| Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac/ax |
| Antennas |
4 individual internal antennas, 2 per band
2.4GHz: maximum gain 4.5dBi
5 GHz: maximum gain 5dBi |
| Wi-Fi Data Rates |
5G:
IEEE 802.11ax: 7.3 Mbps to 1201 Mbps
IEEE 802.11ac: 6.5 Mbps to 867 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
2.4G:
IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between devices,
radio interference in the operating environment and mix of devices in the network |
| Frequency Bands |
2.4GHz radio: 2400 – 2483.5 MHz
(2412-2472MHz are channel central frequency range; 2400-2483.5MHz is Frequency band)
5GHz radio: 5150 - 5850 MHz
*Not all frequency bands can be used in all regions |
| Channel Bandwidth |
2.4G: 20 and 40 MHz
5G: 20, 40 and 80 MHz |
| Wi-Fi and System Security |
WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control
lockdown via digital signatures, unique security certificate and random default password per device |
| MU-MIMO |
2×2:2 2.4GHz
2×2:2 5GHz |
| Coverage Range |
Up to 175 meters
*coverage range can vary based on environment |
| Maximum TX Powe |
5G: 26dBm
2.4G: 27dBm
*Maximum power varies by country, frequency band and MCS rate |
| Receiver Sensitivity |
2.4G
802.11b: -97dBm@1Mbps, -89dBm@11Mbps;
802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -63dBm @MCS11
5G
802.11a: -93dBm @6Mbps, -75dBm @54Mbps;
802.11n: 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7
802.11ac 20MHz: -70dBm@MCS8; 802.11ac: HT40:- 66dBm @MCS9; 802.11ac 80MHz: -62dBm @MCS9;
802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -61dBm @MCS11;802.11ax 80MHz: -58dBm @MCS11 |
