| VIDEO |
| Imaging Device |
1/2.8" 2M CMOS |
| Total Pixels |
1,945(H) x 1,109(V) 2.16M pixels |
| Effective Pixels |
1,945(H) x 1,097(V) 2.13M pixels |
| Scanning System |
Progressive Scan |
| Min. Illumination |
Color : 0.11 Lux (F1.6, 1/30sec)
B/W : 0 Lux (IR LED on) |
| S / N Ratio |
52dB (AGC Off, Weight On) |
| Video Output |
BNC (AHD / TVI / CVI / CVBS selectable) |
| Resolution |
1920 x 1080 |
| Max. Framerate |
25fps@1080p(P) |
| LENS TYPE |
| Focal Length (Zoom Ratio) |
3.2 ~ 10mm (3.1x) motorized varifocal |
| Max. Aperture Ratio |
F1.6 |
| Angular Field of View |
H : 110.2°(Wide) ~ 32°(Tele) / V : 55.4°(Wide) ~ 18°(Tele) / D : 128.4°(Wide) ~ 36.6°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Simple focus (Motorized V/F) / Manual |
| Lens Type |
DC Auto Iris |
| Mount Type |
Board-in Type |
| OPERATIONAL |
| On Screen Display |
Multi-language support (16)
English, Japanese, Spanish, French, Portuguese, Korean, German, Italian, Russian, Polish, Czech, Romanian, Serbian, Swedish, Danish, Turkish |
| Camera Title |
Off / On (Displayed 15 Characters) |
| Day & Night |
Auto (ICR) / Color / B/W |
| Backlight Compensation |
Off / User BLC / HLC / WDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR. (Off / On) |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (4 zones) |
| Privacy Masking |
Off / On (8 zones rectangle) |
| Gain Control |
Off / Low / Middle / High / Very High |
| White Balance |
ATW / Outdoor / Indoor (4,500K° ~ 8,500K°) / Manual / AWC (1,800K° ~ 10,500K°) |
| Electronic Shutter Speed |
1sec ~ 1/12,000sec |
| Reverse |
Off / H-Rev / V-Rev / HV-Rev |
| Profile |
Basic, Day & Night, Backlight, ITS, Indoor, User |
| Alarm |
(MD) Output 1 |
| Remote Control Interface |
Coaxial |
| Protocol |
AHD : ACP (AHD Coax Protocol), CVBS : Pelco-C (Coaxitron), CCP (CVI Coax Protocol), TCP (TVI Coax Protocol) |
| IR Distance |
30m (98.43ft) |
| Video Transmission Distance |
500m (5C2V Coaxial Cable) |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -10°C (+14°F) |
| Ingress Protection |
IP66 |
| Vandal Resistance |
IK10 |
| ELECTRICAL |
| Input Voltage / Current |
Dual (24V AC ±10% & 12V DC ±10%) |
| Power Consumption |
Max. 6W |
| MECHANICAL |
| Color / Material |
Dark Gray / Aluminum |
| Dimensions (WxH) |
Ø78.0 x 259.8mm (Ø3.07" x 10.23") (Without sunshield) |
| Weight |
948g (2.09 lb) |
