| Video |
|---|
| Imaging Device |
1/2.8" 5MP CMOS |
| Effective Pixels |
2592(H)x1944(V) |
| Min. Illumination |
Color: 0.15Lux(F2.0, 1/30sec)
BW: 0Lux(IR LED on) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
6.0mm fixed focal |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H: 49.4°/ V: 37.4°/ D: 61.0° |
| Focus Control |
Fixed |
| Operational |
|---|
| IR Viewable Length |
30m(98.42ft) |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR |
| Motion Detection |
4ea, polygonal zones |
| Privacy Masking |
6ea, rectangular zones |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output |
| Network |
|---|
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Resolution |
2592x1944, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| Smart Codec |
WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory |
512MB RAM, 256MB Flash |
| Environmental |
|---|
| Operating Temperature / Humidity |
-30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -20°C |
| Storage Temperature / Humidity |
-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
| Certification |
IP66, IK10 |
| Electrical |
|---|
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 7.50W, typical 6.10W |
| Mechanical |
|---|
| Color / Material |
Dark grey / Aluminum |
| Product dimensions / weight |
Ø70.0x246.0mm(Ø4.33x3.39"), 680g(1.50 lb) |
