDP/IP, RTP/RTCP, ICMP, ARP, DNS, DDNS, DHCP, NTP, TFTP, SSH, HTTP/HTTPS, PPPoE,
    STUN, SRTP, TLS, LDAP, PPP, Frame Relay (pending), IPv6, OpenVPN®
    Status and statistic Call status and history, device status monitoring and ISDN status monitoring
    Security
    Media Encryption SRTP, TLS, HTTPS, SSH, 802.1X
    User-defined ports SIP port, RTP port, HTTP/HTTPS port
    Advanced Defense Fail2ban, alert events, Whitelist, Blacklist, strong password based access control
    Physical
    Universal Power Supply Input: 100 ~ 240VAC, 50/60Hz; Output: DC+12V, 2A
    Physical & Dimensions GXW4501: Unit Weight: 2,350g; Package Weight: 3130g
    GXW4502: Unit Weight: 2360g; Package Weight: 3140g
    GXW4504: Unit Weight: 2380g; Package Weight: 3160g
    Unit Dimensions: 485mm(L) x 191mm(W) x 46.2mm (H)
    Temperature and Humidity Operating: 32 - 113ºF / 0 ~ 45ºC, Humidity 10 - 90% (non-condensing)
    Storage: 14 - 140ºF / -10 ~ 60ºC, Humidity 10 - 90% (non-condensing)
    Mounting Rack mount & Desktop
    Additional Features
    Multi-Language Support Web UI: English, Simplified Chinese, Traditional Chinese, Spanish, French, Portuguese, German, Russian, Italian, Polish, Czech;
    Customizable IVR/voice prompts: English, Chinese, British English, German, Spanish, Greek,
    French, Italian, Dutch, Polish, Portuguese, Russian, Swedish, Turkish, Hebrew, Arabic;
    Customizable language pack to support any other languages
    Compliance FCC 47 C.F.R FCC Part 15 Class B
    47 C.F.R FCC Part 68 (TIA-968-B Section 5.2.4 (T1+ISDN))
    CE EN 55032,EN 55035,EN 61000-3-2,EN 61000-3-3,EN 60950-1,TBR 4 (E1+ISDN),TBR 12
    (E1),TBR 13 (E1+ISDN)
    RCM AS/NZS CISPR 32,AS/NZS 61000.3.2,AS/NZS 61000.3.3,AS/NZS 60950.1,AS/ACIF
    S016(E1),AS/ACIF S038(E1+ISDN)
    Other ITU K.21 (Enhanced Levels); UL 60950-1 (Power adapter)

    Read more
