Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac/ax |
Antennas |
2 dual band external antennas 2.4GHz, gain 3.5dBi 5 GHz, gain 3.5dBi |
Wi-Fi Data Rates |
5G: IEEE 802.11ax: 7.3 Mbps to 1201 Mbps IEEE 802.11ac: 6.5 Mbps to 867 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 2.4G: IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps IEEE 802.11n: 6.5Mbps to 300Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network |
Frequency Bands |
2.4GHz radio: 2412 - 2484 MHz 5GHz radio: 5180 - 5825 MHz *Not all frequency bands can be used in all regions. |
Channel Bandwidth |
h 2.4G: 20 and 40 MHz 5G: 20, 40 and 80 MHz |
System Security |
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
MU-MIMO |
2×2:2 2.4GHz, 2×2:2 5GHz |
Coverage Range |
Up to 250 meters *Coverage range can vary based on environment |
Maximum TX Power |
5G: 26dBm 2.4G: 30dBm *Maximum power varies by country, frequency band, and MCS rate |
Receiver Sensitivity |
2.4G 802.11b: -99dBm@1Mbps, -90dBm@11Mbps; 802.11g: -93dBm @6Mbps, -77dBm@54Mbps; 802.11n 20MHz: -74dBm @MCS7; 802.11n 40MHz:-72dBm @MCS7; 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -62dBm @MCS11 5G 802.11a: -95dBm @6Mbps, -77dBm @54Mbps; 802.11ac 20MHz: -71dBm@MCS8; 802.11ac: HT40:- 67dBm @MCS9; 802.11ac 80MHz: -64dBm @ MCS9; 802.11ax 20MHz: -63dBm @ MCS11; 802.11ax 40MHz: -62dBm @MCS11;802.11ax 80MHz: -58dBm @MCS11 |
